- Page 1 HSA3400 Keypad alarm system Installation Programming Operating Keep in a handy place for reference and for future maintenance 01902 635998 Helpline www.ukpanels.com...
- Page 2 Calling for help watches. Long battery life Yale have a helpline team who are there to offer There is no need to wire into the mains supply advice or solve problems over the phone. or seek the services of a qualified electrician as all Have your certificate number ready.
-
Page 3: Table Of Contents
Contents Recommended installation sequence Contents We recommend you follow the easy start 1 Location planning sequence, headings numbered 1-6. Subsequent sections provide: 2 Insert the batteries • Use of additional accessories including keyfob remote control, smoke detector and help 3 Program the siren and keypad button. -
Page 4: Location Planning
Location planning Work out the best places to locate the devices for maximum protection. Having chosen the locations Operating range Smoke detector accessory All devices must be within 30 metres of the • Mount on the ceiling at the top of a siren unit and must not be mounted on or near stairwell, or where smoke would most large metal objects. - Page 5 s do not mount at this stage. Siren Choose a position on an external wall where the siren would be most prominent. Mount as high as possible, out of easy reach. Door/Window contacts Use one door/window contact on a door that is used as the main point of entry and exit, usually your front door.
-
Page 6: Insert The Batteries
Unpack all the parts on a table top The easiest way to get to know the system and get it up and running quickly is to get all the devices and accessories programmed on a table top before locating and mounting them. Siren PIR movement detectors WARNING... - Page 7 Keypad remote control Keyfob remote control accessory Remove the cover and insert the 3 AAA alkaline Slide off the battery cover, insert the batteries as shown. The ‘Tx’ LED will flash briefly 23A/MN21 battery as shown, and replace while components initialise. battery cover.
-
Page 8: Program The Siren And Keypad
Program the siren and keypad The siren is the heart of the system. First, teach the siren to recognise (learn) the keypad. Use of jumper switches Programming the siren and learning in the keypad The siren, PIR and door/window contact each have internal switches, or ‘jumpers’, which control WARNING various functions. - Page 9 Further siren programming Tamper alarm The siren can be configured to your personal If the siren detects a tamper condition it will requirements by the use of jumpers. activate the siren for the programmed period. If the tamper condition persists the siren will sound a series of five pips either every time the system is armed or when the tamper is enabled, to Jamming detection...
-
Page 10: Mounting The Siren And Keypad
Mounting the siren and keypad WARNING Before mounting the keypad and siren ensure that the system tamper is disabled as described below. Disabling the system tamper 4 Using the holes as a template, drill holes in the surface and insert the wall plugs if fixing into Before mounting it is important to disable the plaster or brick. -
Page 11: Programming And Mounting Detectors
Mounting methods the door contact is operated. Yale provide two methods of mounting. Choose 3 Fit as described in either the self adhesive pads or the screws and ‘Mounting methods’, wall plugs supplied. mounting the detector... - Page 12 • When the jumper is in the normal ‘off’ position Ensure the test/normal mode Surface fixing the indicator light will normally be off. It will jumper switch is in the test ‘on’ holes x 2 only light if there is a problem, either a low position.
-
Page 13: Using The System
Using the system Arm and disarm the system and practice using it. Trigger the alarm by arming the system and opening protected doors/windows and walking past PIRs. Now’s the time to set your pin code and show the rest of the family how simple it is to use. Setting or changing your user PIN Disarming the system code... -
Page 14: Installing And Using Accessories
The system learn mode can be accessed with • Please note that the Home feature is not used the keyfob as follows: with the HSA3400 system. 1 To enter learn mode, press the Panic and Home buttons simultaneously until the siren confirms Programming (approx 5 seconds). - Page 15 (see user guide) and activating the help on accessory keypads) is not used on the button. The siren will beep in response to the HSA3400 system. activation. Please ensure you exit learn mode 1 Using your original keypad, disable the system after testing.
-
Page 16: Changing The Batteries
Changing the batteries Always use alkaline batteries as replacements, any other type of battery (such as heavy duty) can cause problems with the operation of the system. Typical life of siren batteries is two years, whilst detectors will operate for three years before batteries need changing. Always ensure you disable the system tamper when changing batteries. - Page 17 Model: HSA3400 HSA3020 HSA3060 HSA3010 HSA3050 HSA3045 HSA3080 HSA3030 HSA3070 www.ukpanels.com...
-
Page 18: Specifications
Specifications All devices Passive infra red (PIR) detector Power supply 3 x AAA alkaline cells. 3 years typical domestic service life Alarm processing Microprocessor Help button controlled dual edge sequential pulse Tested to ETS 300 683 count with pulse length discrimination Radio Components tested to EN Radio 433.92MHz AM transmitter EMC Tested to EN 300 220-1 and ETS... -
Page 19: Trouble Shooting
Trouble shooting Siren PIR does not respond to movement Siren does not respond to keypad • Previous movement has triggered the PIR sleep • Keypad low battery or bad connection. Check timer is preventing subsequent movement battery connections and polarity, if OK replace detection. -
Page 20: Key Points
See trouble-shooting, page 19 or require a new battery See how to change a battery, page 16 www.yale.co.uk E-mail: info@yaleuk.com Security Products UK Ltd. Wood Street, Willenhall, West Midlands, WV13 1LA Yale is a registered trademark E2 11/03 www.ukpanels.com...
