Summary of Contents for Nuvico CF-ST1N
- Page 1 *Lens not included.
- Page 2 NUVICO. • NUVICO makes no warranties for damages resulting from corrupted or lost data due to a mistaken operation or malfunction of the cameras, peripheral devices, or unapproved/...
-
Page 3: Warning And Caution
Warning and Caution WARNING! TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR OPENINGS ON THE EQUIPMENT. CAUTION! The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”... -
Page 4: Fcc Compliance Statement
FCC Compliance Statement FCC INFORMATION : THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. -
Page 5: Important Safeguards
Important Safeguards • Read these instructions. • Heed all warnings. • Follow all instructions. • Do not use this equipment near water. • Clean only with dry cloth. • Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. -
Page 6: Table Of Contents
Table of Contents ..................... Disclaimer ..................Warning and Caution ................FCC Compliance Statement ................CE Compliance Statement .................. Important Safeguards ..................Table of Contents ............Introduction / Content Verification ..................Parts & Descriptions ..................Camera Dimensions ..............Installing the DC Auto Iris Lens ................... - Page 7 Table of Contents (Continued) OSD Menu Terms & Settings (Continued) ....................2.3 RED ....................2.4 BLUE ............3. BLC SETUP (Back Light Compensation) ....................3.1 MODE ....................3.2 LEVEL ........3.3 BMB Mode Menu (Brightlight Masking Block) ....................4. SPECIAL ............
-
Page 8: Introduction / Content Verification
Introduction ABOUT THIS MANUAL Thank you for purchasing our S.I.E.™ 2 Fixed Camera. Our Fixed Cameras are all equipped with high resolution 1/3” Interline transfer CCD Imager for enhanced low light sensitivity. Combined with our 2nd generation ‘Super Image Enhancer II’ - ‘SIE II’ module, viewing in the dark is radically amplified. A user-friendly, on- screen display (OSD) menu make it easy to setup and program functions. -
Page 9: Parts & Descriptions
Parts & Descriptions Front Bottom 1. Sensor Protective Cap Be sure to cap the lens mount when the lens is not mounted. Pull out the cap to mount the lens. . CS-Mount Lens Adaptor Used to mount a CS-mount lens. . - Page 10 Parts & Descriptions Back . Video Output Connector BNC connector for composite video out. 7. OSD Menu Set up Key Control the OSD menu. 8. Power Indicator 9. Auto Iris Lens Connector Connect auto iris lens plug. 10. Power Input Terminal Connect 24VAC or 12VDC power source.
-
Page 11: Camera Dimensions
Camera Dimensions See the diagrams below for the exact dimensions of the Fixed Camera. Dimensions Unit: mm... -
Page 12: Installing Dc Auto Iris Lens
Installation Installing DC Auto Iris Lens Using DC Auto Iris lens, connect the Iris lens plug to the camera as shown below. 1. Strip approximately 8mm for outer shield and 2mm for inner shield of lens cable for soldering. 2. Remove the cover from the Iris lens plug and solder the lens cable to the plug pin following the table below. -
Page 13: Power Requirement
Installation Power Requirement - 12VDC/24VAC 500mA regulated power supply. - The camera is reverse - polarity protected. Note: Do not use power sources other than specified. -
Page 14: Camera Osd Setup Controls
Camera OSD Setup Controls Please use the directional keys located at the back of the camera to make the desired changes in the OSD menu. Directional Navigation Keys Up Key Enter Key Left Key Right Key Down Key... -
Page 15: Osd Menu Controls (On-Screen-Display)
OSD Menu Controls & Navigation OSD MENU CONTROLS (On-Screen-Display) Enter Key - Used to access MAIN SETUP menu mode. Up / Down Key - Used to scroll through the desired sub-menu selection and to move the cursor up or down during the OSD menu. Left / Right Key - Used to adjust the desired menu selection, and to move the cursor left or right during the OSD menu. -
Page 16: Osd Menu Terms & Settings
OSD Menu Terms & Settings 1. AE MODE (Automatic Exposure) The AE MODE is used to control the video output levels under different intensities in the lighting. The factory default is ‘ALC.’ 1.1 MODE (ELC, ALC) • ALC (Automatic Level Control): Select the ALC mode and the camera will continuously monitor changes in the lighting intensity and automatically adjust the Iris to the most optimal level. -
Page 17: Shutter
OSD Menu Terms & Settings 1.3 SHUTTER (AUTO, 1/60 a ... a 1/100,000) • In the case of ALC Mode: The SHUTTER speed can be selected manually according to user preference. The shutter speed of 1/60(NTSC), or 1/50(PAL) seconds are recommended. •... -
Page 18: Wb Setup (White Balance)
OSD Menu Terms & Settings . WB SETUP (White Balance) The WB SETUP is used to control the white balance under different illumination sources. Adjust this setting to calibrate the camera for correct color rendering. The factory default of ‘AWC AUTO’ is strongly recommended. 2.1 MODE (AWC, ATW, INDOOR, OUTDOOR, MWB) •... -
Page 19: Control
OSD Menu Terms & Settings 2.2 CONTROL - WB Mode Control (LOCK, AUTO, CRLS, 3200°K, 5400°K, R/BCONT) • This field displays the current CONTROL status of the WB mode. In the AWC LOCK mode, the user may control the white balance after pointing the camera to the desired location. -
Page 20: Blc Setup (Back Light Compensation)
OSD Menu Terms & Settings . BLC SETUP (Back Light Compensation) The BLC SETUP is used to control the various Back Light Compensation modes available in the Fixed camera. BLC can assist in compensating for exposure problem associated with very bright backgrounds causing subjects to bloom or silhouette. The factory default is ‘OFF.’... -
Page 21: Bmb Mode Menu (Brightlight Masking Block)
OSD Menu Terms & Settings 3.3 BMB Mode Menu (Brightlight Masking Block) To activate or deactivate specific areas to be masked by BMB, follow the simple instructions below 1. Select the BMB mode, then scroll down to AREA SEL and press the LEFT/RIGHT Key. . -
Page 22: Special
OSD Menu Terms & Settings . SPECIAL The Special Setup is used to control the MOTION, PRIVACY MASK, DNR, SHARPNESS, LANGUAGE, EDIT TITLE, and FACTORY DEFAULT of the dome camera. 4.1 MD SETUP - Motion Detection •OPERATION: Select this function ON or OFF. The MD detects motion in area monitored by the camera. -
Page 23: Pzm Set (Private Zone Masking)
OSD Menu Terms & Settings 4.2 PZM SET (Private Zone Masking) The PZM is used to mask specific areas within the frame of the camera to be concealed. A total of 8 areas can be masked. To setup the Privacy Zone masks, follow the simple instructions below. -
Page 24: Dnr (Digital Noise Reduction)
OSD Menu Terms & Settings 4.3 DNR - Digital Noise Reduction (OFF, LOW, HIGH) The DNR improves picture quality by filtering out signal noise associated with night-time recording. It compares pictures from a frame with the one previous and removes noise grains not present before. -
Page 25: Factory Default
OSD Menu Terms & Settings 1. Select the DISPLAY, then change the setting to “ON” using the LEFT/RIGHT keys. . Scroll down to the bottom and input the desired custom title (10 digits MAX). A custom title may be entered by pressing the ENTER key while highlighting the desired letter, number, or symbol shown above. -
Page 26: Technical Specifications | Ntsc
Technical Specifications | NTSC Technical Specifications CF-ST1N Video Format NTSC Image Sensor 1/3” CCD Horizontal Resolution 580 TV Lines Day / Night Functionality Lens Mount Type C/CS Sync System Internal Effective Pixels (HxV) 768 x 494 Scanning System 525 Lines. 2:1 Interlaced Electronic Shutter 1/60 ~ 1/100,000 sec. -
Page 27: Technical Specifications | Pal
Technical Specifications | PAL Technical Specifications CF-ST1P Video Format Image Sensor 1/3” CCD Horizontal Resolution 580 TV Lines Day / Night Functionality Lens Mount Type C/CS Sync System Internal Effective Pixels (HxV) 752 x 582 Scanning System 625 Lines. 2:1 Interlaced Electronic Shutter 1/50 ~ 1/100,000 sec. - Page 28 050600003600...
