Product Guide ineo 1051/1200
SD-506 Booklet Making Unit
Type
Configuration
Other specifications
Power supply
Power Consumption
Dimensions
Weight
Functionality
Processing speed
Booklet functionality
Media size
Media weight
Staple page
Staple position
Staple type
Tray capacity
Saddle stitch/fold and staple device
2 output trays
Modes: Staple
Straight, Shift, Sub-tray output
Consumables: Staple needles (1 cartridge, 5000 needles)
Internal
5V (supplied by Main engine)
270VA
(WxHxD) 1170 x 1020 x 775 mm (Booklet tray retracted)
Width when Booklet tray extended: 1441 mm
280 kg
Sub-tray mode: no finishing, output to sub-tray
Saddle stitch mode: Center fold +saddle stitch, output to Booklet tray
Saddle stitch+Trim mode: Center fold +saddle stitch + trim, output to Booklet
tray
Multi center fold mode:
Multi letter fold mode:
tray
Through pass mode:
+
105 ppm (ineo 1200 configurations need the RU-506)
A3, B4, A4, A4S, B5S, A5, SRA3, SRA4S,
Foolscap (8"x13"), (8-1/4"x13"), (8-1/2"x13"), (8-1/8"x13-1/4"),
12"x18", Ledger (11"x17"), Legal (8-1/2"x14"),
Letter (8-1/2"x11")S, Executive (7-1/4"x10-1/2")S,
8K, 16KS,
ISOB4,
Free paper, Wide paper
Min: 182 x 257 mm / Max: 324 x 463 mm
50 to 244 g/m²
50 – 81 g/m²: 50 sheets / 49 sheets + 1 sheet (200 g/m²)
82 – 91 g/m²: 30 sheets / 29 sheets + 1 sheet (200 g/m²)
92 –130 g/m²: 20 sheets / 19 sheets + 1 sheet (200 g/m²)
131 -161 g/m²: 15 sheets / 14 sheets + 1 sheet (200 g/m²)
162 -209 g/m²: 10 sheets
210 -244 g/m²: 5 sheets
(Values not valid for High Quality paper, Coated paper, and Long grain paper.)
changeable (90 to 165 mm)
Inline clinch
2 to 10 stapled sheets:
11 to 20 stapled sheets:
21 to 30 stapled sheets:
31 to 40 stapled sheets:
41 to 50 stapled sheets:
(Long grain paper not specified.)
21
Center fold of multiple sheets, output to Booklet tray
Letter fold of multiple sheets, output to Letter fold
50 sets or more
30 sets or more
20 sets or more
20 sets or more
15 sets or more
