SP Input Module
1•3
5
4
6
3
7
The SP input module is the most straightforward of the
2
8
1
9
Century Series. While it shares many features with more
0
10
5
2•4
4
6
complex input modules, the SP input module is simple in
3
7
2
8
design and operation.
1
9
0
10
LINE Switch
3•4
Selects between the Balanced XLR Microphone Input con-
POST
nector and the Balanced Line Input 1/4" TRS connector.
5
5
4
6
3
7
48V Phantom Power Switch
8
2
1
9
Turns on 48V Phantom Power, required by certain micro-
10
0
6
phones for proper operation.
5
4
6
3
7
2
8
PAD Switch
1
9
0
10
Introduces a -15 dB attenuation to the mic input signal.
7
5
4
6
3
7
GAIN Control
2
8
1
9
Adjusts input gain for proper signal level.
0
10
5
8
4
6
80Hz High Pass Switch
3
7
2
8
1
9
Reduces all low frequency content at a 12db per octave rate
0
10
referenced to 80Hz (-3db point).
Four Band Fixed Equalizer
PRE
Controls the cut or gain of four fixed frequencies (10 kHz,
AUX SENDS
PAN
2.7kHz, 300Hz, 80Hz) within the input signal only when the
EQ IN switch is depressed.
EQ IN Switch
MUTE
Inserts the EQ section into the input channel signal. An asso-
ciated LED illuminates when the switch is down.
MONO
AUX Level 1•3 / 2•4
L - R
1 - 2
Adjusts audio level of a mix for use as a monitor or an effect
send. The signal source for this mix may be selected pre or
3 - 4
post fader by an associated switch.
5 - 6
7 - 8
AUX ASSIGNMENT 3•4 Switch
Selects the first two Aux level controls between the Aux 1•3
PFL
1
mix bus and the Aux 2•4 mix bus.
PEAK
POST/PRE Switch
SIG
Selects the Aux 1•3 and Aux 2•4 signal sources between post
and pre fader positions.
AUX 5 - 8 Individual Level Controls
Adjusts audio level of a mix for use as a monitor or an effect
0
send. The signal source for these mixes may be selected pre
or post fader by an associated switch.
5
PRE/POST Switch
Selects the Aux 5 through 8 signal sources between pre and
10
post fader positions.
PAN CONTROL
20
Positions the channel image between the left (odd) and right
(even) channel assignment.
30
MUTE Switch with LED
40
Mutes the channel and all send functions. This switch does
not affect the PFL switch or the Peak and Signal Present LED
indicators, The LED illuminates when the channel is muted
from the local mute switch.
