ACCURACY
Volumetric fl ow
±1% of reading accuracy (±2% for ¾" & smaller sizes)
Mass fl ow
±1.5% of reading accuracy (±2.5% for ¾" & smaller sizes)

OPERATING TEMPERATURE RANGE

Media temperature
25° to 464° F
Ambient temperature
0° to 132° F
DISPLAY / USER INTERFACE
16x64 dot matrix LCD with 3 button keypad and magnetic pin programming

OUTPUT SIGNALS

Rate: 4-20mA, loop-powered
Supply voltage range: 14-36 VDC
Minimum load resistance: 100 ohms
Maximum load resistance is calculated as follows:
Max load = Vs – 12V
Total: Scaled output pulse, programmable
Optically isolated open collector, 0.5 hz maximum
Rating: 5-36 VDC, 100mA maximum
SUPPLY VOLTAGE:
14-36 VDC

PROCESS CONNECTIONS:

Standard: ANSI #300 fl anges
Optional: ANSI #600 fl anges
APPROVALS
Safety: Conforms to CE mark as per LVD, PED and EMC Directive
Enclosure: Conforms to IP 65 and IP 67
F-2200 Series Vortex Flow Meter Installation and Operation Guide • Revised 12/08
Where Vs = supply voltage
