Ergotron PowerShuttle Assembly Instructions Manual page 7

6
Insert the laptop/tablet dividers in the top compartment.
Push each divider down into place, then slide forward until it locks in place. The
dividers will hold power cables in their channels.
LEFT = 1
7
Lower the cable routing tray by
removing the thumb screws.
888-24-280-W-00 rev. A • 03/14
NOTE: there are three divider styles, one for the right end
of the compartment, one for the left end and seven for the
middle area.
MIDDLE = 7
NOTE: to remove dividers, press release tabs in back of
divider and push divider back.
RIGHT = 1
7 of 13
