Summary of Contents for Contec IPC-BX701 Series

  • Page 1 IPC Series BOX-PC for IPC-BX701 Series User’s Manual CONTEC CO.,LTD.
  • Page 2 1 *2, *4 Windows XP Embedded Notes Please confirm latest information on the CONTEC homepage though the user's manual is stored in IPC-SLIB-01. It is not packed to the Windows XP Professional pre-install model. It is not packed to the Windows XP Embedded pre-install model.

  • Page 3: Copyright

    No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this document.

  • Page 4: Table Of Contents

    Table of Contents Check Your Package ..........................i Copyright..............................ii Trademarks .............................. ii Table of Contents ........................... iii INTRODUCTION About the Product............................ 1 Features ............................1 Supported OS ........................... 2 Customer Support............................ 3 Web Site ............................3 Limited One-Year Warranty ........................3 How to Obtain Service ..........................
  • Page 5 BIOS SETUP BIOS Setup............................29 Starting the Setup Screen ....................... 29 Main Menu ............................. 32 Standard CMOS Features....................... 33 Advanced BIOS Features....................... 35 Advanced Chipset Features......................39 Integrated Peripherals........................41 OnChip IDE Device ........................42 Onboard Device..........................43 SuperIO Device ..........................45 Power Management Setup ......................
  • Page 6 Expansion Slots (P2 and P4 model)....................82 LED: POWER, ACCESS, STATUS ..................... 83 Watch-Dog-Timer .......................... 86 APPENDIX Memory Map ............................91 I/O Port Addresses..........................92 Interrupt Level List..........................93 List of Options............................94 Difference from IPC-BX700 series....................... 96 User’s Manual...
  • Page 7 User’s Manual...

  • Page 8: Introduction

    CF card disconnection. Retention of CMOS data by EEPROM allows the system to start up even when the battery has run out. In addition, the use of a CONTEC-customized BIOS (by Award) allows support to be provided at the BIOS level. User’s Manual...

  • Page 9: Supported Os

    1. Introduction Structure free from mechanical moving parts (Windows XP Embedded pre-installed model) The use of a silicon disk for the storage device has eliminated any moving parts, improving the levels of the environment resistance (ambient temperature, impact, vibration), reliability and quietness. Expansion slots to hold PCI / ISA bus boards (Model with Expansion Slot).

  • Page 10: Customer Support

    You can download updated driver software and differential files as well as sample programs available in several languages. Note! For product information Contact your retailer if you have any technical question about a CONTEC product or need its price, delivery time, or estimate information. Limited One-Year Warranty CONTEC products are warranted by CONTEC CO., LTD.

  • Page 11: Safety Precautions

    1. Introduction Safety Precautions Understand the following definitions and precautions to use the product safely. Safety Information This document provides safety information using the following symbols to prevent accidents resulting in injury or death and the destruction of equipment and resources. Understand the meanings of these labels to operate the equipment safely.
  • Page 12 Hard disks have a limited life span. Please perform systematic backup and maintenance. CONTEC does not provide any guarantee for the integrity of data on hard disks. To prevent corruption of files, always shutdown the OS before turning off the BOX-PC.

  • Page 13: Fcc Part 15 Class A Notice

    1. Introduction FCC PART 15 Class A Notice NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in commercial environment.

  • Page 14: System Reference

    2. System Reference 2. System Reference Specifications Table 2.1. Functional Specifications < 1 / 2 > Model IPC-BX701-AC IPC-BX701P2-AC IPC-BX701P4-AC Ultra Low Voltage Intel(R) Celeron(R)M Processor 1.0GHz, FSB400MHz Chip set Intel(R) 855GME Memory L2 Cache 512KB Main memory 1GB (2.5V 184pin DDR SDRAM PC2700 DIMM Socket x 1) BIOS ROM 128KB E0000H - FFFFFH (Award) Video...
  • Page 15 2. System Reference Table 2.1. Functional Specifications < 2 / 2 > Model IPC-BX701-AC IPC-BX701P2-AC IPC-BX701P4-AC Watch dog timer Software programmable, 255 level (1sec - 255 sec) Causes a reset upon time-out. Expansion board slot None Shared PCI/ISA slot x 2, Shared PCI/ISA slot x 2, Installable board length PCI slot x 2...
  • Page 16 2. System Reference Table 2.2. Installation Environment Requirements Parameter Requirement description Allowable instantaneous Less than 20ms Power supply power outage One minute each for AC2.0kV (input - FG) 20mA specifications Dielectric strength 50MΩ (500VDC) 0 - 50°C (SDD in use *1), Operating temperature 5 - 45°C (HDD in use) Storage temperature...

  • Page 17: System Configuration

    2. System Reference System Configuration Expansion slot When three or more slots are needed, select (P2 and P4 models) the P4 model. To use five or more slots or a full-size board, connect the expansion unit. PC-HELPER Expansion Series bus adapter PCI, ISA Half-size board Expansion chassis...

  • Page 18: Physical Dimensions

    2. System Reference Physical Dimensions IPC-BX701-AC 4-φ5 2-R2.5 R5.5 LAN2 P - IDE LINE IN LAN1 1000/100/10 100/10 LVDS LINE OUT POWER KB/MS ACCESS SERIAL3 SERIAL4 STATUS [mm] RESET SERI AL1 SERIAL2 Figure 2.2. IPC-BX701-AC User’s Manual...
  • Page 19 2. System Reference IPC-BX701P2-AC 4-f5 4-φ5 2-R2.5 R5.5 LAN2 P - IDE LINE IN LAN1 1000/100/10 100/10 LVDS LINE OUT POW ER KB/MS A CCESS SERIAL3 SERIAL4 STATUS [mm] RESET SERIAL1 SERIAL2 Figure 2.3. IPC-BX701P2-AC User’s Manual...
  • Page 20 2. System Reference IPC-BX701P4-AC 4-φ5 2-R2.5 R5.5 LAN2 P - IDE LINE IN LAN1 1000/100/10 100/10 LVDS LINE OUT POWER [mm] KB/MS ACCESS SERIAL3 SERIAL4 STATUS RESET SERIAL1 SERIAL2 Figure 2.4. IPC-BX701P4-AC User’s Manual...
  • Page 21 2. System Reference User’s Manual...

  • Page 22: Hardware Setup

    3. Hardware Setup 3. Hardware Setup Before Using the BOX-PC for the First Time Follow the next steps to set up the BOX-PC: STEP1 Install the hard disk and set jumper switches. By referring to the information in this chapter, set the BOX-PC. STEP2 Connect cables.

  • Page 23: Hardware Setup

    3. Hardware Setup Hardware Setup Before you start, be sure that the power is turned off. Remove only those screws that are explained. Do not move any other screw. Locations and settings of Jumpers (1) Remove the top cover. Figure 3.1. Removing the Top Cover When you remove the top cover and hard disk bracket, the connectors, jumpers, and switches are laid out as shown in the figure below: JBAT1...

  • Page 24: Installing The Hard Disk

    3. Hardware Setup Installing the Hard Disk (1) Remove the hard disk bracket from this product. Figure 3.3. Removing the Hard Disk Bracket (2) Remove the part of socket from the hard disk bracket. Figure 3.4. Removing the Hard Disk Socket (3) Peel the protective film off the thermal conduction sheet, and install the hard disk (silicon disk) to the hard disk bracket.
  • Page 25 3. Hardware Setup (4) Install the part of socket to the hard disk bracket. Plug the HDD into the socket first, then fasten it with two screws. Figure 3.6. Installing the Hard Disk to the Socket CAUTION Connect the HDD cable in alignment with pins from the left end of the connector on the HDD side. Four master/slave setting pins are left unconnected on the right side.

  • Page 26: Attaching The Cf Card Retaining Bracket

    3. Hardware Setup Attaching the CF Card Retaining Bracket (1) After inserting a CF Card, fasten the bundled CF Card retaining bracket with a screw. Figure 3.8. Attaching the CF Card Retaining Bracket CAUTION Insert the CF Card face up. Figure 3.9.

  • Page 27: Pci Board Installation Procedure

    3. Hardware Setup PCI Board Installation Procedure IPC-BX701P2-AC (1) Be sure the power is turned off. (2) Remove the top cover. Figure 3.10. Removing the Top Cover (3) Remove the brace that holds the printed circuit board (PCB) down. Remove the screws on the brace. The brace will separate toward you. Figure 3.11.
  • Page 28 3. Hardware Setup (4) Insert the board into the slot and fasten it with screws. Figure 3.12. Installation of an Expansion Board CAUTION Make sure carefully that the board has been secured in the slot. (5) Install the PCB brace. It can hold down a board if its height is at least 68mm. For an ISA board, attach the PCB brace with the retaining brackets...
  • Page 29 3. Hardware Setup (6) Replace the expansion slot cover. Figure 3.14. Replacing the Top Cover User’s Manual...
  • Page 30 3. Hardware Setup IPC-BX701P4-AC (1) Be sure the power is turned off. (2) Remove the top cover. Figure 3.15. Removing the Top Cover (3) Remove the brace that holds the printed circuit board (PCB) down. Remove the screws on the brace. The brace will separate toward you. Figure 3.16.
  • Page 31 3. Hardware Setup (4) Insert the board into the slot and fasten it with screws. Figure 3.17. Installation of an Expansion Board CAUTION Make sure carefully that the board has been secured in the slot. (5) Install the PCB brace. It can hold down a board if its height is at least 68mm. For an ISA board, attach the PCB brace with the retaining brackets...
  • Page 32 3. Hardware Setup (6) Replace the expansion slot cover. Figure 3.19. Replacing the Top Cover User’s Manual...

  • Page 33: Fastening The Cable

    3. Hardware Setup Fastening the Cable The “Cable fixed clamp” is bundled with this product. Fastening the AC Cable (1) The system unit has four holes for accepting cable ties. Using a cable clamp for a cable with lock-less connector, such as the AC cable or USB cable, prevents the connector from being unplugged. Use the cable ties and cable clamps appropriately according to the connecting states and wiring directions of cables.

  • Page 34: Installation Requirements

    3. Hardware Setup Installation Requirements The BOX-PC can be installed in any orientation (1) - (3). Avoid orientation (4) - (6) since it might not adequately dissipate heat. In addition, take appropriate measures so that the ambient temperature falls within the range of installation environment conditions, such as keeping the system unit well-ventilated and sufficiently spaced its surroundings.
  • Page 35 3. Hardware Setup Distances between the BOX-PC and Its Vicinity 50mm or more (side) 50mm or more (side) 100mm or more (above) LAN2 P - IDE LINE IN LAN1 1000/100/10 100/10 LVDS LINE OUT POWER KB/MS ACCESS SERIAL3 SERIAL4 STAT US RESET SERIAL1 SERIAL2...

  • Page 36: Bios Setup

    4. BIOS Setup 4. BIOS Setup BIOS Setup BIOS setup sets various settings during startup. When using the system for the first time, be sure to run BIOS setup. Once set up, the specified details will be backed up. Starting the Setup Screen When you turn on the system power supply, the BOX-PC displays the following initial screen as long as the system is normal.
  • Page 37 4. BIOS Setup Using Setup In general, you use the arrow keys to highlight items, press <Enter> to select, use the <PageUp> and <PageDown> keys to change entries, press <F1> for help and press <Esc> to quit. Table 4.1. Using Setup program Function Up Arrow Move to the previous item...
  • Page 38 4. BIOS Setup Note on the setup Information in this chapter is subject to change without notice. Phoenix - Award BIOS CMOS Setup Utility Frequency/Voltage Control Standard CMOS Features Load Fail-Safe Defaults Advanced BIOS Features Load Optimized Defaults Advanced Chipset Features Set Supervisor Password Integrated Peripherals Set User Password...

  • Page 39: Main Menu

    4. BIOS Setup Main Menu Once you enter the Award BIOS CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from several setup functions and two exit choices. Use the arrow keys to select among the items and press <Enter>...

  • Page 40: Standard Cmos Features

    4. BIOS Setup Supervisor / User Password Use these menu items to specify passwords for BIOS Setup. You can set up all the BIOS setup items in supervisor mode but not in user mode. CAUTION Once a password is registered, even the password function itself cannot be cancelled without the password.
  • Page 41 4. BIOS Setup Selection from the Standard CMOS Setup This table shows the selections that you can make on the Standard CMOS Setup. Table 4.2. Selecting item of the Standard CMOS Setup Item Option Description Date Month DD YYYY Sets the date on the equipment calendar clock. Note that the ‘Day’...

  • Page 42: Advanced Bios Features

    4. BIOS Setup Advanced BIOS Features This section allows you to configure your system for basic operation. Phoenix - Award BIOS CMOS Setup Utility Advanced BIOS Features [Disabled] Item Help Virus Warning [Enabled] CPU L1 & L2 Cache [Enabled] Quick Power On Self Test Menu Level [USE-FDD] First Boot Device...
  • Page 43 4. BIOS Setup Selection from the Advanced BIOS Features This table shows the selections that you can make on the Advanced BIOS Features. Table 4.3. Selecting item of the Advanced BIOS Features < 1 / 2 > Item Option Description Virus Warning Enabled If you enable this feature, a warning message is displayed when a...
  • Page 44 4. BIOS Setup Table 4.3. Selecting item of the Advanced BIOS Features < 2 / 2 > Item Option Description Gate A20 refers to the way the system addresses memory above 1 MB (extended memory). When set to Fast, the system chipset Normal Gate A20 option controls Gate A20.
  • Page 45 4. BIOS Setup If a warning message appears, run an antivirus program. This feature protects only the boot sector. Note that the feature does not protect the entire hard disk drive. A virus warning message may be displayed in response to various diagnostic and installation programs which access the boot sector table.

  • Page 46: Advanced Chipset Features

    4. BIOS Setup Advanced Chipset Features Use this menu to set up some features of the chipset. Phoenix - Award BIOS CMOS Setup Utility Advanced Chipset Features DRAM Timing Selectable [By SPD] Item Help CAS Latency Time Active to Precharge Delay DRAM RAS# to CAS# Delay Menu Level DRAM RAS# Precharge...
  • Page 47 4. BIOS Setup Table 4.4. Selecting item of the Advanced Chipset Features < 2 / 3 > Item Option Description This item is disabled with "DRAM Timing Selectable" set to "BySPD." You usually do not DRAM RAS# Precharge have to change this setting. Displays the detected type of memory installed DRAM Data Integrity Non-ECC...

  • Page 48: Integrated Peripherals

    4. BIOS Setup Table 4.4. Selecting item of the Advanced Chipset Features < 3 / 3 > Item Option Description 640 x 480 Select the LVDS panel device resolution. 800 x 600 Panel Number 1024 x 768 Use DDC data selection for VGA (analog RGB). Disabled Display data is loaded from internal DDC ROM Internal DDC ROM...

  • Page 49: Onchip Ide Device

    4. BIOS Setup OnChip IDE Device This submenu is used to set up the features of IDE devices. Phoenix - Award BIOS CMOS Setup Utility OnChip IDE Device Item Help On-Chip Primary PCI IDE [Enabled] Menu Level IDE Primary Master PIO [Auto] IDE Primary Slave PIO [Auto]...

  • Page 50: Onboard Device

    4. BIOS Setup Table 4.5. Selecting item of the Onchip IDE Device < 2 / 2 > Item Option Description On-Chip Secondary PCI Disabled The integrated peripheral controller contains Enabled an IDE interface with support for two IDE channels. Select Enabled to activate each channel separately.
  • Page 51 4. BIOS Setup Selection from the Onboard Device This table shows the selections that you can make on the Onboard Device. Table 4.6. Selecting item of the Onboard Device Item Option Description Disabled USB Controller Enable or disable the USB port. Enabled Enable or disable the use of the USB ports for Disabled...

  • Page 52: Superio Device

    4. BIOS Setup SuperIO Device This submenu is used to set up the features of SuperIO devices. Phoenix - Award BIOS CMOS Setup Utility Super IO Device Item Help Onboard Serial Port 1 [3F8/IRQ4] Onboard Serial Port 2 [2F8/IRQ3] Onboard Parallel Port [Disabled] Menu Level Parallel Port Mode...
  • Page 53 4. BIOS Setup Selection from the SuperIO Device This table shows the selections that you can make on the SuperIO Device. Table 4.7. Selecting item of the Super IO Device Item Option Description Select the base I/O address and IRQ for serial port Disabled 3F8/IRQ4 - Selecting "3F8/IRQ4"...

  • Page 54: Power Management Setup

    4. BIOS Setup Power Management Setup Phoenix - Award BIOS CMOS Setup Utility Power Management Setup Item Help Power-Supply Type [ATX] ACPI Function [Enabled] Power Management [User Define] Menu Level Video Off In Suspend [Yes] Suspend Mode [Disabled] HDD Power Down [Disabled] Soft-Off by PWR-BTTN [Instant-Off]...
  • Page 55 4. BIOS Setup Selection from the Power Management Setup This table shows the selections that you can make on the Power Management Setup. Table 4.8. Selecting item of the Power Management Setup Item Option Description Power-Supply Type Select the power supply type. ACPI Function Enabled Select to Enabled the ACPI function and select...

  • Page 56: Pnp/Pci Configurations Setup

    4. BIOS Setup PnP/PCI Configurations Setup Phoenix - Award BIOS CMOS Setup Utility PnP/PCI Configurations Item Help PNP OS Installed [No] Reset Configuration Data [Disabled] Menu Level Resources Controlled By [Auto(ESCD)] IRQ Resources Press Enter Select Yes if you are DMA Resources Pres Enter using a Plug and Play...
  • Page 57 4. BIOS Setup Selection from the PnP/PCI Configurations Setup This table shows the selections that you can make on the PnP/PCI Configurations Setup. Table 4.9. Selecting item of the PnP/PCI Configurations Setup Item Option Description PNP OS Installed Selecting [Yes] causes a Plug-and-Play OS to automatically allocate resources.
  • Page 58 4. BIOS Setup IRQ Resources Phoenix - Award BIOS CMOS Setup Utility IRQ Resources Item Help IRQ-3 assigned to [PCI/ISA PnP] IRQ-4 assigned to [PCI/ISA PnP] IRQ-5 assigned to [PCI/ISA PnP] Menu Level IRQ-7 assigned to [PCI/ISA PnP] IRQ-9 assigned to [PCI/ISA PnP] Legacy ISA for devices IRQ-10 assigned to...
  • Page 59 4. BIOS Setup DMA Resources Phoenix - Award BIOS CMOS Setup Utility DMA Resources Item Help DMA-0 assinged to [PCI/ISA PnP] DMA-1 assinged to [PCI/ISA PnP] DMA-3 assinged to [PCI/ISA PnP] Menu Level DMA-5 assinged to [PCI/ISA PnP] DMA-6 assinged to [PCI/ISA PnP] Legacy ISA for devices DMA-7 assinged to...

  • Page 60: Pc Health Status Setup

    4. BIOS Setup PC Health Status Setup Phoenix - Award BIOS CMOS Setup Utility PC Health Status Item Help Delay Prior to Thermal [16 Min] CPU Temperature Function [Disabled] Warning BEEP Disabled Menu Level THRM-Throttling Disabled CPU THRM-Throttling 50.0% Current System Temp. 31°C/ 87°F Current System Temp.
  • Page 61 4. BIOS Setup Table 4.10. Selecting item of the PC Health Status Setup < 2 / 2 > Item Option Description CPU Temperature Disabled If the CPU temperature reaches the set value, the Function 50°C/122°F system beeps or activates the throttling function. 53°C/127°F 56°C/133°F 60°C/140°F...

  • Page 62: Frequency/Voltage Control

    4. BIOS Setup Frequency/Voltage Control Phoenix - Award BIOS CMOS Setup Utility Frequency/Voltage Control Item Help Spread Spectrum [Enabled] Menu Level ↓ →← : Move Enter : Select +/-/PU/PD : Value F10 : Save ESC : Exit F1 : General Help F5 : Previous Values F6 : Fail-Safe Defaults F7 : Optimized Deefaults Figure 4.15.

  • Page 63: Supervisor/User Password Setting

    4. BIOS Setup Supervisor/User Password Setting You can set either supervisor or user password, or both of then. The differences between are: SUPERVISOR PASSWORD: can enter and change the options of the setup menus. USER PASSWORD: just can only enter but do not have the right to change the options of the setup menus. When you select this function, the following message will appear at the center of the screen to assist you in creating a password.

  • Page 64: Exit Without Saving

    4. BIOS Setup Exit Without Saving Pressing <Enter> on this item asks for confirmation: Quit Without Saving (Y/N)? N Pressing the <Y> key quits Setup without saving the changes made on the Setup screen to CMOS (EEPROM). Quitting Setup without saving leaves the last saved settings in effect, with which the system is rebooted after that.

  • Page 65: Error Messages

    4. BIOS Setup Error Messages One or more of the following messages may be displayed if the BIOS detects an error during the POST. DISK BOOT failure [INSERT SYSTEM DISK AND PRESS ENTER] No boot device was found. This message appears, for example, when the BIOS cannot find any drive from which to boot the system.
  • Page 66 4. BIOS Setup Keyboard is locked out – Unlock the key A key remains held down during a system boot. Check that the keyboard is connected correctly and that no key is pressed during a system boot. Memory address error at… Memory parity error at…...
  • Page 67 4. BIOS Setup User’s Manual...

  • Page 68: Each Component Function

    5. Each Component Function 5. Each Component Function Component Name IPC-BX701-AC TOP COVER LAN1 SERIAL3 LVDS SERIAL4 P-IDE RESET (100BASE-TX) LAN2 POWER SW (1000BASE-T) LAN2 P - IDE LINE IN LAN1 1000/100/10 LINE IN 100/10 POWER LED LVDS LINE OUT LINE OUT POWER ACCESS LED...
  • Page 69 5. Each Component Function Side view IPC-BX701-AC IPC-BX701P2-AC Secondary IDE power supply connector Secondary IDE connector IPC-BX701P4-AC Secondary IDE connector Secondary IDE power supply connector Figure 5.1. Component Name < 2 / 2 > User’s Manual...
  • Page 70 5. Each Component Function Table 5.1. Component Function Name Function POWER SW Power switch AC INLET AC power input connector Line in ( φ 3.5 PHONE JACK) LINE IN LINE OUT Line out ( φ 3.5 PHONE JACK) Mike in ( φ 3.5 PHONE JACK) LAN1 Ethernet 100BASE-TX/10BASE-T RJ-45 connector LAN2...

  • Page 71: Component Function

    The audio driver is required to use the line input, line output, and microphone input interfaces. Install the appropriate audio driver for your OS from the bundled CD-ROM [IPC-SLIB-01]. (For information on the latest version of IPC-SLIB-01, check the CONTEC's web site.) User’s Manual...

  • Page 72: Fast-Ethernet : Lan1

    Right LED: Link / Operation LED Normal connection: Yellow ON, Operation: Yellow Blinking LAN drivers Install the appropriate audio driver for your OS from the bundled CD-ROM [IPC-SLIB-01]. (For information on the latest version of IPC-SLIB-01, check the CONTEC's web site.) User’s Manual...

  • Page 73: Gigabit Ethernet : Lan2

    Right LED: Link / Operation LED Normal connection: Green ON, Operation: Green Blinking LAN drivers Install the appropriate audio driver for your OS from the bundled CD-ROM [IPC-SLIB-01]. (For information on the latest version of IPC-SLIB-01, check the CONTEC's web site.) User’s Manual...

  • Page 74: Usb Ports

    5. Each Component Function USB Ports The BOX-PC is equipped with six channels for USB 2.0 interface. Table 5.4. USB Connector Pin No. Signal name USB VCC USB –Data USB0 +Data USB GND CAUTION To recover the OS using a retail USB-connected CD-ROM drive, refer to the bundled "Recovery Procedures"...

  • Page 75: Serial Port Interface

    Serial Port Interface CAUTION Serial ports 3 - 6 are implemented by mounting a CONTEC PCI serial communication board "COM-4(PCI)H" on the CPU board. The board ID on the CPU board is 0. When installing the COM-4(PCI)H in a PCI expansion slot, use the board ID other than 0. Serial 5/6 cannot be used on standard models as the output connector is not provided.
  • Page 76 5. Each Component Function SERIAL3, 4 (RS-232C Ports) The product has two channels of RS-232C compliant serial ports supporting up to a baud rate of 230,400 bps with a 64-byte transmission-dedicated data buffer and a 64-byte reception-dedicated data buffer. Table 5.6. RS-232C Port Connector Connector used on the product 9-socket D-SUB (MALE) No.4-40UNC...
  • Page 77 5. Each Component Function Table 5.8. Function of Each Register < 1 / 4 > I/O address Description 03F8H THR: Transmitter Holding Register [DLAB=0] bit7 bit0 Register dedicated to write transmitted data to 03F8H RBR: Reciever Buffer Register [DLAB=O] bit0 bit7 Register dedicated to read received data from 03F8H...
  • Page 78 5. Each Component Function Table 5.8. Function of Each Register < 2 / 4 > I/O address Description 03FAH IIR : Interrupt Identification Register Interrupt details 1: Do not generate interrupts 0: Generate interrupts bit2 bit1 bit0 Priority Description Interrupts are not generated. Generated by overrun, parity, framing error or break 1 (high) interrupt.
  • Page 79 5. Each Component Function Table 5.8. Function of Each Register < 3 / 4 > I/O address Description 03FCH MCR: Modem Control Register Loop IRQ RTS DTR 0 : Inactive [HIGH] 1 : Active [LOW] RTS 0 : Inactive [HIGH] 1 : Active [LOW] Interrupt control bit...
  • Page 80 5. Each Component Function Table 5.8. Function of Each Register < 4 / 4 > I/O address Description 03FEH MSR : Modem Status Register DSR CTS DDCD TERI DDSR DCTS Delta CTS Delta DSR Since these statuses are Trailing edge RI not used with Delta data carrier detect RS-485, data...
  • Page 81 5. Each Component Function Table 5.9. Baud Rate Settings Baud rate to be set SERIAL1, 2 SERIAL3, 4 Clock input (1.8432MHz) Clock input (14.7456MHz) Value to be set Setting error (%) Value to be set Setting error (%) in the divisor register in the divisor register (Decimal) (Decimal)

  • Page 82: Crt Interface

    For the LCDs that can be connected, please refer to “Chapter7 List of Options”. Display driver Install the appropriate audio driver for your OS from the bundled CD-ROM [IPC-SLIB-01]. (For information on the latest version of IPC-SLIB-01, check the CONTEC's web site.) User’s Manual...

  • Page 83: Lvds Interface : Lvds

    * Please do not connect anything with the RESERVED pin. Display driver Install the appropriate audio driver for your OS from the bundled CD-ROM [IPC-SLIB-01]. (For information on the latest version of IPC-SLIB-01, check the CONTEC's web site.) User’s Manual...

  • Page 84: Keyboard / Mouse Interface : Kb / Ms

    5. Each Component Function Keyboard / Mouse Interface : KB / MS The product provides a standard PS/2 type keyboard/mouse 6 pin mini-DIN connector for attaching a keyboard/mouse. When connecting only a PS/2 type keyboard, connect directly to this connector. Please use the bundled keyboard / mouse distribution cable, when you connect both PS/2 type mouse and keyboard.

  • Page 85: Connector For The Internal Drive (Primary Ide Master Connection) : P-Ide

    5. Each Component Function Connector for the Internal Drive (Primary IDE Master Connection) : P-IDE The BOX-PC is equipped with an E-IDE controller to allow a 2.5inch IDE hard disk to be connected to connector on the board by using the bundled hard disk bracket. Table 5.13.

  • Page 86: Secondary Ide Connector (Secondary Ide Master Connection) : S-Ide

    5. Each Component Function Secondary IDE Connector (Secondary IDE Master Connection) : S-IDE The CD-ROM/DVD-ROM drive can be connected by using a general-purpose 3.5-inch IDE cable (40 pins). Before plugging or unplugging the cable, be sure to turn the power off. Table 5.14.

  • Page 87: Power Connector For Secondary Ide (S-Ide) : S-Ide

    5. Each Component Function Power Connector for Secondary IDE (S-IDE) : S-IDE This connector can be used to supply power to the drive connected to the secondary IDE (S-IDE) connector. Table 5.15. Power Connector for Secondary IDE Pin No. Signal name +12V User’s Manual...

  • Page 88: Cf Card Connector (Secondary Ide Slave Connection) : Cf

    5. Each Component Function CF Card Connector (Secondary IDE Slave Connection) : CF The CF Card (Type I : dedicated to the memory card) can be connected. Please go after turning off the power supply without fail when the CF card is pulled out and it opens. Table 5.16.

  • Page 89: Expansion Slots (P2 And P4 Model)

    5. Each Component Function Expansion Slots (P2 and P4 model) The P2 model is equipped with two PCI/ISA bus expansion slots capable of accepting either PCI or ISA bus boards. The P4 model is equipped with two PCI/ISA slots and two PCI slots capable of accepting only PCI bus boards as well.

  • Page 90: Led: Power, Access, Status

    5. Each Component Function LED: POWER, ACCESS, STATUS There are three LED in the front of this board. POWER LED (Green) : This LED is “On” when power supply is on. ACCESS LED (Yellow) : This LED is “On” when IDE drive or CF card access. STATUS LED (Red) : User can control this LED.
  • Page 91 5. Each Component Function MOV AL,F0 OUT DX,AL MOV DX,2F MOV AL,1E OUT DX,AL ;----------------------------------- ;Set PIN64S GP35 ;----------------------------------- MOV DX,2E MOV AL,29 OUT DX,AL MOV DX,2F MOV AL,80 OUT DX,AL ;----------------------------------------- ;Exit the extended function mode ;----------------------------------------- MOV DX,2E MOV AL,AA OUT DX,AL (2) LED On...
  • Page 92 5. Each Component Function OUT DX,AL ;----------------------------------------- ;Exit the extended function mode ;----------------------------------------- MOV DX,2E MOV AL,AA OUT DX,AL (3) LED Off ;------------------------------------------ ;Enter the extended function mode ;------------------------------------------ MOV DX,2E MOV AL,87 OUT DX,AL OUT DX,AL ;------------------------------------------------------ ;Select logical device GPIO Port3(number 9) ;------------------------------------------------------ MOV DX,2E MOV AL,07...

  • Page 93: Watch-Dog-Timer

    5. Each Component Function Watch-Dog-Timer The watchdog timer serves as a safeguard against possible system lock-up in your industrial computer system. In most industrial environments, there are heavy equipment, generators, high-voltage power lines, or power drops that have adverse effects on your computer system. For instance, when a power drop occurs, it could cause the CPU to come to a halt state or enter into an infinite loop, resulting in a system lock-up.
  • Page 94 5. Each Component Function (2) Example programming The following example is written in Intel8086 assembly language. ;=============== ;<WDT Initial> ;=============== ;------------------------------------------- ;Enter the extended function mode ;------------------------------------------- MOV DX,2EH MOV AL,87H OUT DX,AL OUT DX,AL ;----------------------------------- ;Set WDT function at pin89 ;----------------------------------- MOV DX,2EH MOV AL,2BH...
  • Page 95 5. Each Component Function MOV DX,2FH MOV AL,00H OUT DX,AL ;------------------------------------------ ;Exit the extended function mode ;------------------------------------------ MOV DX,2EH MOV AL,AAH OUT DX,AL ;================================ ;<WDT START : counter set and a start > ;================================ ;--------------------------------------------- ;Enter the extended function mode ;--------------------------------------------- MOV DX,2EH MOV AL,87H...
  • Page 96 5. Each Component Function MOV AL,AAH OUT DX,AL ;============== ;<WDT STOP> ;============== ;----------------------------------- ;Enter the extended function mode ;----------------------------------- MOV DX,2EH MOV AL,87H OUT DX,AL OUT DX,AL ;----------------------------------- ;Select logical device WDT(number 8) ;----------------------------------- MOV DX,2EH MOV AL,07H OUT DX,AL MOV DX,2FH MOV AL,08H OUT DX,AL...
  • Page 97 5. Each Component Function User’s Manual...

  • Page 98: Appendix

    6. Appendix 6. Appendix Memory Map FFFFFFF Expansion memory area 0100000 00FFFFF Main BIOS (128KB) 00E0000 00DFFFF Expansion ROM area (Free to the user) 00D0000 00CFFFF Reserved for BIOS 00CC000 00CBFFF VGA BIOS (48KB) 00C0000 00BFFFF Video RAM area (128KB) 00A0000 009FFFF (640KB)

  • Page 99: I/O Port Addresses

    6. Appendix I/O Port Addresses Table 6.1. I/O Port Addresses < 1 / 2 > Description Remark ADDRESS(hex) DMA controller 1 (slave) ch0 - 3 (8-bit transfer) 000-00F Reserved for system 010-01F Interrupt controller 1 (master) 020-03F Timer 040-05F Keyboard controller 060-06F RTC, NMI mask 070-07F...

  • Page 100: Interrupt Level List

    6. Appendix Table 6.1. I/O Port Addresses < 2 / 2 > Description Remark ADDRESS(hex) Reserved for system CF0-CFF Reserved for system 4000-403F Reserved for system 46E8 Reserved for system 83D0-B3D3 Interrupt Level List Table 6.2. Hardware Interrupt Levels (Factory Settings) Type 8259 Priority...

  • Page 101: List Of Options

    6. Appendix List of Options Silicon disk drive for extension [PCI Board Type] For IPC-BX701P2-ACxxx, IPC-BX701P4-ACxxx PC-RSD1000-PCI 1GB silicon disk drive PC-RSD2000-PCI 2GB silicon disk drive PC-RSD4000-PCI 4GB silicon disk drive PC-RSD8000-PCI 8GB silicon disk drive Silicon disk drive (IDE 2.5inch) PC-ESD500-A 512MB silicon disk drive PC-ESD1000-A...
  • Page 102 800 x 600 dots, Embedded type) *1 Please purchase the optional connection cable [FPD-26M26M-005, FPD-26M26M-020, FPD-26M26M-050]. Cable FPD-26M26M-005 LVDS Cable (0.5m) FPD-26M26M-020 LVDS Cable (2m) FPD-26M26M-050 LVDS Cable (5m) * Check the CONTEC’s Web site for the latest information on these options. User’s Manual...

  • Page 103: Difference From Ipc-Bx700 Series

    6. Appendix Difference from IPC-BX700 series The difference point with the IPC-BX700 series is shown in the following. IPC-BX700 series IPC-BX701 series 100BASE-TX/10BASE-T x 1 100BASE-TX/10BASE-T x 1, 1000BASE-T/100BASE-TX/10BASE-T x 1 － LVDS I/F LVDS I/F x 1 １GB Memory 512MB User’s Manual...
  • Page 104 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan Japanese http://www.contec.co.jp/ English http://www.contec.com/ Chinese http://www.contec.com.cn/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. [10242008] [02012008] Management No. A-51-514 [10242008_rev2] Parts No.
