Summary of Contents for Yale HSA3000
-
Page 1: Alarm System
HSA3000 100% wirefree security alarm system Installation Programming Operating Keep in a handy place for reference and for future maintenance Helpline 01902 635998... -
Page 2: General System Overview
Calling for help are included in the pack. Please stick them in a front and rear window. Yale have a helpline team who are there to No connections offer advice or solve problems over the phone. All the components are self contained and no Have your certificate number ready. -
Page 3: Table Of Contents
Contents Recommended installation sequence Contents We recommend you follow the easy start 1 Insert the batteries sequence, headings numbered 1-5. Subsequent sections provide: 2 Program the siren • Use of additional accessories including keypad remote control, smoke detector and help watch 3 Location planning 4 Mounting and testing Carton contents... -
Page 4: Insert The Batteries
Insert the batteries The easiest way to get to know the system and get it up and running quickly is to get all the devices and accessories programmed on a table top before locating and mounting them. Siren PIR movement detector WARNING Remove the fixing screw and cover assembly The siren is very loud, be prepared for a loud... - Page 5 Keyfob remote controller Keypad remote control accessory Slide off the battery cover, insert the battery as shown, and replace battery cover. Switch on. Remove the cover and insert the PP3 battery as shown. The light will flash briefly while components initialise. On/Off switch Smoke detector accessory Remove the bayonet cover and insert the...
-
Page 6: Program The Siren
Program the siren The siren contains the systems control unit. First, teach the siren to recognise (learn) all the devices. Use of jumper switches Programming the siren The siren, PIR and door contact have internal WARNING switches, or jumpers, which control various The siren is very functions. - Page 7 Further siren programming Tamper alarm The siren can be further programmed by the If the siren detects a tamper condition it will use of jumpers if you desire. activate the siren for the programmed period. If the tamper condition persists the siren will sound a series of five pips either every time the system is armed or when the tamper is enabled, to Jamming detection...
-
Page 8: Location Planning
Location planning Work out the best places to locate the devices for maximum protection. Range Smoke detector accessory All devices must be within 30 metres of the • Mount on the ceiling at the top of a control unit and must not be mounted on or near stairwell, or where smoke would most large metal objects. - Page 9 Siren Warning The siren is extremely loud, so cover the unit before testing. • Choose a prominent position high up on an external wall, out of reach of the ground • Away from large metal structures and obvious sources of electrical interference Door/Window contact Select a door that will be the main point of entry and exit, usually your front door.
-
Page 10: Mounting And Testing
Alternative mounting methods and check that the detection coverage is adequate. Yale provide two methods of mounting. Choose • Remember to wait a few seconds after the PIR either the self adhesive pads or the screws and has detected movement. - Page 11 Door/Window contact Siren WARNING 1 Ensure the jumper switch is in the test The siren is Jumper ‘On’ position. extremely loud! switch • In this position the The tamper switch indicator light will plunger protrudes Frame illuminate every time through the back of the the door contact is unit, so that if the siren Door/...
-
Page 12: Using For The First Time
Using for the first time Arm and disarm the system and practice using it. Trigger the alarm by arming the system and opening protected doors/windows and walking past PIR’s. Now’s the time to show the rest of the family how simple it is to use. Arming Panic Press Arm on the keyfob for at least 1 second. -
Page 13: Adding Keypad Accessory
Installing and using accessories To provide additional protection you can add additional keyfobs, PIR’s, door and window contacts, a keypad, a help watch and a smoke detector. Putting the system in and out of Adding keypad accessory learn mode 1 Follow sections 1, 3 and 4 (Inserting batteries, Put the system into learn mode and disable the Location planning and Mounting). -
Page 14: Adding Help Watch/Smoke Detector
Tamper Adding the smoke detector If the keypad is removed from its mounting the tamper switch will sound the alarm. 1 Follow sections 1, 3 and 4 (Inserting batteries, The keypad will produce a periodic beep if the Location planning and Mounting). tamper switch has been activated. -
Page 15: Siren
Changing the batteries Always use alkaline batteries as replacements to ensure long service life. The typical life of the batteries is 2 years. Siren Smoke detector The siren will produce a series of pips when The LED will flash and the sounder will beep armed and disarmed, and an interrupted alarm periodically to signal low battery. -
Page 17: Specifications
Specifications All devices Passive infra red (PIR) Keypad detector Radio Microprocessor controlled 433.92MHz AM transmitter Tested to EN 300 220-1 and ETS Alarm processing Microprocessor Power supply 9V alkaline PP3. 2 years 300 683 controlled dual edge sequential pulse typical domestic service life count with pulse length discrimination Environmental conditions Radio 433.92MHz AM transmitter... -
Page 18: Trouble Shooting
Trouble shooting PIR is slow to respond Siren • This is normal, the PIR has sophisticated false Siren does not respond to keyfob controller alarm filtering that will filter out random • Keyfob not switched on. Check it is switched fluctuations and responds to genuine on and the LED illuminates brightly when the movement across field of view, it is less... -
Page 19: Notes
Notes My PIN code... -
Page 20: Key Points
See trouble-shooting, page 18 or require a new battery See how to change a battery, page 15 http://www.yale.co.uk E-mail: info@yaleuk.com Yale Security Products UK Ltd. Wood Street, Willenhall, West Midlands, WV13 1LA Yale is a registered trademark...
