Returning Products For Repair; Warranty And Limitation Of Liability - Setra Systems 267 Installation Manual

8.0 RETURNING PRODUCTS FOR REPAIR

Please contact a Setra application engineer (800-257-3872, 978-263-1400) before
returning unit for repair to review information relative to your application. Many times
only minor field adjustments may be necessary. When returning a product to Setra, the
material should be carefully packaged and shipped prepaid to:
Setra Systems, Inc.
159 Swanson Road
Boxborough, MA 01719-1304
Attn: Repair Department
To assure prompt handling, please supply the following information and include it
inside the package or returned material:
1. Name and phone number of person to contact.
2. Shipping and billing instructions.
3. Full description of the malfunction.
4. Identify any hazardous material used with product.
Notes: Please remove any pressure fittings and plumbing that you have installed and
enclose any required mating electrical connectors and wiring diagrams.
Allow approximately 3 weeks after receipt at Setra for the repair and return of the unit.
Non-warranty repairs will not be made without customer approval and a purchase
order to cover repair charges.
Calibration Services
Setra maintains a complete calibration facility that is traceable to the National Institute
of Standards & Technology (NIST). If you would like to recalibrate or recertify your
Setra pressure transducers or transmitters, please call our Repair Department at 800-
257-3872 (978-263-1400) for scheduling.

9.0 WARRANTY AND LIMITATION OF LIABILITY

SETRA warrants its products to be free from defects in materials and workmanship, subject to the followin
terms and conditions: Without charge, SETRA will repair or replace products found to be defective in material
or workmanship within the warranty period; provided that:
a) the product has not been subjected to abuse, neglect, accident, incorrect wiring not our own, improper
installation or servicing, or use in violation of instructions furnished by SETRA;
b) the product has not been repaired or altered by anyone except SETRA or its authorized service agen-
cies;
c) the serial number or date code has not been removed, defaced, or otherwise changed; and
d) examination discloses, in the judgment of SETRA, the defect in materials or workmanship developed
under normal installation, use and service;
e) SETRA is notified in advance of and the product is returned to SETRA transportation prepaid.
Unless otherwise specified in a manual or warranty card, or agreed to in writing and signed by a SETRA officer,
SETRA pressure and acceleration products shall be warranted for one year from date of sale.
The foregoing warranty is in lieu of all warranties, express, implied or statutory, including but not limited
to, any implied warranty of merchantability for a particular purpose.
SETRA's liability for breach of warranty is limited to repair or replacement, or if the goods cannot be
repaired or replaced, to a refund of the purchase price. SETRA's liability for all other breaches is limited
to a refund of the purchase price. In no instance shall SETRA be liable for incidental or consequential damages
arising from a breach of warranty, or from the use or installation of its products.
No representative or person is authorized to give any warranty other than as set out above or to assume
for SETRA any other liability in connection with the sale of its products.
For all CE technical questions, contact Setra Systems, USA. EU customers may contact our EU representative
Hengstler GmbH, Uhlandstr. 49, 78554 Aldingen, Germany (Tel: +49-7424-890, Fax: +49-7424-89500).
10
Table of Contents
1.0 GENERAL INFORMATION ................................................................................................1
2.0 MECHANICAL INSTALLATION ........................................................................................2
2.1 Media Compatibility ............................................................................................2
2.2 Environment ..........................................................................................................2
2.3 Pressure Fittings ...................................................................................................2
3.0 ELECTRICAL INSTALLATION ...........................................................................................2
3.1 Voltage Output Units
1/2"Conduit Opening, PG9, PG-13.5 Electrical Termination ................2
3.2 Voltage Output Units
9 Pin D-sub Connector Electrical Termination ..........................................4
3.3 Current Output Units
1/2" Conduit Opening, PG9, PG-13.5 Electrical Termination ................4
3.4 Current Output Units
9 Pin D-sub Connector Electrical Termination .........................................5
3.5 4-20 mA Circuit Diagram ...................................................................................5
3.6 EMC Certification ...................................................................................................5
4.0. CALIBRATION ......................................................................................................................6
4.1 Voltage Output Zero Adjustment...................................................................6
4.2 Voltage Output Span Adjustment .................................................................6
4.3 Current Output Zero Adjustment ..................................................................7
4.4 Current Output Span Adjustment ..................................................................7
5.0 MODEL 267 OPTIONAL LCD DISPLAY .........................................................................7
6.0 MODEL 267MR MULTI-RANGE OPERATION ..............................................................8
7.0 MODEL 267 & 267MR PERFORMANCE SPECIFICATIONS .....................................9
8.0 RETURNING PRODUCTS FOR REPAIR ....................................................................... 10
9.0 WARRANTY AND LIMITATION OF LIABILITY .......................................................... 10
10.0 MODEL 267 DESICCANT COVER ............................................................................. 11
10.1 Regenerate the Desiccant ........................................................................... 11
10.2 Replacing the Desiccating Cover .............................................................. 11
