Specifications
Frame Size
Terminal
D1h/D3h/D5h/D6h Mains
Motor
Load sharing
Regen
Earth (Ground)
Brake
D2h/D4h/D7h/D8h Mains
Motor
Regen
Load sharing
Earth (ground)
Brake
Table 11.10 Torque for Terminals
MG16D302
Operating Instructions
Torque
Bolt
size
19-40 Nm
M10
(168-354 in-lbs)
8.5-20.5 Nm
M8
(75-181 in-lbs)
19-40 Nm
M10
(168-354 in-lbs)
8.5-20.5 Nm
M8
(75-181 in-lbs)
Danfoss A/S © Rev. 06/2014 All rights reserved.
11
11
85
