SP / TC / GT
SP/TC/GT USER-OPTIONS
SP, TC, and GT consoles are shipped having standard configuration unless specified at time of order. These are ways that the
console configuration may be varied after manufacture. The items listed are internal options selected by gold jumper links.
Default is marked with a line on the board and is usually pins 1&2 of the three pin header.
In addition there are links for module function assignment. Take care to not disturb these when using USER OPTION links.
MODULE LOCATION
M = Main board
C = Connector
All Inputs M
M
Group Outs M
Left/Right Outs M
Monitor Master C
Optional Modules
Matrix Module M
GT Stereo In M
M
M
M
M
M
These modules must always be installed in the correct positions. They are NOT interchangeable without being properly re-
assigned. Please contact the Crest Audio Service Department for more information.
A A
PPENDIX
OPTION TITLE
Pre Source (SRC)Mute
Pre Source Select
Matrix Post Mute? Y/N
J8, Aux local Mute
Talkback XLR +48V
Cue (PFL switch)
Polarity Reverse
Aux 5-6 Select
Aux 7-8 Select
SEL 1 Pre source L
SEL 2 Pre source R
Pre SRC (source) Mute?
IMPORTANT
Output modules are pre-assigned at the Crest factory
C
ENTURY
FUNCTION
Shipped with the option underlined
Aux sends with or without Mute
Pre & Post EQ
Send Group Post Mute Y/N
Fit links to enable local mutes
On or Off
PFL or AFL
L only or L+R
Mono sum Pre or Post Fader
Mono sum Pre or Post Fader
Pre EQ or Pre Fader
Pre EQ or Pre Fader
Yes or No
S
ERIES
