Installation

3.7.7 Contactor

The contactor is powered by a customer-supplied 230 V
AC 50/60 Hz signal.
Voltage Frequency Contactor
[V] converter manufacturer and
model type
N110T5– GE CK95BE311N
N160T4
380-500 N200T5– GE CK11CE311N
N250T4
N315T4 GE CK11CE311N
N75KT7– GE CK95BE311N
N160T7
525-690
N200T7– GE CK11CE311N
N400T7
Table 3.7 Contactor Types
NOTICE
In applications requiring UL listing, when the frequency
converter is supplied with a contactor, the customer
must provide external fusing to maintain the UL rating
of the frequency converter and a short circuit current
rating of 100,000 A. See chapter 11.1.1 Power-dependent
Specifications for fuse recommendations.

3.7.8 Circuit Breaker

Table 3.8 provides details on the type of circuit breaker
provided as an option with the various units and power
ranges.
Voltage [V] Frequency
converter model
N110T5–N132T5
N160T5
380–500 N200T5
N250T5
N315T5
N75KT7–N160T7
525–690 N200T7–N315T7
N400T7
Table 3.8 Circuit Breaker Types
MG16D302
Operating Instructions
IEC
utilization
category
AC-3
AC-3
AC-1
AC-3
AC-3
Circuit breaker manufacturer
and type
ABB T5L400TW
ABB T5LQ400TW
ABB T6L600TW
ABB T6LQ600TW
ABB T6LQ800TW
ABB T5L400TW
ABB T6L600TW
ABB T6LQ600TW
