At this point, you should have an excel file with three different sheets.
Each sheet corresponds to a different view of the same data:
The first one will show you the generic signal information and the
different coverage measures for each point acquired.
In the second one, you will find the same data but presented in a
table format, more user friendly for working with graphs based on
each measured parameter.
The third one provides data in a format adapted for geolocation. This
is available only for users with GPS option (refer to annex
OP-001-GPS).
Now save the data as a true excel file. No specific name or path is
required, but you must remember the path.
7.8

Datalogger

7.8.1

Description

The Datalogger function stores automatically measurements in a file set by the
user (name, channel plan), and associated to a specific installation. User can
store for each datalogger measurements taken at different test points of the
selected installation. Measurements are made for all channels in the active
channel plan, both analogue and digital.
7.8.2

Operation

To create a new datalogger:
First select one installation of the list of installations
pressing the "Load" key
and DiSEqC commands selected by the user and it stores dataloggers
and screenshots made while it is selected (more information in chapter
"Installations management").
Check the installation is selected. The name of the installation should
appear on the upper left corner of the screen.
Press the
Press on the "Datalogger" option.
7-102
. An installation contains the channel plans
: Tools key.
and load it
November 2014
