General Specifications -
GT Console
The following are the technical specifications for the Century
GT console.
Frequency Response
+0.0, -0.5dB, 20Hz to 20 kHz (referenced to 1kHz)
Total Harmonic Distortion
Mic input to Group output
20Hz to 20 kHz at +15dBu
Noise (22Hz to 22kHz)
Mic EIN
Mix Bus Output Noise (20 ch routed)
Aux Bus Output Noise (20 ch routed)
Crosstalk (Measured at 1kHz)
Channel Mute
Channel Fader Attenuation
Channel Routing
Channel Aux Send Attenuation
Input/Output Impedances
Mic Input
Line Input
Outputs
Input/Output Levels (0VU = +4 dBu, 1.23V RMS)
Mic Input Sensitivity
Line Input Sensitivity
Input Insertion Point Level
Output Insertion Point Level
Nominal Output Level
Maximum Balanced Output Level
Configurations
GT Consoles are available in the following configurations:
Four Subgroup 16, 24, 32, 36, 44, or 56 inputs
Eight Subgroup 12, 20, 28, 32, 40, or 52 inputs
Optional stereo input modules and matrix modules are available.
A A
PPENDIX
Architect's & Engineer's
Specifications - GT Console
The following text should be used when specifying a Century GT
in a bid or proposal.
The live sound console shall be constructed in a modular fashion and be
housed in a steel frame with molded plastic side panel/carrying handles.
The console shall be black with white labeling and utilize XLR lighting
device connectors. The console shall have an XLR talkback mic connector
and a headphone jack. These shall be located beneath the far right side of
<0.01%
the armrest.
All microphone inputs shall be electronically balanced and accessed via 3-
pin XLR connectors and have an EIN of -129 dBm. All line inputs shall be
-129 dBu
electronically balanced and accessed via 1/4" TRS jacks. The insert points
- 80 dBu
shall be via 1/4" TRS jacks.
- 80 dBu
Each input channel shall have: a +48 volt phantom power switch, a -15 dB
mic pad switch, a 80Hz high pass filter switch, a polarity reverse switch
and 4-band (LF-40-800Hz, LMF-100Hz-2kHz, HMF-400Hz-8kHz, HF-
>102 dB
1.5k-20kHz) sweepable EQ with peak/shelve switches on the high and low
> 96 dB
controls and an EQ In switch. Each input channel shall also have: a FET
> 85 dB
controlled (10 millisecond ramp) mute switch with LED, sub-group
> 93 dB
assignment switches, a L/R assignment switch, a dedicated mono assign-
ment switch, a dynamic signal present LED and peak LED, a PFL switch,
4kΩ balanced
4 scene mute switches (A-D), scene mute safe switch with LED, and a
>10kΩ balanced
100mm long throw fader.
140Ω balanced
Each input channel shall have eight auxiliary sends which shall be con-
trolled via six knobs and four switches. The aux sends shall have a
pre/post fader switch for every four sends. The aux sends shall be selec-
+ 4 to -62 dBu
table pre or post EQ and pre or post mute. There shall be an Aux 8 direct
+ 12 to -38 dBu
switch that shall allow the Aux 8 rotary knob to directly control the output
+ 4 dBu
of the 1/4" direct out TRS jack.
- 2 dBu
The console shall be available in four or eight bus configurations. Each
+ 4 dBu
group module shall have a ten-segment LED meter array. The effect return
+28 dBu
section of each group module shall have a gain control, a two-band fixed
EQ, sub-group assignment switches, a L/R assignment switch, a dedicated
mono assignment switch, two aux send controls, a pan control, a level con-
trol, a dynamic signal present LED and peak LED, and a PFL switch. The
remainder of the group module shall have a pan control, an FET controlled
(10 millisecond ramp) mute switch with LED, assignment switches for:
mono, L/R, Group XLR and matrix post. It shall also have a fader reverse
switch with LED. A PFL switch, dynamic signal present LED and peak
LED, 4 scene mute switches (A-D), scene mute safe switch with LED, and
a 100mm long throw fader shall also be provided on the group module.
The master section shall be four modules in width and have the following
features: an 11x2 matrix, eight aux master controls with associated AFL
switches, eight aux scene mute switches with LED, a 100mm long throw
fader for each of the three master outputs, a fully assignable comprehen-
sive talkback system, a talkback mic connection, a headphone jack, stereo
program input control, and five scene mute master switches each with
LED.
The power supply shall be housed in a 14 ga. steel chassis that shall occu-
py two 19" rack spaces. The power supply shall have the ability to be
daisy-chained to additional power supplies to provide a fail-safe operating
environment. Connection of two or more power supplies shall not require
additional interface hardware other than the provided cable.
The live sound console shall be: the Crest Audio Century GT.
