bon BQM-170LS Operating Instructions Manual

17 inch 24 inch integrated 4chanel quad view
Hide thumbs
Table of Contents

Advertisement

Quick Links

OPERATING INSTRUCTIONS
Integrated 4chanel Quad View
Multi format LCD Monitor
Model : BQM-170LS(17")
BQM-240LS(24")
-- 1 --

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BQM-170LS and is the answer not in the manual?

Questions and answers

Related Manuals for bon BQM-170LS

Summary of Contents for bon BQM-170LS

  • Page 1 OPERATING INSTRUCTIONS Integrated 4chanel Quad View Multi format LCD Monitor Model : BQM-170LS(17”) BQM-240LS(24”) -- 1 --...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1. Read all of these instructions. 2. Save these instructions for later use. 3. All warnings on the product and in the operating instructions should be adhered to. 4. Unplug this appliance system from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
  • Page 3 17. Unplug this appliance from the wall outlet and refer servicing to qualified service personnel under the following conditions: a. When the power cord or plug is damaged or frayed. b. If liquid has been spilled into the appliance. c. If the appliance has been exposed to rain or water. d.

  • Page 4: Safety Precautions

    SAFETY PRECAUTIONS WARNING : CAUTION -TO REDUCE THE RISK OF FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS EQUIPMENT RISK OF ELECTRIC SHOCK TO RAIN OR MOISTURE. DO NOT OPEN -TO REDUCE THE RISK OF FIRE OR SHOCK HAZARD, KEEP THIS EQUIPMENT AWAY FROM ALL LIQUIDS.
  • Page 5 • Aspect ratio 16:9 Y/C, DVI-I, HDMI, LTC • Contrast 600:1 • Output : • Viewing Angle: 160 ˚ SDI(4EA,BNC) BQM-170LS • Power : AC100-230V ( 17 Inch HD LCD Monitor ) • Input : • Resolution 1920 X 1200 SDI(4EA,BNC), Analog(3EA,BNC), •...

  • Page 6: Table Of Contents

    Thank you for purchasing this product. Before operating this product, please read this instructions carefully and save this manual for later use Contents 1. Out Line • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 7 2.

  • Page 7: Outline

    1. Outline BON HD Digital Monitor series are a Multi-Format HD Monitors with high core technology to display various kind of digital video input signals. It supports HD / SD-SDI, RGB, Component and Composite signals 2. Functions and Features • High Quality Video Display with RGB 10BIT Digital Signal Process •...

  • Page 8: Controls And Functions

    3. Control and Functions 3.1. Front Panel BQM-170LS,240LS(Front Push Button) 3.1. Front Panel ①STANDBY -Power ON/OFF Button. When you power OFF, it operates after being pushed about 1 second ②SDI, SDI2, SDI3, SDI4 INPUT SELET -Used to select HD/SD-SDI CH1, CH2, CH3, CH4 ③YPbPr, RGB(Component) INPUT SELECT...
  • Page 9 ⑥CVBS1, CVBS2,CVBS3, Y/C INPUT SELECT -Used to select Composite Signal(CVBS), Y/C(S-Video)Signal. -By pressing this button, it converts Input modes between CVBS1,2,3 and Y/C mode ⑦FULL/SPLIT -Used to convert Display Mode between Full Mode and Split Modes -FULL Mode : shows 1 signal source only. -SPLIT Mode :shows 2 or 4 signal sources together ⑧SHIFT -Used to convert another Display mode in Split mode...
  • Page 10 ⑬W-FORM/VECTOR -This function is only activated in Full Mode ONLY(Not SPLIT Mode) -When this button being pushed, it shows waveform or vector scope for corresponding input -By being pushed, it converts each mode between waveform and vectorscope -Please note : this function does not work in DVI/HDMI/VGA(PC-RGB)Mode ⑭ENTER/MARKER 1) When OSD Menu is ON, this button is used as Enter Key.

  • Page 11: Rear Panel

    ⑬ S-VIDEO LTC IN ⑥ ⑬ LTC IN S-VIDEO ⑦ ⑦ ⑭ ⑭ CVBS1,2 CVBS1,2,3 ,3 & & COMPO COMPON ⑧ NENT HDMI ⑧ HDMI ⑨ AC IN ⑨ AC IN BQM-170LS Rear panel BQM-240LS Rear panel -- 11 --...
  • Page 12 ① REMOT(RJ-45 Jack)Port -Used for external Control(Make/Trig type terminal) -For detailed information, please refer to category8. Terminal Assignment Connection ②③④⑤ :SDI Input Port - HD/SD-SDI Signal Input Port. SMPTE standard type. Aviailable to input SDI signal which includes Audio Signal. ⑥...

  • Page 13: Tally & Audio

    3.3. Tally & Audio 1) Tally LED Tally UMD Tally There are 2 different Tally types(LED, UMD). The colors are 2types(Red, Green). Color can be selected by External Contact terminal 1) Audio In/Output ① Analog Audio L/R Input Terminal(3.5mm Phone Jack) -External Input Port for Analog Input.

  • Page 14: Front F1,F2의 Function

    3.4. Function Buttons for F1, F2 There are 2 push buttons located on the front panel. Function1 and Function2. You can select and designate desired function into each button from below list -F1 Default Value : Audio Display -Fe Default Value : H/V Delay ◊Selectable Functions◊...

  • Page 15: Status Display

    4. STATUS DISPLAY Used to confirm the operating status. Some functions may not be supported depending on the installed options Time Code Display Displays selected channel’s signal format information Displays Left Audio Level Meter Displays Right Audio Level Meter Ch1,3,5~15 Ch2,4,6~16 When Menu is activated, Information indication such as Audio Level Meter, Timecode, Source ID is designed to be lighter in color...
  • Page 16 1) Audio Level Meter Display -Sets “ON/OFF” and “POSITION” from Audio Level Display Menu -ON: Displays Level Meter (Left shows even ch/Right shows odd ch) -OFF: Display Off Level Meter █ Audio Level Meter Direction Assignment : You can set either Horizontal or Vertical bar. █...

  • Page 17: Input Select

    5. INPUT SELECT ① TO CHANGE FULL/SPLIT MODE ② TO CHANGE LAYOUT IN SPLIT MODE ③ TO SELECT DESIRED CHANNEL IN SPLIT MODE 5-1. Full Mode -Push FULL/SPLIT Button to be Full Mode. -FULL/SPLIT KEY LED will be off in Full Mode █...

  • Page 18: Split Mode

    5.2. SPLIT MODE Push FULL/SPLIT Button to be SPLIT Mode. In this mode, FULL/SPLIT Key LED will be ON Selected Channel’s Source ID character background color will become BLUE █ SPLIT Layout Mode Change : In Split Mode, to change layout, press SHIFT KEY button, then, it will change layout out of 9 designated different Layout Modes.

  • Page 19: Display Mode(Lay Outs)

    5.3. SPLIT MODE Lay Out <SPLIT-MODE1>QUAD VIDEO <SPLIT-MODE2>Video + Measure <SPLIT-MODE3>Video + Measure <SPLIT-MODE4>2Video + Clock <SPLIT-MODE5>2Video + Measure <SPLIT-MODE6>2Video + Measure -- 19 --...
  • Page 20 5.3. SPLIT MODE Lay Out <SPLIT-MODE7>1 + 2 Video <SPLIT-MODE8>1 + 3 Video <SPLIT-MODE9>1 + 3 Video <FULL Mode> -- 20 --...

  • Page 21: Osd Menu Control

    6. OSD Menu ▲ Up/Down Enter Menu Control Button 6-1. Menu Setup. 1) Press Menu Button for OSD Menu 2) Move into the itesm with Up▼/Down▲ or by rotating VOLUME Knob Press ENTER Button to select the desired item Note) Volume can be used as UP(CW) button by rotating Volume knob on the status of Menu Control.

  • Page 22: M A I N M E N

    6-2. MAIN MENU ④ ① ② ③ ⑤ ① shows signal channel information for current window ② shows input video signal format and frequency information ③ shows Main MENU items ④ shows sub items of currently selected Main MENU (Yellow color) ⑤...
  • Page 23 MAIN MENU █ VIDEO : controls bright, contrast, phase, chroma,etc █ DISPLAY : controls Waveform/Vector ,etc █ COLOR : controls color temperature mode █ MARKER : sets Marker type, color, thickness █ OSD : sets MENU, Closed Caption and UMD Display, etc █...

  • Page 24: Video Setup

    6-3. VIDEO SETUP █ Brightness : adjusts Brightness, █ Contrast : adjusts Contrast █ Chroma : adjusts Chroma █ Phase(Hue) : adjusts Phase █ Sharpness: adjusts Sharpness [VIDEO SETUP MENU] █ NTSC Setup : sets 0 IRE, 7.5 IRE -7.5 IRE-> Operates in NTSC or in SD level YPbPr mode -0 IRE: Operates in PAL signal █...

  • Page 25: Vga Color Setup

    6-3-1. VGA COLOR SETUP █ How to set Menu : MENU -> VIDEO -> VGA Display Set -> change “Default” value into “ User Adjust” and ENTER █ Red Gain : adjusts Red Input Gain █ Green Gain : adjusts Green Input Gain █...

  • Page 26: Display Setup

    6-4. Display SETUP This menu sets picture size or output █ PC Scan : sets output either Fill mode or Aspect mode in VGA channel. -Aspect : displays original source rate -Fill : displays source filled to screen size █ Pixel to Pixel :Used to show the picture as original input source size in SD-SDI or Analog mode or used to show picture as P2P mode in 2K format signal input.
  • Page 27 █ Anamorphic resize Vertical Resolution into 2.35 : 1 in 1280*720 / 50p, 59.94p, 60p mode. 1280*720 format 1280*720 format 16:9 2.35 : 1 Anamophic Off Anamophic On █ Fast Mode : - Fast : minimize delay time by Interace signal output without changing Progressive Scan - Normal : outputs Interace signal into Progressive Scan █...
  • Page 28 █ Waveform Position - locates Waveform Display Position. - Position can be located as following 4 areas : (Left Top, Left Bottom, Right Top, Right Bottom) █ Vector Position - locates Vector Display Position. - Position can be located as following 4 areas : (Left Top, Left Bottom, Right Top, Right Bottom) █...
  • Page 29 -In case of 1920*1080/60i signal, LTC is located in line10, VITC#1 is located in line9, VITC#2 is located in line571. -Spec is SMPTE RP-188, ITU-T BT.1366. In case of BON Monitor, following menu set is recommended in Time Code MENU. - LTC in HANC : located in Line 1.

  • Page 30: Color Setup

    6-5. COLOR SETUP █ Color Temperature Sets Monitor color temperature or user color temperature. There are 4 different type color temperatures such as 3200K, 5400K, 6500K, 9300K, and each color temperature is set when product is released from factory. █ Adjust Temperature (User mode) When setting User Mode, it become activated, User can adjust RGB Gain &...

  • Page 31: Marker Setup

    6-6. MARKER SETUP █ Marker 16:9 -Sets Marker type in 16:9 HD. -There are 9 different Marker such as 4:3, 15:9, 14:9, 13:9, 1.85:1, 2.35:1, User1, User2, User3, Off. █ Safety Area 16:9 -sets safety area in 16:9 HD. -There are 12 different types such as EBU GRA 4:3, EBU ACT 4:3, EBU GRA 14:9, EBU ACT 14:9, EBU GRA 16:9, EBU ACT 16:9, 95%, 93%, 90%, 88%, 85%, 80%, Off .

  • Page 32: Osd Setup

    6-7. OSD SETUP █ MENU Display Time -Used to set Menu Window display time. You can set Menu display time with 5 seconds interval. Time can be set 5~60 seconds. If continue value is set, Menu Window will not disappear in the screen. █...
  • Page 33 (Note) NS : indicates “Not Support” CC 708 / CC 608 Transcoded CC 608 Line 21 (SD-SDI) (HD-SDI) CC 608 Line 21 (SD-SDI) CC 608 Line 21 / V-Chip (Composite) -- 33 --...

  • Page 34: Source Id Setup

    6-8. SOURCE ID SETUP █ You can set ID for each input signal. Once you set the ID, it displays on the UMD display window. UMD supports alphabet small letter, capital letter, some of special characters. Upto 10 digits supported. █...

  • Page 35: Audio Setup

    6-9. AUDIO SETUP █ Play Channel [ L ] -designates extracted sound signal from Speaker Source into Left Output Channel. █ Play Channel [ R ] -designates extracted sound signal from Speaker Source into Right Output •Audio Output Channel has from CH1 ~ CH16 - Left Channel : CH 1, CH 3, ~ CH 15 - Right Channel : CH 2, CH 4, ~ CH 16 - GROUP1 : CH 1 ~ CH 4...
  • Page 36 Audio Level Meter Display Condition Table for BQM Model When Speaker Source is set into Auto mode, Audio Source outputted via Speaker is Screen Channel(1~4) related Audio that is selected by CH.SELECT button. - If selected Channel’s Input Source is SDI, corresponding signal’s Embedded Audio will be output,.

  • Page 37: Gpi Setup

    0~99. Or IR Remote control, it sets monitor body number. (Option) █ Serial Remote Selects use BON or TSL v4.0 mode. Selects whether use external SERIAL PORT (RJ-11) control or not. If Serial Remote is ON, then, it becomes Standby, with the exception of MENU button, the other buttons does not operate.

  • Page 38: System Setup

    6-11. SYSTEM SETUP █ Function 1,2 Used to select the functions to be assigned to individual buttons to F1,F2. (For detailed information, please refer to 3-4 table.) █ Back Light Used to adjust brightness of LCD Panel █ Front Button Lock Switches ON/OFF Rock function for Front Key button .

  • Page 39: Info Setup

    6-12. INFO MENU █ Firmware Version -displays product Firmware & Hardware PLD version █ Operating Time -displays Operating hour █ Input Status - Displays input source information for each window channel. Note : While Back Light is adjusted, LCD Panel requires enough time to be stable adjusting Phase (brightness).

  • Page 40: Remote Terminal Assignment

    7. Remote Terminal Assignment 7-1. Remote Terminal(RJ-45) Assignment Each terminal function can be set from the GPI CONTROL SETUP Menu. 1 2 3 4 5 6 7 8 Remote (RJ-45) Remote PIN Assignment 1 PIN GPI Port 1 5 PIN GPI Port 5 2 PIN GPI Port 2...

  • Page 41: Remote Terminal Assignment

    7-3. Remote Terminal Assignment Operating Port Assignment Items Function conditions SDI1 Input Switches the input SDI-1 SDI2 Input Switches the input SDI-2 SDI3Input Switches the input SDI-3 SDI4 Input Switches the input SDI-4 Y/Pb/Pr Input Switches the input YPbPr R/G/B Input Switches the input RGB DVI Input Switches the input DVI...

  • Page 42: Program Update Port

    8. Program Update Port(RJ-11) Update Port(RJ-11) can be used in a situation as below. 1) To modify Firmware program 2) To control Color Temperature, Gamma Setting for LCD 3) To control Multi Monitors using PC Exclusive use program “Wall System Control” on PC Please consult with technician for Program Update or for Serial Port use.

  • Page 43: List Of Compatible Signal Formats

    9. List of Compatible Signal formats : BQM Series 9-1. Input Video Signals -- 43 --...

  • Page 44: Computer Signals (Pc-Rgb/Dvi)

    9-2. Computer Signals (VGA/DVI) : BQM Series Input Signal Screen Vertical Frequency Names Resolution (PC-RGB) 640*480 √ √ 60Hz ~ 100Hz SVGA 800*600 √ √ 56Hz ~ 85Hz 1024*768 √ √ 86Hz ~ 100Hz WXGA 1280*768 √ √ 50Hz ~ 85Hz SXGA 1280*1024 √...

  • Page 45: Specifications

    10. Specifications Section BQM-170LS BQM-240LS SDI Input 4EA, HD/SD Serial Digital , 1.485Mb/s/270M, BNC Jack Analog Input 3EA, Composite, Component, RGB, BNC Jack Input Y/C Input 1EA, Y/C, Super Jack(4p) DVI-I Input 1EA, DVI-I, 24pin, Female, PC-RGB (with Gender) 5pin...

  • Page 46: Dimensions

    11. Dimensions BQM – 170LS Dimensions (Unit: mm) WALL Mounting Hole (100*100mm) Size M4, Depth 10mm BQM – 240LS Dimensions (Unit: mm) -- 46 --...

  • Page 47: Up Version And Modification Of Product

    12. Trouble shooting Solutions to common problems related to the monitor are described here. If none of the solutions presented here solves the problem, unplug the monitor and consult an authorized dealer or service center. Symptom Probable cause and corrective action Page •...
  • Page 48 BON ELECTRONICS, INC. (Head Office) 2F Tresbelle-sky Building,9-19 Yangcheon-ro 57-gil, Gangseo-Gu, Seoul, Korea Tel : (+82) 2-2659-0333 (113), fax: (+82) 2-2659-8133, salesbon@bon.co.kr http://www.bon.co.kr -- 48 --...
