Summary of Contents for Contec IPC-BX720-AC Series

  • Page 1 IPC Series BOX-PC for IPC-BX720-AC Series User’s Manual CONTEC CO.,LTD.

  • Page 2: Trademarks

    No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this document.

  • Page 3: Table Of Contents

    Table of Contents Copyright ............................. i Trademarks ............................i Table of Contents..........................ii INTRODUCTION Features ............................1 Supported OS ..........................2 Customer Support ..........................2 Web Site............................2 Limited One-Year Warranty....................... 2 How to Obtain Service........................3 Liability............................... 3 Safety Precautions ..........................3 Safety Information ........................
  • Page 4 BIOS SETUP BIOS Setup ............................27 Starting the Setup Screen......................27 Main Menu..........................30 Standard CMOS Setup....................... 31 Advanced BIOS Features Setup ....................33 Advanced Chipset Features Setup ..................... 36 Integrated Peripherals ........................ 39 Power Management Setup ......................42 PnP/PCI Configurations Setup ....................43 PC Health Status Setup......................
  • Page 5 APPENDIX Memory Map ............................ 83 I/O Port Addresses ..........................84 Interrupt Level List ........................... 85 Utility Soft ............................86 How to exchange the FAN ....................... 87 LIST OF OPTIONS User’s Manual...

  • Page 6: Introduction

    PCI slots concentrated on the front panel, providing superb maintainability and other added values unique to CONTEC. As the BOX-PC incorporates handpicked components such as the embedded types of CPU and chipset, it excels in reliability and stable supply for an extended period of time, offering usability without anxiety.

  • Page 7: Supported Os

    You can download updated driver software and differential files as well as sample programs available in several languages. Note! For product information Contact your retailer if you have any technical question about a CONTEC product or need its price, delivery time, or estimate information. Limited One-Year Warranty CONTEC products are warranted by CONTEC CO., LTD.

  • Page 8: How To Obtain Service

    How to Obtain Service For replacement or repair, return the device freight prepaid, with a copy of the original invoice. Please obtain a Return Merchandise Authorization number (RMA) from the CONTEC group office where you purchased before returning any product.

  • Page 9: Handling Precautions

    Hard disks have a limited life span. Please perform systematic backup and maintenance. CONTEC does not provide any guarantee for the integrity of data on hard disks. To prevent corruption of files, always shutdown the OS before turning off the BOX-PC.
  • Page 10 1. Introduction There is USB apparatus by which current flows conversely to BOXPC through a connection cable at the time of power supply off of BOXPC. When such apparatus is connected, since 5V power supply does not turn off completely, BOXPC may be unable to be started. In such a case, please remove USB apparatus and connect again after a power supply injection.
  • Page 11 1. Introduction User’s Manual...

  • Page 12: Overview

    2. Overview 2. Overview Specifications Table 2.1. Functional Specifications < 1 / 2 > Item Specification Intel(R) Celeron(R) Processor 2.0GHz(FSB400MHz) Chipset Intel(R) 845GV Memory L2 Cache 256KB Main Standard 512MB *1 2GB(1GB x 2)(Max.), memory 2.5V 184 pin DDR SDRAM PC2100 DIMM Socket x 2 BIOS ROM 128KB E0000H - FFFFFH (Award) Video...
  • Page 13 About 5.6kg(At the time of the HDD(SDD) uninstalling) 512MB memory module is plugged. The interface can connect the PC to a CONTEC Panel Link input type display (using an optional cable) or an ordinary analog RGB input display (using the bundled DVI-analog RGB adapter).
  • Page 14 2. Overview Table 2.2. Installation Environment Requirements Item Specification Allowable instantaneous Less than 20ms Power supply power outage One minute each for 2.0kV AC (input - FG) 20mA specifications Dielectric strength 50MΩ (500VDC) 0 - 50°C(Using the SDD *1), Operating temperature 5 - 45°C(Using the HDD) Storage temperature -10 - 60°C...

  • Page 15: System Configuration

    When using the Panel Link Main memory standard I/F LCD 184pin DIMM *optional DVI-Panel Link PCI half-size board conversion cable ECH series Display IPC-BX720-AC series When using the general-purpose Built-in analog input display *DVI-analog RGB adapter (bundled) POWER Mouse MOUSE...

  • Page 16: Physical Dimensions

    2. Overview Physical Dimensions 4-M4 TAP (Containing it in facing) (Maximum tapping length : 5mm) 4-φ5 POWER MOUSE SERIAL1 SERIAL3 LAN1 LAN2 LINE IN 1000/100/10 POWER P - IDE LINE OUT SERIAL2 SERIAL4 ACCESS S - IDE RESET STATUS [mm] Figure 2.2.

  • Page 17: Air Flows

    2. Overview Air flows The following sketches illustrate air flows of this product. Before installing the product, consider the air flows, ventilation, and installation conditions for its use. Front Back Figure 2.3. Air flows User’s Manual...

  • Page 18: Hardware Setup

    3. Hardware Setup 3. Hardware Setup Before Using the BOX-PC for the First Time Follow the next steps to set up the BOX-PC: STEP1 Install the hard disk and set jumper switches. By referring to the information in this chapter, set the BOX-PC. STEP2 Connect cables.

  • Page 19: Hardware Setup

    3. Hardware Setup Hardware Setup Please confirm the power supply is turning off before it works. Please do not remove excluding the explained screw. How to attach the PCI board (1) Use a Phillips screwdriver to remove the screws and top cover as shown below. Figure 3.1.
  • Page 20 3. Hardware Setup (3) Insert each PCI board into the PCI riser bracket and attach the plug board holding bracket. CAUTION Make sure carefully that the board has been secured in the slot. Figure 3.3. Setting the PCI Boards on the PCI Riser Bracket (4) Mount the PCI riser bracket with PCI boards on the system unit.
  • Page 21 3. Hardware Setup (5) Set the top cover. Figure 3.5. Setting the PCI Riser Bracket User’s Manual...

  • Page 22: Locations And Settings Of Dimm Sockets And Jumpers

    3. Hardware Setup Locations and Settings of DIMM Sockets and Jumpers (1) Remove the top cover. Figure 3.6. Removing the top cover (2) Remove the PCI riser bracket and the fan bracket. Figure 3.7. Removing the PCI Riser Bracket, FAN Bracket User’s Manual...
  • Page 23 3. Hardware Setup (3) Remove the power duct bracket. Figure 3.8. Removing the power duct bracket When you have removed the top cover and brackets, you can see the DIMM sockets and a series of jumpers as shown below. DIMM Slot JBAT1 Front Figure 3.9.
  • Page 24 SDRAM Optional memories * PC-MDD512-184A(512MB) Operation is not guaranteed if memory parts other than CONTEC option products are used. (6) After setting the jumpers and plugging the DIMMs, put the brackets and top cover back in place in reverse order.

  • Page 25: Installing The Hard Disk

    3. Hardware Setup Installing the Hard Disk (1) Remove the Hard Disk bracket from the IPC-BX720-AC. Figure 3.10. Removing the Hard Disk Bracket (2) Install the hard disk (silicon disk) to the hard disk bracket. Plug the HDD into the socket first, then fasten it with four screws.

  • Page 26: Attaching The Cf Card Stopper

    3. Hardware Setup (3) Insert the HDD mounted bracket into the system unit and fasten them with screws. Figure 3.12. Installing the Hard Disk Bracket CAUTION When tightening the screws to fasten the HDD to the bracket or the HDD mounted bracket to the system unit, do not use any tool such as an electric screwdriver, which vibrates the HDD.
  • Page 27 3. Hardware Setup Figure 3.14. After the CF Card Stopper is Attached User’s Manual...

  • Page 28: Fastening The Ac Power Cable

    3. Hardware Setup Fastening the AC Power Cable The “Power Cable Fixed Clamp” is attached to the main case. (1) Attach the tip of the cable tie to the hole above the AC inlet. Figure 3.15. Attaching the cable tie (2) Plug the AC power cable into the AC inlet.
  • Page 29 3. Hardware Setup (3) Apply the clamp to the AC power cable. Figure 3.17. Installing the Clamp (4) Move the clamp as close to the AC inlet as possible, then tighten the clamp to fasten the AC power cable. Figure 3.18. Fixing the Clamp User’s Manual...

  • Page 30: Installation Requirements

    3. Hardware Setup Installation Requirements The BOX-PC can be installed in any orientation (1) through (3). Avoid orientation (4) through (6) since it might not adequately dissipate heat. Similarly, to maintain the ambient temperature within the range specified in the specifications, ensure a clearance between the unit and surrounding equipment of at least 100mm for the top and rear and 50mm for the bottom and sides.
  • Page 31 3. Hardware Setup Distances between the BOX-PC and Its Vicinity 50mm or more (Side view) 50mm or more (Side view) 100mm or more (top view) POWER MOUSE SERIAL1 SERIAL3 LAN1 LAN2 LINE IN 1000/100/10 POWER P - IDE LINE OUT SERIAL2 SERIAL4 ACCESS...

  • Page 32: Bios Setup

    4. BIOS Setup 4. BIOS Setup BIOS Setup BIOS setup sets various settings during startup. When using the system for the first time, be sure to run BIOS setup. Once set up, the specified details will be backed up. Starting the Setup Screen When you turn on the system power supply, the BOX-PC displays the following initial screen as long as the system is normal.
  • Page 33 4. BIOS Setup Using Setup In general, you use the arrow keys to highlight items, press <Enter> to select, use the <PageUp> and <PageDown> keys to change entries, press <F1> for help and press <Esc> to quit. Table 4.1. Using Setup program Function Up Arrow Move to the previous item...
  • Page 34 4. BIOS Setup Note on the setup Information in this chapter is subject to change without notice. Phoenix - AwardBIOS CMOS Setup utility > Standard CMOS Features > Frequency/Voltage Control > Advanced BIOS Features Load Fail-Safe Defaults > Advanced Chipset Features Load Optinized Defaults >...

  • Page 35: Main Menu

    4. BIOS Setup Main Menu Once you enter the Award BIOS CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from several setup functions and two exit choices. Use the arrow keys to select among the items and press <Enter>...

  • Page 36: Standard Cmos Setup

    4. BIOS Setup CAUTION Once a password is registered, even the password function itself cannot be cancelled without the password. Passwords should be handled with great care. Save & Exit Setup Use this option to save all the changes made on the Setup screen to CMOS (EEPROM) and reboot the Exit Without Save Use this option to reboot the PC with the last saved settings without saving any changes made on the Setup screen to CMOS (EEPROM).
  • Page 37 4. BIOS Setup Selection from the Standard CMOS Setup This table shows the selections that you can make on the Standard CMOS Setup. Table 4.2. Selecting item of the Standard CMOS Setup Item Option Description Date Month DD YYYY Sets the date on the equipment calendar clock. Note that the ‘Day’...

  • Page 38: Advanced Bios Features Setup

    4. BIOS Setup Advanced BIOS Features Setup This section allows you to configure your system for basic operation. Phoenix - AwardBIOS CMOS Setup Utility Advanced BIOS Features Item Help Virus Warning [Disabled] CPU L1 & L2 Cache [Enabled] Quick power On Self Test [Enabled] Menu Level >...
  • Page 39 4. BIOS Setup Selection from the Advanced BIOS Features Setup This table shows the selections that you can make on the Advanced BIOS Features Setup. Table 4.3. Selecting item of the Advanced BIOS Features Setup < 1 / 2 > Item Option Description...
  • Page 40 4. BIOS Setup Table 4.3. Selecting item of the Advanced BIOS Features Setup < 2 / 2 > Item Option Description Select whether the password is required every time the system boots or only when you enter setup. Select whether the password be requested whenever the system boots up or only upon startup of Setup.

  • Page 41: Advanced Chipset Features Setup

    4. BIOS Setup Advanced Chipset Features Setup Use this menu to set up some features of the chipset. Phoenix - AwardBIOS CMOS Setup Utility Advanced Chipset Features DRAM Timing Selectable [By SPD] Item Help * CAS Latency Time * Active to Precharge Delay * DRAM RAS# to CAS# Delay Menu Level >...
  • Page 42 4. BIOS Setup Table 4.4. Selecting item of the Advanced Chipset Features Setup < 2 / 3 > Item Option Description DDR333 The default is "Auto"; you usually do not have to change this setting. Memory Frequency For DDR266 Auto The default is "Disabled";...
  • Page 43 4. BIOS Setup Table 4.4. Selecting item of the Advanced Chipset Features Setup < 3 / 3 > Item Option Description Set watchdog timer output to PO2. Selecting "Enabled" connects the output of the watchdog timer to the PIO2 pin in the RAS Disabled WDT Output to PO2 connector.

  • Page 44: Integrated Peripherals

    4. BIOS Setup Integrated Peripherals Phoenix - AwardBIOS CMOS Setup Utility Integral Peripherals On-Chip Primary PCI IDE [Enabled] Item Help IDE Primary Master PIO [Auto] IDE Primary Slave PIO [Auto] IDE Primary Master UDMA [Auto] Menu Level > IDE Primary Slave UDMA [Auto] On-Chip Secondary PCI IDE [Enabled]...
  • Page 45 4. BIOS Setup Table 4.5. Selecting item of the Integrated Peripherals Setup < 2 / 3 > Item Option Description Auto The default is "Auto"; you usually do not have to change this setting. Mode 0 Mode 1 IDE Secondary Master/Slave PIO Mode 2 Mode 3...
  • Page 46 4. BIOS Setup Table 4.5. Selecting item of the Integrated Peripherals Setup < 3 / 3 > Item Option Description Ctrl-F1 You can select hot keys with "POWER ON Function" set to "HotKEY". Ctrl-F2 Ctrl-F3 Ctrl-F4 Ctrl-F5 Ctrl-F6 Hot Key Power ON Ctrl-F7 Ctrl-F8 Ctrl-F9...

  • Page 47: Power Management Setup

    4. BIOS Setup Power Management Setup Phoenix - AwardBIOS CMOS Setup Utility Power Management Setup ACAP Function [Enabled] Item Help ACAP Suspend Type [SI(POS)] * Run VGABIOS if S3 Resume Auto Menu Level > Wake-Up by Onboard LAN [Enabled] Power On by Ring [Enabled] * USB KB Wake-Up From S3 Disabled...

  • Page 48: Pnp/Pci Configurations Setup

    4. BIOS Setup PnP/PCI Configurations Setup Phoenix - AwardBIOS CMOS Setup Utility PnP/PCI Configurations Reset Configuration data [Disabled] Item Help Resources Controlled By [Auto(ESCD)] * IRQ Resources Press Enter Menu Level > Default is Disabled. Select Enabled to reset Extended System Configuration Data ESCD) when you exit Setup if you have...

  • Page 49: Irq Resources

    4. BIOS Setup IRQ Resources Phoenix - AwardBIOS CMOS Setup Utility IRQ Resources IRQ-3 assigned to [PCI Device] Item Help IRQ-4 assigned to [PCI Device] Menu Level IRQ-5 assigned to [PCI Device] IRQ-7 assigned to [PCI Device] Legacy ISA for devices IRQ-9 assigned to [PCI Device]...

  • Page 50: Pc Health Status Setup

    4. BIOS Setup PC Health Status Setup Phoenix - AwardBIOS CMOS Setup Utility PC Health Status CPU Temperature Function [Disabled] Item Help * Warning DEEP Disabled * THRM-Throttling Disabled * Throttling Mode 50.0% Menu Level > Current System Tenp. 38°C/100°F Current CPU Temperature 43°C/109°F Current CPUFAN1 Speed...
  • Page 51 4. BIOS Setup Table 4.8. Selecting item of the PC Health Status Setup < 2 / 2 > Item Option Description THRM-Throttling Disabled Throttling starts when the CPU temperature reaches the value set under "CPU Temperature Function" with this item set to "Enabled". Enabled Throttling Mode 87.5%...

  • Page 52: Frequency/Voltage Control

    4. BIOS Setup Frequency/Voltage Control Phoenix - AwardBIOS CMOS Setup Utility Frequency/Voltage Control Spread Spectrum [Disabled] Item Help Menu Level :Move Enter:Select +/-/PU/PD:Values F10:Save Esc:Exit F1 General Help F5: Previous Values F6: Fail-Safe Defaults F7: 0 timized Defaults Figure 4.11. Frequency/Voltage Control Window (factory setting) Description Choice Spread Spectrum...

  • Page 53: Supervisor/User Password Setting

    4. BIOS Setup Supervisor/User Password Setting You can set either supervisor or user password, or both of then. The differences between are: SUPERVISOR PASSWORD: can enter and change the options of the setup menus. USER PASSWORD: just can only enter but do not have the right to change the options of the setup menus.

  • Page 54: Save & Exit Setup

    4. BIOS Setup Save & Exit Setup Pressing <Enter> on this item asks for confirmation: Save to CMOS and EXIT (Y/N)? Y Pressing the <Y> key saves the changes made on the Setup screen to CMOS (EEPROM). Pressing “Y” stores the selections made in the menus in CMOS(EEPROM) – a special section of memory that stays on after you turn your system off.

  • Page 55: Error Messages

    4. BIOS Setup Error Messages One or more of the following messages may be displayed if the BIOS detects an error during the POST. DISK BOOT failure [INSERT SYSTEM DISK AND PRESS ENTER] No boot device was found. This message appears, for example, when the BIOS cannot find any drive from which to boot the system.
  • Page 56 4. BIOS Setup Keyboard error or no keyboard present This message appears with no keyboard connected. The message may also appear if a key remains held down during a boot-up. If this message is displayed, check the connection of the keyboard and its situation during startup.
  • Page 57 4. BIOS Setup User’s Manual...

  • Page 58: Each Component Function

    5. Each Component Function 5. Each Component Function Component Name SERIAL3 SERIAL1 AC INLET (Ethernet) Expansion slot PCI x 2 TOP COVER POWER Primary IDE POWER SW MOUSE SERIAL1 SERIAL3 Secondary IDE MOUSE LAN1 LAN2 LINE IN 1000/100/10 LINE IN POWER P - IDE KEYBOARD...

  • Page 59: Component Function

    The audio driver is required to use the line input, line output, and microphone input interfaces. Install the appropriate audio driver for your OS from the bundled CD-ROM [IPC-SLIB-01]. (For information on the latest version of IPC-SLIB-01, check the CONTEC's web site.) Reset SW : RESET The BOX-PC is equipped with a hardware reset switch.

  • Page 60: Connector For The Internal Drive (Primary Ide Master Connection) : P-Ide

    5. Each Component Function Connector for the Internal Drive (Primary IDE Master Connection) : P-IDE The BOX-PC is equipped with an E-IDE controller to allow a 2.5inch IDE hard disk to be connected to connector on the board by using the bundled hard disk bracket. Table 5.2.

  • Page 61: Secondary Ide Connector (Secondary Ide Master Connection) : S-Ide

    Before plugging or unplugging the cable, be sure to turn the power off. The cable is not intended to connect devices (such as hard disks) other than CONTEC option products. Table 5.3. Secondary IDE Connector (S-IDE) Connector in use 36 pin half-pitch type (0.8mm pitch)

  • Page 62: Cf Card Connector (Secondary Ide Slave Connection) : Cf

    5. Each Component Function CF Card Connector (Secondary IDE Slave Connection) : CF The CF Card (Type I and II x 1 : dedicated to the memory card) can be connected. Please go after turning off the power supply without fail when the CF card is pulled out and it opens. Table 5.4.

  • Page 63: Fast-Ethernet : Lan1

    Right LED: Link / Operation LED Normal connection: Yellow ON, Operation: Yellow Blinking LAN drivers Install the appropriate audio driver for your OS from the bundled CD-ROM [IPC-SLIB-01]. (For information on the latest version of IPC-SLIB-01, check the CONTEC's web site.) User’s Manual...

  • Page 64: Giga Bit Ethernet : Lan2

    Right LED: Link / Operation LED Normal connection: Green ON, Operation: Green Blinking LAN drivers Install the appropriate audio driver for your OS from the bundled CD-ROM [IPC-SLIB-01]. (For information on the latest version of IPC-SLIB-01, check the CONTEC's web site.) User’s Manual...

  • Page 65: Usb Ports

    5. Each Component Function USB Ports The BOX-PC is equipped with four USB 2.0 interface channels. Table 5.7. USB Connector Pin No. Signal name USB VCC USB -Data USB0 +Data USB GND CAUTION To recover the OS using a retail USB-connected CD-ROM drive, refer to the bundled "Recovery Procedures"...

  • Page 66: Serial Port Interface

    5. Each Component Function Serial Port Interface CAUTION Serial ports 3 - 6 are implemented by mounting a CONTEC PCI serial communication board "COM-4(PCI)H" on the CPU board. The board ID on the CPU board is 0. When installing the COM-4(PCI)H in a PCI expansion slot, use the board ID other than 0.
  • Page 67 5. Each Component Function SERIAL3, 4(RS-232C Ports) The product has two channels of RS-232C compliant serial ports supporting up to a baud rate of 230,400 bps with a 64-byte transmission-dedicated data buffer and a 64-byte reception-dedicated data buffer. Table 5.9. RS-232C Port Connector Connector used on the product 9-socket D-SUB (MALE) No.4-40UNC...
  • Page 68 5. Each Component Function SERIAL5 (touch panel) One channel of serial port is provided for use as a touch panel connector (for a CONTEC flat panel display). SERIAL6 (RS-422/485 Ports) One channel of serial port is provided for use as a RS-422/485 ports supporting up to a baud rate of 230,400 bps with a 64-byte transmission-dedicated data buffer and a 64-byte reception-dedicated data buffer.
  • Page 69 5. Each Component Function Control of Transmitted Data in Half-Duplex Mode In half-duplex mode, the transmission buffer needs to be controlled in order to prevent collision of transmitted data. The BOX-PC uses RTS and controls the buffer with modem control register's bit 1. Transmission and reception gate control by the register setting of port address 4006h and 4007h is allowed only for the RS-422/485 (Serial port D).
  • Page 70 5. Each Component Function Table 5.12. Function of Each Register < 1 / 4 > I/O address Description 03F8H THR: Transmitter Holding Register [DLAB=0] bit7 bit0 Register dedicated to write transmitted data to 03F8H RBR: Reciever Buffer Register [DLAB=O] bit0 bit7 Register dedicated to read received data from 03F8H...
  • Page 71 5. Each Component Function Table 5.12. Function of Each Register < 2 / 4 > I/O address Description 03FAH IIR : Interrupt Identification Register Interrupt details 1: Do not generate interrupts 0: Generate interrupts bit2 bit1 bit0 Priority Description Interrupts are not generated. Generated by overrun, parity, framing error or break 1 (high) interrupt.
  • Page 72 5. Each Component Function Table 5.12. Function of Each Register < 3 / 4 > I/O address Description 03FCH MCR: Modem Control Register Loop IRQ RTS DTR 0 : Inactive [HIGH] 1 : Active [LOW] RTS 0 : Inactive [HIGH] 1 : Active [LOW] Interrupt control bit...
  • Page 73 5. Each Component Function Table 5.12. Function of Each Register < 4 / 4 > I/O address Description 03FEH MSR : Modem Status Register DSR CTS DDCD TERI DDSR DCTS Delta CTS Delta DSR Since these statuses are Trailing edge RI not used with Delta data carrier detect RS-485, data...
  • Page 74 5. Each Component Function Table 5.13. Baud Rate Settings Baud rate to be set SERIAL1, 2 SERIAL3 - 6 Clock input (1.8432MHz) Clock input (14.7456MHz) Value to be set Setting error (%) Value to be set Setting error (%) in the divisor register in the divisor register (Decimal) (Decimal)

  • Page 75: Keyboard Interface : Kb

    5. Each Component Function Keyboard Interface : KB The BOX-PC is equipped with a keyboard connector Table 5.14. Keyboard Connector Connector type Equivalent to the MD-DS12300-14S-14 (JST) Signal name Pin No. Pin No. Signal name +KBD DATA +KBD CLK N.C. N.C.

  • Page 76: Dvi Interface : Dvi

    A DVI interface is provided. You can use it to connect a CRT (even a 15 pin D-SUB connector is acceptable by using the bundled DVI-analog RGB adapter) or a CONTEC Panel Link display. The connector is named DVI (DVI-I 29-pin connector).
  • Page 77 Display driver Install the appropriate audio driver for your OS from the bundled CD-ROM [IPC-SLIB-01]. (For information on the latest version of IPC-SLIB-01, check the CONTEC's web site.) Serial Interface for Touch Panel (Inside the DVI connector) The BOX-PC is equipped with a serial port (SERIAL5) to communicate with a touch panel when an LCD equipped with a touch panel is used.

  • Page 78: Ras Functions

    5. Each Component Function RAS Functions A RAS port is provided for this product. This port offers watchdog timer, remote reset, and general-purpose I/O RAS functions. Table 5.18. RAS Connector Connector type 15pin D-SUB(FEMALE) (DALC-J15SAF-20L9) JAE Pin No. Signal Function External speaker signal External speaker ground TX +...

  • Page 79: Watchdog Timer

    5. Each Component Function Watchdog Timer The watchdog timer is started by output of A5 to I/O port address 4002h. A second output of A5 to the same port within the specified expiration time once again triggers the watchdog timer. If a time-out occurs, a reset or an interrupt is generated according to the 4004h port setting or an alarm is output according to the 4004h port setting.
  • Page 80 5. Each Component Function How to Use the Watchdog Timer BIOS setting Power ON Set event Output data to ports 4001h and 4004h to set the counter clock. output control Read port 4002h, stop the WDT, and turn off alarm output. Instruct WDT to stop Set timer value...
  • Page 81 5. Each Component Function * 4001h (bit4-6): Alarm out output control WD_S1 WD_S0 PO2_M RESET PIM2 PIM1 PIM0 R/W (Default: XXXX0000b) Figure 5.4. Alarm Out Output Control Port (4001h) PO2_M : PO PO2/WDT pin output setting : Set the RAS connector's PO2/WDT(12) signal to PO2 (general-purpose output). : Set the RAS connector's PO2/WDT(12) signal to alarm out.
  • Page 82 5. Each Component Function * 4004h : Event output control RESET R/W (Default: XXXX0000b) Figure 5.7. Event Output Control Port (4004h) Table 5.20. WM2-WM0: Interrupt Output Modes Interrupt output at occurrence of WDT errors Output to IRQ5 when time expires on the WDT. Output to IRQ7 when time expires on the WDT.

  • Page 83: General-Purpose I/O And Remote Reset

    5. Each Component Function General-purpose I/O and Remote Reset The BOX-PC is equipped with three general-purpose isolated signals each for input and output. The input signals can also be used for interrupt input or remote reset input. Specifications [ Input ] Input specifications Current-driven input by photocoupler insulation.
  • Page 84 5. Each Component Function I/O Addresses and Instructions * 4000h: General-purpose I/O PIO2 PIO1 PIO0 Figure 5.10. General-purpose Input Port (4000h) R : Read data from PI0, PI1 and PI2. W : Set data to be output to PO0, PO1 and PO2. * 4001h (bit0-3): PI2/IRQ(14) event input control WD_S1 WD_S0...
  • Page 85 5. Each Component Function * 4006h: Index address setting Figure 5.12. Index Address Setting Port (4006h) W : Index address setting When specifying the RS-485 setting with port 4007h, output 00h to this port before you specify the setting. (* Index addresses other than 00h are used by the system. Do not set addresses except for 00h.) * 4007h: Control of RS-485 transmission and reception RE_GATE TE_GATE TE_SEL...
  • Page 86 5. Each Component Function 0 : Controlled by RTS TE_SEL 1 : Controlled by TE_GATE 0 : Transmission prohibited 1 : Transmission permitted RX-(11) 0 : Transmission permitted TE_GATE RX+ (3) 1 : Transmission prohibited TX-(10) TX+ (2) 0 : Receiving permitted RE_GATE 47kΩ...

  • Page 87: Expansion Slots

    5. Each Component Function Expansion Slots This product has two PCI bus expansion slots to hold PCI bus boards. Board Dimensions Allowed 190.00mm(Max.) Figure 5.18. Expansion Board Dimensions CAUTION A board that uses the back of the board edge connector (the shaded area in the figure) may not be mounted.

  • Page 88: User's Manual

    6. Appendix 6. Appendix Memory Map FFFFFFF Expansion memory area 0100000 00FFFFF Main BIOS (128KB) 00E0000 00DFFFF Expansion ROM area (Free to the user) 00D0000 00CFFFF Reserved for BIOS 00CC000 00CBFFF VGA BIOS (48KB) 00C0000 00BFFFF Video RAM area (128KB) 00A0000 009FFFF (640KB)

  • Page 89: I/O Port Addresses

    6. Appendix I/O Port Addresses Table 6.1. I/O Port Addresses < 1 / 2 > ADDRESS(hex) Description Remark DMA controller 1 (slave) 000-00F ch0 - 3(8-bit transfer) Reserved for system 010-01F Interrupt controller 1 (master) 020-03F Timer 040-05F Keyboard controller 060-06F RTC, NMI mask 070-07F...

  • Page 90: Interrupt Level List

    6. Appendix Table 6.1. I/O Port Addresses < 2 / 2 > ADDRESS(hex) Description Remark Reserved for system CF0-CFF 4000-4007 RAS function Reserved for system 4008-400F 4020-402F RTC function Reserved for system 4030-403F 46E8 Reserved for system 83D0-B3D3 Reserved for system Interrupt Level List Table 6.2.

  • Page 91: Utility Soft

    6. Appendix Utility Soft The following gives a brief description of utility software found on the bundled CD-ROM "IPC-SLIB-01". For detailed information and usage, refer to the help file in IPC-SLIB-01. Hardware monitor Utility MTView MTView is a utility to monitor the following items using the hardware monitor and SMART features: - CPU temperature - MB temperature - Rotational speed of CPU fan...

  • Page 92: How To Exchange The Fan

    6. Appendix How to exchange the FAN 1. Remove the screw and dismount FAN bracket from system from main case. A. Case of 40mm FAN (IPC-FAN4020S) [1] Release the lock of the connector which fixed to the bracket. Push the lock and release the connector [2] Remove old FAN and attach new FAN to bracket.
  • Page 93 6. Appendix [3] Attach connector to bracket. Attach the connector to hole near from 40mm FAN B. Case of 92mm FAN (IPC-FAN9225S) [1] Remove the FAN filter and release the lock of the connector which fixed to the bracket. Release the cable Push the lock and release the connector User’s Manual...
  • Page 94 6. Appendix [2] Remove old FAN and attach new FAN to bracket. Then be careful of wind direction. [3] Attach FAN filter and attach connector to bracket. Let the cable pass to hole Attach the connector to hole farfrom 40mm FAN User’s Manual...
  • Page 95 6. Appendix 2. Mount the FAN bracket to main case and fasten the screw. User’s Manual...

  • Page 96: List Of Options

    7. List of Options 7. List of Options Memory for extension (184 pin DIMM) PC-MDD512-184A 184-Pin DDR-Memory (PC2700, 512MB) PC-MDD1G-184A 184-Pin DDR-Memory (PC2700, 1GB) Silicon disk drive for extension (IDE 2.5inch) [PC-ESD Series] PC-ESD500-A 512MB silicon disk drive PC-ESD1000-A 1GB silicon disk drive PC-ESD2000-A 2GB silicon disk drive PC-ESD4000-A...
  • Page 97 7. List of Options Terminal block for connecting the RAS connector IPC-PSD-20 Terminal block for connecting the RAS connector TFT color liquid-crystal display < Analog RGB types > FPD-H21XT-AC (15 inch 1024 x 768 dots, Panel mounted type) FPD-L21ST-AC (12.1 inch 800 x 600 dots, Panel mounted type) FPD-M21VT-AC (10.4 inch...
  • Page 98 7. List of Options FAN, FAN Filler IPC-FAN9225S FAN for IPC-Series (92 x 25mm) IPC-FAN4020S FAN for IPC-Series (40 x 20mm) IPC-FLT92 FAN Filter (92 x 92mm 10pcs) User’s Manual...
  • Page 99 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan Japanese http://www.contec.co.jp/ English http://www.contec.com/ Chinese http://www.contec.com.cn/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. [10032008] [09012005] Management No. A-51-037 [10032008_rev9] Parts No.
