Page 1: User Manual
User manual CQ Future Combi automat Your retail dealer U_GB ................Rev. 080822 ................1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1... -
Page 2: Table Of Contents
1. Table (list) of contents. Table of contents sid. 2 General Overview of components, membran switch Overview of components, front Overview of components mixing system SERVICE; Installation and start Place the brewer Connectings: Electricity/Water Starting up machine Fill canisters Operation Brewing of coffee in cup, , Brewing of jug Cleaning program... -
Page 3: General
Please read this manual before you take the machine into operation for the first time. The manual contains important instructions for a safe and proper use of the machine. Always keep this manual within reach for the user! CQ Future Combi automat Making coffee cup by cup Jug facility with key switch... -
Page 4: Overview Of Components Membranswitch
3. Overview of components membranswitch. Future Membranswitch Drink 1 Drink 5 Drink 2 Drink 6 Drink 3 Drink 7 Drink 4 Drink 8... -
Page 5: Overview Of Components, Front
3. Overview of components , front Future Display Key switch Membran switch 8 choices of drinks Door lock Strength of drinks ++ / - - Outlet drinks Drip tray Drip tray insert... -
Page 6: Overview Of Components Mixing System
3. Overview of components , mixer system Future Ingredients- canisters Chute Mixer bowls FUTURE IV 2 mixer bowls Brewing mechanism Outlet FUSE holder Main switch FUTURE III Detail; Ingredients; Width; Height; Volume/litre; Amount/unit Canister; coffee ´ Canister; choco Canister; topping FUTURE IV Detail;... -
Page 7: Service; Installation And Start
4. Service. Installation and start Future Place the machine on a flat level and waterproof surface. Connect the electrical plug to a separate grounded wall socket 230V 10A. OBSERVE! Make sure there is a space behind the machine for free flow of air.( minimum 10cm ). Connect attached water tube to cold water with an R 1/2”. -
Page 8: Fill Canisters
4. Service. Installation and start Future Fill canisters with ingredients. Take out (this to avoid unnecessery spillage in the machine) ingredient canisters and fill them with ingredients. When placing the ingredient canisters; Make sure that the outlet pipes on the ingredient canisters are touching the steam traps (B) and that the coffee powder will fall into the centre of the brew mechanism (A). - Page 9 5. Operation; Brewing of coffee in cup Future Brewing of coffe etc. in a cup Place a cup in the centre of the cup holder. The strength has a standard setting, if you wish to increase or decrease it, do as follows , if not continue to point 3.
-
Page 10: Operation
5. Operation; Brewing of coffee into jug. Future Brewing of jug. Place a jug in the centre of drip tray. (For jug 1,8L dismantle drip tray). Serving pot 1, 8L: Serving pot 1,2L: art.nr. 1103091 art.nr. 110001 Thermos pot 1L : art.nr. 1103251 Turn on the key with jug symbole clockwise. -
Page 11: Cleaning Program
6. Cleaning program CLEANING Future Automatic cleaning of brew mechanism, mixing bowl: Should be done every week. The brewmechanism can easily be cleaned with the key switch in ”cup” (normal) position. Turn the key slowly ninety degress and back again. Push button for drink 1 for 6 seconds. - Page 12 6. Cleaning program CLEANING Future Dismantling and cleaning/washing brew house: Dismantle brew house: 3. Flush brew house! To remove detergent and coffee remnants. Reassemble brew house. NOTE! When reassemble brew house make sure that (B) wiper are between (A) arms.
-
Page 13: Automatic Cleaning Of Mixing Bowl
6. Cleaning program. CLEANING Future Weekly cleaning! Automatic cleaning of mixing bowls 2 or 3. If you only wish to clean the mixer bowl and whipper house; Follow these instructions: The mixer bowls can easily be cleaned with the key switch in ”cup”... -
Page 14: Automatic Cleaning Of In/Outlet Valves
6. Cleaning program CLEANING Future Automatic cleaning of In/Outlet valves: The In/Outlet valves can easily be cleaned with the key switch in ”cup” (normal) position. Place a jug under the outlet. (dismantle drip tray). Turn the key slowly ninety degrees and back again. -
Page 15: Rotate Brew Mechanism Without Water Or Ingredients
6. Cleaning program CLEANING Future Rotate brew mechanism without water or ingredients: The brew mechanism can be rotatedwithout water and ingredients with the key switch in ”cup” (normal) position. To be used when brew mechanism has been dismounted for washing and shall be remounted. -
Page 16: Weekly Cleaning
7. CLEANING: Weekly cleaning Future Dismantle : Mixer system Cleaning Loosen mixer bowl. Pull apart (C). 5. Clean with a wet rag and Loosen outlet hose (A) drought drily. turn lock knob (B) anti-clockwise. Wash these parts: A. Mixer bowl B. -
Page 17: Assemble Mixer System
7. CLEANING: Weekly cleaning Future REASSEMBLE: Mixer system Make sure that the motor whippers plane side will be in accordance with the whippers plane Reassemble the assembly plate by turning side. see next (G) and picture (H). lock knob (F) clockwise. INSPECT gaskets. pil (G). -
Page 18: Cleaning And Maintenance
Prolonged contact with detergent may damage the screen assembly. Once this is done, the screen should then be thoroughly rinsed with dish soap and warm water to remove any leftover residu Cleaning agent: (brew mechanism) Coffee Queen artikel nr 1104161 Filter: (brew mechanism) Coffee Queen artikel nr... -
Page 19: Outside Cleaning
8. Cleaning and maintenance CLEANING Future Outside cleaning; Outside cleaning; use a soft rag and liquid cleaning agent that doesn´t scratch. -
Page 20: Cup Counter And Easy Access
Cup counter -Easy Access Future Cup counter: Easy Access: The machine has an in built cup counter which Volume and strength can be adjusted with±15% is available to with the key switch see and reset with the key switch in ”cup” (nor- in ”cup”... -
Page 21: Safety Functions
10. Safety functions. Future The machine is equipped with following safety functions Indication of door Door not closed The display shows; ”Door open” ”Door open” When machine is not in use: Valves are blocked. 11. Failure messages. Failure messages which can mostly be corrected without any help from service company The display shows;... -
Page 22: Dimension Sketch
13. DIMENSION SKETCH. Future... -
Page 23: Circuit Diagram
14. Circuit diagram. - Page 24 COFFEE QUEEN FOR SERVICE Please contact your retail dealer Your retail dealer ................................................COFFEE QUEEN AB Box 960, 67129 ARVIKA besöksadress; korpralsv. 1B, Tel vxl; +46 (0)570-477 00, Fax; +46 (0)570 477 19 E-mail: info@coffeequeen.se www.coffeequeen.se Art. no. 1704013...
