Easy Fit SmartPhone alarm
system (EF-IPBox)
Installation · Programming · Operating
Keep this manual safe for reference and future maintenance
Introduction
Thank you for choosing the Yale Wireless Alarm System.
This simple to install system has been designed with the
user in mind.
All the components are self contained and no connections
are needed between the units. There is no need to
damage the home decor, lift carpets or run cables.
You can install up to 20 devices (Max. 6 PIR Cameras) in
this system. As well as extra door/window contacts, PIRs
and smoke detectors, you can add keyfob remote controls
and keypads for added control convenience.
There is no need to wire into the mains supply or seek
the services of a qualified electrician. The control box is
powered by an adaptor and all other components are
powered by battery (all batteries included).
Batteries will operate for 2 years or more before they need
changing. Regular testing and battery changes (when
notified by the system) will ensure reliability and peace of
mind.
The security detectors and external siren are 'tamper'
protected. Any unauthorised tampering with these items
when the system is armed will result in an alarm.
Display extreme caution when using ladders or steps,
please follow manufacturer's instructions.
Be careful when using hand and power tools and follow
the manufacturer's guidelines when using them. Take care
that the correct tools are used. Wear goggles or protective
clothing where required.
The external Siren is extremely loud, please ensure you
replace the cover and retreat to a safe distance before
testing.
The dialling facilities must only be used with persons who
have consented to being contacted by the system.
The system is not to be used to make 999 emergency
calls directly. Yale do not hold responsibility for any actions
taken by emergency services for incorrect use of the
dialling facility.
Special Notes on Compatibility:
This alarm system is NOT compatible with SmartHome
Alarm, HSA6000 series and HSA3000 series accessories.
Please note the prefix "EF-" on the front of the part
number to indicate compatibility. It is also compatible with
accessories labelled "For use with SmartPhone alarm
only".
V3 onward
Contents
Recommended Installation Sequence
We recommend you follow the simple install
sequence, headings numbered 1-5.
Information and illustrations are subject to change within this
document. Yale reserves the right to alter the specification and
product design at anytime without notice. Yale® is a registered
trademark. © 2014 ASSA ABLOY. All rights reserved.
2
4
6
8
11
13
15
17
18
Advertisement
Table of Contents
Related Manuals for Yale EF-IPBox
Summary of Contents for Yale EF-IPBox
-
Page 1: Table Of Contents
The system is not to be used to make 999 emergency calls directly. Yale do not hold responsibility for any actions taken by emergency services for incorrect use of the dialling facility. -
Page 2: Location Planning
Location planning Work out the best places to locate the devices for maximum protection. Having chosen the locations do not mount at this stage. Home and Away Mode Planning Keypad Remote Control Accessory The home arming mode allows the premises to be When used as second keypad, it is ideal in part armed so that no one can get inside without bedrooms or at the top of a stairwell so the... - Page 3 Smoke Detector Siren • Mount in the middle of the ceiling at the top of a stairwell, or on the centre of hallway ceilings Choose a position on an external wall where the where smoke would most likely be detected. siren would be most prominent. Mount as high as • Do not mount in corners or above cooking possible, out of easy reach. appliances and heaters.
-
Page 4: Unpack All The Parts
Yellow ON: Device fault (Tamper/Low battery) the battery. FLASH: Mains power failed OFF: Normal Bottom LED 3 (Operation Status) Learn/Test Sensor button Yellow ON: Network problem. FLASH: Disconnected from Yale server Green ON: Normal Gap no more than 10mm Magnet... - Page 5 Keyfob Remote Control EF-KF 1 Open the battery compartment using a coin by turning cover in the direction of the big arrow so Keypad remote control Keypad Remote Control EF-KP Keyfob remote control accessory the small arrow is next to round dot. Remove the cover and insert the 3 AAA alkaline Slide off the battery cover, insert the 1 Pull out the plastic battery saver tab at the back of...
-
Page 6: Initial Set-Up
Please ensure all devices are powered and operational at this point. Download Yale app (Smart Phone) Search term in app store: Yale Home System Compatibility: iOS 4.3+, Android 2.2+ (with minimum resolution 320x480) Internet connection: Required on Smart Phone First time registration Start the app on your phone. - Page 7 Adding accessories (if you purchased extra accessories) All accessories in the kit are linked to the control box. If you purchased extra accessories (or for some reason the accessories are deleted), please do the following: Power Battery Learn <On Off> Press and hold the learn button for at least 3 seconds.
-
Page 8: Mounting Devices
1 Using the large screws and wall plugs provided, screw the siren onto the wall through the 4 Login to your Yale Home system app. Select mounting holes on the siren base. “Controller”, “Device List” then select “Walk Test”. - Page 9 Mounting the Keypad: degreaser agent. Please note that some surface or environment (i.e. exposure to Sunlight) may be unsuitable for this mounting method. Please use screw mounting in these cases. -Mounting using screws and wall plugs Battery Saver tab Loosen the bottom screw and open the door/ window contact.
- Page 10 This is done to conserve battery life When the alarm is triggered, the Each system has 20 free SMS credits, after which Yale reserves the right to charge for any system will send an email, push additional SMS sent.
-
Page 11: Using The System
Home Omit in order to be ignored during Home Arm mode. If you wish to trigger alarm count down with a sensor during Home Arm mode, please select the attribute: Home Access. Arming and Disarming your alarm Using the Yale Home system app... - Page 12 Users are advised to delete unwanted images/videos. Controlling Yale Digital door lock This is a reserved function for use with our Digital door lock. We will shortly be launching a module compatible with our Yale Digital door lock range.
-
Page 13: Adding And Using Accessories
Adding and using Accessories To provide additional protection you can add extra door/window contacts, PIRs, keyfob remote controls, keypad remote controls, help buttons and smoke detectors. These are available separately from your local stockist. Keypad Adding accessories to your Keypad initialisation system If you purchase a keypad as an accessory, you will need to initialise it prior to use with the control panel. - Page 14 Using your Help Button Using your keypad • The keypad can be used to Away Arm and Home Arm the system using the buttons as shown. Activate an Alarm • The system is disarmed by pressing the disarm • Press and hold the red button for at least 3 button followed by any user code. seconds. The LED will light momentarily and the • An emergency alarm can be activated by pressing alarm will be activated. the panic A and B buttons simultaneously.
-
Page 15: Changing The Batteries
Changing the Batteries Always use correct type of batteries as replacements because any other battery can cause problems with the operation of the system. Typical life of batteries is two years or more. Ensure the correct steps are taken when changing batteries in tamper protected devices. Low Battery Indication PIR &... - Page 16 Keyfob Battery Change Help Button Battery Change When the battery is low the LED will glow dimly When the battery is low the LED will glow dimly when any key is pressed. The battery is changed as when the button is pressed. The battery is changed follows: as follows: 1 Using a coin turn the battery cover anticlockwise...
-
Page 17: Troubleshooting
Troubleshooting www.Yale.co.uk For online assistance, please visit: Siren PIR LED flashes • Batteries are low or the tamper switch is disturbed. Siren does not respond to arming or disarming Check that the tamper switch spring is making contact with base. If the tamper switch is OK, • Siren batteries are completely exhausted. change batteries with new alkaline replacements. -
Page 18: Specifications
Specifications All devices Passive infra red (PIR) Help button Detector Radio 868MHz FM Environmental conditions Power supply 3V, CR2032 lithium -10°C to 40°C, relative humidity Alarm processing Microprocessor coin cell. 3 years typical domestic 70% non-condensing for all units controlled dual edge sequential service life except the external siren. - Page 19 EF-BX EF-KIT3 HSA3060 HSA3060 EF-SD EF-KIT4 HSA3010 HSA3010 EF-PB EF-DC HSA3050 EF-PANEL EF-PIR HSA3050 HSA3045 EF-IPBOX EF-PC HSA3045 HSA3080 EF-PVC HSA3080 HSA3030 EF-RS HSA3030 HSA3070 EF-PS HSA3070 EF-PETPIR EN 300 220-1 / V2.3.1 (2010) EN 300 220-2 / V2.3.1 (2010) EN 301 489 -1 / V1.8.1 (2008)
- Page 20 50°C, relative humidity 95% non- condensing Radio Microprocessor controlled 433.92MHz AM transmitter RF environment Please note that it is a condition of this guarantee that your Yale Radio Microprocessor controlled condensing 433.92MHz AM transmitter Radio Microproce Power supply 3V, 2 x AAA alkaline cells. 3 product: 433.92MHz AM transmitter...
