- Page 1 WSP-CP MODEL (2,3inch Panel Printer) Rev. 3.0 WOOSIM SYSTEMS Inc. #501, Daerung Technotown 3th, 448, Gasan-Dong, GeumChun-Ku, Seoul, Korea Tel : +82-2-2107-3700 Fax : +82-2-2107-3707 URL: http://www.woosim.com All specifications are subjected to change without notice http://www.woosim.com...
- Page 2 And may not be reproduced in whole or in part without the prior written permission of Woosim Systems Inc. Trademark a registered trademark of Woosim Systems Inc. All other trademark are the properties of their respective companies. Caution Some semiconductor devices are easily damaged by static electricity. You should turn the printer “OFF”, before you connect or removed the cable on...
- Page 3 One touch paper cover In field programming – Update Firmware, Download Fonts and Logos Microsoft Windows XP / VISTA / 7 / CE / Linux / Android compatible. Flow control : Software (XON/XOFF) ※ Hardware flow control not supported in printer. http://www.woosim.com 2012-02-02...
- Page 4 Do not allow plastic film, erasers, or adhesive tape to touch the paper for long periods. ● Do not stack the thermal paper with diazo copies immediately after copying or wet-type copies. ● Do not use chemical glue. ● Always use the clean thermal paper. http://www.woosim.com 2012-02-02...
-
Page 5: Table Of Contents
3.2. USB ............................19 4. Using the printer ........................20 4.1. Control panel ........................20 4.2. The self test .......................... 21 5. Consumable Parts ........................22 5.1. Recommended paper......................22 5.2 Printing position ........................23 6. Revision History ........................24 http://www.woosim.com 2012-02-02... -
Page 6: Outline
None : 24VDC, 3A 1.2. Product Part Number System Model name Interface Spec. Wired Wireless RS-232C Bluetooth SC30 IrDA None RS-485 Parallel None Example) 1. Porti-S40 Serial/Bluetooth Part No. ⇒ S40/A1 2. Porti-SC30 Bluetooth Only Part No. ⇒ SC30/Z1 http://www.woosim.com 2012-02-02... -
Page 7: Specifications
MCU : 32bits RISC, FLASH : 4Mbytes, RAM : 8Mbytes Receive buffer size 1M bytes Paper cutting Slide cutting method Type of paper Full cut and Partial cut(1.5±0.5mm tab left at the center) cutting Input Power 24VDC, 3A Over http://www.woosim.com 2012-02-02... - Page 8 30% - 85% (operating) Activation pulse 100 million pulses or more resistance Life span Abrasion 100km or more (excluding damage caused by (at 25℃ and rated resistance dust and foreign materials) energy) Paper cutting 700,000 cuts or more resistance http://www.woosim.com 2012-02-02...
-
Page 9: Setting Up The Printer
WSP-CP Rev. 3.0 2.1. Printer & Accessories Your printer box should include these items. If any items are damaged or missing, please contact your dealer for assistance. WSP-CP260 WSP-CP280 WSP-CP360 WSP-CP380 Screw M2x5PH Thermal roll paper Bracket (2EA) http://www.woosim.com 2012-02-02... -
Page 10: Printer Features
WSP-CP Rev. 3.0 2.2. Printer Features http://www.woosim.com 2012-02-02... -
Page 11: Dimension
WSP-CP Rev. 3.0 2.3. Dimension CP260 CP280 http://www.woosim.com 2012-02-02... - Page 12 WSP-CP Rev. 3.0 CP360 CP380 http://www.woosim.com 2012-02-02...
-
Page 13: Panel Installation Ⅰ
WSP-CP Rev. 3.0 2.3. Panel Installation Ⅰ http://www.woosim.com 2012-02-02... -
Page 14: Panel Installation Ⅱ
WSP-CP Rev. 3.0 2.3. Panel Installation Ⅱ Uses BRACKET and fixes, like the picture of difficult case lower part and will be able to fix with SCREW. http://www.woosim.com 2012-02-02... - Page 15 WSP-CP Rev. 3.0 http://www.woosim.com 2012-02-02...
-
Page 16: Replacing Paper Roll
2. Open the paper cover as the “One-Touch” way by pressing the button in the arrow direction like the picture 3. Insert a new paper roll as shown. 4. Tear the excess paper off using the edge of paper door as a tear bar. http://www.woosim.com 2012-02-02... -
Page 17: Specified Power Supply
WSP-CP Rev. 3.0 2.5. Specified power supply The following specifications are requested for power supply. Input : DC 24V / Max 3A Avoid using power supply which its power capacity of power current is extremely high. http://www.woosim.com 2012-02-02... -
Page 18: Interface
Direction Function INPUT 24VDC/3A INPUT 24VDC/3A Output Transmit Data Input Receive Data Ground Ground <J2 : MOLEX (5267-06P)> Mates with : MOLEX 5264-06P or equivalent. WARNING A wrong connection of power supply connector could be damage the printer http://www.woosim.com 2012-02-02... -
Page 19: Usb
Function INPUT 24VDC/3A INPUT 24VDC/3A USB_VCC 5VDC Data “+” Data “-” Ground Ground Ground <J2 : MOLEX (53014-0810)> Mates with : MOLEX 51004-0800 or equivalent. WARNING A wrong connection of power supply connector could be damage the printer http://www.woosim.com 2012-02-02... -
Page 20: Using The Printer
At the time of the reel which will know the shift time of the paper POWER LAMP blinks. - Error (Red) : Indicates a fault condition or a printer error. (i.e : no paper, paper cover opened. etc.) http://www.woosim.com 2012-02-02... -
Page 21: The Self Test
ROM version and the communication method setting. 3) After printing the current printer status, Self-Test will print a pattern using the built-in character set. 4) The Self-Test automatically ends. The printer is ready to receive data as soon as it complete the Self-Test. http://www.woosim.com 2012-02-02... -
Page 22: Consumable Parts
2. Chemicals or oil may change the color of paper, or printed characters may fade. 3. Change of paper color starts from approx . 70℃. Pay attention to heat, humidity and sun light. 4. Color of paper may be changed by being scratched by nail or hard metal, etc. http://www.woosim.com 2012-02-02... -
Page 23: Printing Position
WSP-CP Rev. 3.0 5.2 Printing position 2Inch 3Inch http://www.woosim.com 2012-02-02... -
Page 24: Revision History
WSP-CP Rev. 3.0 Date Version Comments Revision History Initial Release Dec. 20. 2010 Product weight revision P13 2.3. Panel Installation Ⅰ Nov. 03. 2011 (CP380 dimension correction) http://www.woosim.com 2012-02-02...
