  • Page 1 Service manual Coffee Queen Espressomachines Compact Digital 2 groups Digital 3 - 4 groups Crema Compact Digital S / GB Your retail dealer Rev.041004...

  • Page 2: Table Of Contents

    Contemplated use and warnings Technical description 5.1 Overview of the espresso coffee machines Crema Comp/Dig 5.2 Operating Principles 5.3 Operation for espresso machine model Crema Compact/Digital Safety precautions Installation - Location - Start up 7.1 Precautions for installation 7.2 Locations and connections 7.3 Start up...

  • Page 3: Orientation

    2. Orientation 1. Steam pipe 8. Main switch 2. Tap handgrip (steam) 9. Indication light 3. Manometer 10. Drip tray 4. Tap handgrip (hotwater) 11. Outlet (hotwater) 5. Brew switch (manual) 12. Handgrip for filterholder 6. Push-button pad 13. Rubber spacer ( for automatic cleaning).

  • Page 4: Introduction

    Introduction: Crema Compact och Digital Save; your manual and instructions: The manual is dedicated the user and/or an authorized personel. It will give you information how to use the machine in a correctly way, desirable maintenance and a good safety and security for the user.

  • Page 5: Contemplated Use And Warnings

    Long machine stoppages at temperatures as below 0ºC (zero degrees celsius) can cause damage or breakage to the piping boiler ; thus total emptying is recommended. 5. Technical description Crema Compact och Digital 5.1 Overview of the espresso coffee machines Crema Compact och Digital Automatic coffee machines Crema Compact och Crema Compact Take Away Espresso coffee machine with microprocessor controlled electronic measured dosage and digital programming from the push-button pad.

  • Page 6: Operating Principles

    Technical description Crema Compact och Digital 5.3 Operation for espresso machine model Crema Compact och Digital Water system diagram The water used for production of coffee does not come from the boiler. It is supplied directly from the water net, through the heat exchangers inside the boiler.

  • Page 7: Installation - Location - Start Up

    Installation - Location - Start up Crema Compact och Digital 7.1 Precautions for installation The manufacturer has obviously taken every possible precaution to guarantee user safety, but the different installation and/or transport conditions could give rise to uncontrollable or unpredictable conditions; so it is always necessary to assess hidden hazards and to consider the following suggestions: The packing elements (cardboard, cellophane,metal staples, etc.) can cut, wound or cause...

  • Page 8: Locations And Connections

    Installation - Location - Start up Crema Compact och Digital 7.2 Locations and connections Before installing the machine it is advisable to check the efficiency of the water mains (pos. 10 fig. 1), of the electrical connections (pos. 1 fig. 1) and of the gas mains ( for gas heated machines). An electric cut out (pos.

  • Page 9: Digital Automatic Version Dose Programming

    Installation - Location - Start up Crema Compact och Digital 7.5 Digital automatic version dose programming: To program the doses: (fig. 2). Press button on push-button pad in approx. 8 seconds. The Indicator lamps above the other buttons will be switched on.

  • Page 10: Failure Message

    Installation - Location - Start up Crema Compact och Digital 7.6 Failure message Finite brewtime for each group are 240 seconds. If you reach this time indicator lamp start blinking and the group will be blocked. If the flowmeter operate incorrect, the indic. lamp above the button you pressed will start blinking.

  • Page 11: Automatic Cleaning Of The Groups

    (B fig. C) Put 20 gram of detergent in filterholder (C fig. C). Detergent can be ordered from your retail dealer or Coffee Queen AB. Hook the filterholder in a careful way into the group you want to clean. (D fig. D) Turn OFF the machine with the main switch.

  • Page 12: User Instructions

    User instructions Crema Compact och Digital The following should be considered general lines of operating. It is quite essential to follow the manufacturer’s instructions and regulations as regards safety. Operating the machine is very simple. The checks that the operator obtains good coffee are: use suitably softened fresh mains water boiler water temperature between 85 °C and 105°C...

  • Page 13: How To Make Espresso Coffee

    User instructions Crema Compact och Digital 8.2 How to make espresso coffee Remove the filterholder from the group and dispose of the grounds by hitting the edge of the filterholder against the bar in the apposite drawer. Do not hit the filterholder against an unprotected surface; the filterholder’s seal could be demaged.

  • Page 14: Daily Cleaning

    Maintenance Crema Compact och Digital 9.1 Daily cleaning Preferably done in the evening: - CLEAN nozzles, gasket, filterholder and the bayonets in groups. Use a clean dishing brush or the angled cleaning brush. - RINSE 1 cup filter / 2 cup filter and filterholders with hot water. Use detergent intended for coffee machines or dishing machines to remove oil and dirt - Put the rubber pad in 2 cup filter.

  • Page 15: Instructions For Regenerating Descaling Filter

    Maintenance Crema Compact och Digital 9.4 Instructions for regenerating descaling filter The instructions given below should be followed to regenerate the descaling filter: Place a container with a capacity of at least 2 litres under pipe E. Move levers C och D from left to right.

  • Page 16: Faults And Routine Repairs

    10. Faults and routine repairs Crema Compact och Digital Identifying problems: - Always ensure that there is enough ground coffee for at least one dose in the grinder-doser´s reservoir. - If the coffee drops are to slowly then grinding is propably too fine. Vice-versa, if it drops to fast, the grinding is too coarse.
  • Page 17 10. Faults and routine repairs Crema Compact och Digital Fault: Problem: The water level control provides water when it should not. Cause 1: The level sensor/control centre electrical connection is broken. Cures: Repair. Cause 2: The frame earthing/control centre electrical connection is broken.
  • Page 18 10. Faults and routine repairs Crema Compact och Digital Fault: Problem: Machine is only brewing while the heating element is charged. Cause 1: Neutral conductor is missing. (electric delivery). Cures: Check and cure. Problem: Regulary dosage when machine is brewing is faulty. (only version with dosage).

  • Page 19: Shut-Down And Dismantling

    10. Faults and routine repairs Crema Compact och Digital Fault: Problem: Leakage between group and filterholder when machine is brewing. Cause 1: Brew groups filter spring are worn out. Cures: Replace it. Cause 2: 1 cup filter/2 cup filter is damaged.

  • Page 20: Technical Data

    12. Technical Data Crema Compact och Crema Digital 2-4 groups Crema Compact Crema Digital2 group Crema Digital 3 group Crema Digital 4 group Model Group Tankage (L) Voltage V-Hz Capacity (W) Current consumption(A) Crema Compact 240V1N - 50/60Hz 2670 11,1...

  • Page 21: Spare Part List

    13. Spare part list Crema Compact och Digital Description: Art.no. Pos.no Comp2 Comp2TA Dig2TA Dig3TA Dig4TA Plug C 30200035 Gasket, plug C 50010040 Tubular filter(Trumpet jet) C 70000009 Plate,teflon (Trumpet jet) C 50030000 Trumpet jet, teflon C 30200060 Jet support, teflon...
  • Page 22 13. Spare part list Crema Compact och Digital Benämning: Artnr. Pos.nr Dig4TA Comp2 Comp2TA Dig2TA Dig3TA Filter support C 70000001 Pump Raccord 3/8x3/8 C 30000240 Inox flexible tube hose 180cm C 35900180 Inox flexible tube hose 55 cm C 35900040...

  • Page 23: Exploded View

    14. Exploded view Brewing / Filter holder Crema...
  • Page 24 14. Exploded view Steam / Hot water knob Crema...
  • Page 25 14. Exploded view Motor pump Crema...
  • Page 26 14. Exploded view Crema Compact Heat exchanger...
  • Page 27 1 4 . Exploded view Crema...

  • Page 28: Flow Diagram (Comp Machines)

    15. Flow diagram Ångkran-sats / Steam tap set Hetvattenkran-sats / Water tap set Bryggrupp / Brewing unit set Motorpump / Motor-pump set Vattenpåfyllnadssats / Charging/loading/inlet & draining set Avkalkningsfilter / Water softener 30. Pressostat - 3 fas / Three phase presostat (pressurestat/pressure switch) 31.

  • Page 29: Flow Diagram (Dig Machines)

    15. Flow diagram 17. Doserturbin / Flowmeter 18. Värmeelement / Heating element 20. Tank, 2 grupps / 2 groups boiler 22. Pressostat 3 fas / Three phase presostat (pressurestat/pressure switch) 28. Nivåsensor / Probe (level probe) 30. Övertrycksventil / Safety valve CN 10 32.

  • Page 30: Electrical Diagram

    16. Electrical diagram...
  • Page 31 Your retail dealer ................................................COFFEE QUEEN AB Box 960, 67129 ARVIKA besöksadress; korpralsv. 1B, Tel vxl; +46 (0)570-477 00, service +46 (0)570-477 30, lager +46 (0)570 477 20, Fax; +46 (0)570 477 19 E-mail: info@coffeequeen.se www.coffeequeen.se Art. nr/Art. 170436...
