Yale HSA6200 Quick Manual

Yale HSA6200 Siren Based Alarm System
Quick Guide
Quick Setup Guide
1) SIREN: POWER OFF
2) SIREN PROGRAMMING SWITCHES: 1 & 4 TO ON, 3 & 4 TO OFF
3) PRESS LEARN BUTTON 3- 4 TIMES THEN TURN POWER ON
4) MOVE PROGRAMMING SWITCH 1 BACK TO OFF
5) PRESS AND HOLD LEARN BUTTON ON SIREN – LED 1 & 3 FLASH
6) PRESS RED ARM BUTTON (closed padlock) ON KEYPAD – SIREN BEEPS
7) PRESS LEARN BUTTON ON SIREN – LED 2 FLASHES
8) PRESS DISARM BUTTON (open padlock) THEN 0000 – SIREN BEEPS
9) PRESS PANIC A THEN 0000, PANIC A THEN 2 – SIREN BEEPS
10) PRESS PANIC A THEN 4 – SIREN BEEPS
11) PRESS TEST BUTTON ON THE DETECTORS ONE AT A TIME –SIREN
BEEPS EACH TIME
12) PRESS PANIC A THEN 5 – SIREN BEEPS
13) PRESS DISARM TWICE
Changing the PIN Number
1) PRESS PANIC A THEN 0000
2) PRESS PANIC B THEN NEW FOUR DIGIT PIN CODE
3) PRESS ARM (closed padlock)
4) PRESS DISARM (open padlock)TWICE
Using the System
TO ARM: PRESS ARM (closed padlock) FOR 1 SECOND
TO DISARM: PRESS DISARM (open padlock) AND ENTER PIN NUMBER
Adding Additional Accessories
1) Press Panic A then PIN number, Panic A and 2 – siren beeps
2) Press Panic A then 4 – siren beeps
3) Press the Test button on the detector to be programmed – siren beeps
4) Press Panic A then 5 – siren beeps
5) Press DISARM twice – Key Pad LED stops flashing
Adding an Additional Key Pad:
1) Press Panic A then PIN number, Panic A and 2 – siren beeps
2) Press Panic A then 4 – siren beeps
3) Press the ARM button on the Key Fob to learn in – siren beeps
4) Press DISARM twice – Key Pad LED stops flashing
ADDING AN ADDITIONAL KEY PAD:
