Contents Safety Instructions....................3 Front........................4 Rear........................6 MENU Description....................7 VIDEO........................9 DISPLAY 1......................10 DISPLAY 2......................12 COLOR.........................14 MARKER......................15 OSD........................17 AUDIO........................19 GPI........................21 SYSTEM......................23 USB Firmware Update..................25 External Remote Control..................26 List of Compatible Video Formats (HDMI/Composite)........28 List of Compatible Video Formats (SDI)............29 Specifications......................31 Dimensions......................32 Troubleshooting....................33 Warranty Information..................35 Modification of Product..................35 Caution on Menu Operation................35 Caution for Monitor Placement................35...
Safety Instructions • To help avoid damaging your monitor, connect only one power (AC or DC) in operation. • Rough handling of product may cause physical damage or malfunction. • Never insert anything metallic into the monitor openings. Doing so may create the danger of electric shock.
Rear AC Input Please check Power Cord, Power Voltage, Supply power for power input are suitable for the standard before use. Please do not mix AC power and DC power as it may cause the defects or fire. DC Input For DC power supply.
USB Port USB Firmware Update Port. MENU Description General Cautions for OSD menu or Display The menu may not be displayed even when user pressed Menu button if there's No Signal, or in unclear signal status. The menu selection may be saved for each input signal mode, so sometimes user should do menu selection again.
VIDEO Brightness, Contrast, Chroma, Phase, Sharpness Adjust color representation values. SDI Switching Normal : Use Normal in general condition but the screen might be blinking on screen change when you use Matrix or Routing Switcher. Fast : Use Fast to minimize blinking on screen change. NTSC Setup Select IRE among 0 or 7.5 (Default) HDMI UV Swap...
DISPLAY 1 Aspect Set the aspect ratio of the screen. 16:9, 4:3, Native(Original) are selectable. This selection is ignored on 1080i, 1080p, 720p. 1:1 Scan On SD signals(Not HD), Set this on to display picture in 1:1 pixel mapping. Turn this mode on to adjust aspect ratio with the ratio value in the source signal. Waveform Display Select waveform display mode.
Page 10
Waveform Intensity Adjust waveform intensity. Waveform & Vector Size Adjust size of Waveform & Vector. Waveform & Vector Blend Adjust transparency value of Waveform & Vector. False Color Turn False Color mode on to check exposure levels of the picture.
DISPLAY 2 Exposure Range Check (Video Range Check) Checks Y, C level and displays over-exposed or under-exposed area on screen. The base value can be Y, Cb, or Cr. Y Range Max / Min Set Y range value for range check. C Range Max / Min Set C range value for range check.
Page 12
Focus Assist Color Set brush color of focus assist mode among Blue, Green, and Red.
COLOR Color Temperature Select color temperature among 3200K, 5400K, 6500K, 9300K or USER. (Gain and Offset menu are displayed on USER temperature only) Red/Green/Blue Gain (USER mode only) R,G,B gains are adjustable on User mode. Red/Green/Blue Offset (USER mode only) R,G,B offsets are adjustable on User mode.
MARKER Marker Ratio Select one of preset markers or user marker. To display marker, press Marker button in front of the monitor. Center Marker Set preference to display center marker or not. Safety Area 16:9 Adjust size of the safety area when marker displayed on 16:9 screen. Safety Area 4:3 Adjust size of the safety area when marker displayed on 4:3 screen.
Page 15
User Marker H1 / User Marker H2 / User Marker V1 / User Marker V2 Set user marker’s position. H1 for left, H2 for right, V1 for top, V2 for bottom. The positions are saved as the selected marker name such as USER1.
Timecode Display On/Off Timecode Position Set the position of timecode. OSD Display Time Set menu display time (seconds) MENU Position Set menu position among Left Top, Right Top, Left Bottom, Right Bottom and Center. V-Chip SD-SDI, Composite signal might contain V-Chip data. Turn this mode on to display V-Chip information on screen.
Page 17
Service 1: general captions. Service 2: translated captions. Service 3,4: not assigned. CC608 StartLine Display line of captions are selectable by user. (e.g. 13) Internal Pattern Show internal test pattern such as color bars. Turn this mode off to display general pictures from input port.
Page 18
OSD 2 PIP Source Select Picture-in-Picture source. PIP Mode Large PIP, Small PIP, Side by Side can be selected. PIP Position Sets sub-picture position.
AUDIO Embedded Audio Left Select audio channel for left (Ch 1 ~ 15) Embedded Audio Right Select audio channel for right (Ch 2 ~ 16) Audio Level Meter Turns on/off audio level meters. Level Meter Size Select the size of the meters : Small or Large. Level Meter Position Select the position of the meters : Upper or Lower.
GPI Control Turns on/off external monitor control function. GPI Port 1,2,3,4,5,6 Assigns each GPI port’s function. (e.g. SDI 1 input, HDMI input, Tally Red) See EXTERNAL REMOTE CONTROLLING section for details. Remote ID Number Assigns the ID for the monitor to control through serial port. 0 to 99 can be assigned.
SYSTEM Function 1,2,3,4 Assigns a function to each function button. See FRONT section for detail. Backlight Set the backlight intensity from 0 to 40. An LCD panel requires more than 30 minutes to be settled to a new backlight value. Front Button LED Set front LEDs on/off status.
Page 23
Firmware Version This version number is required when you request for service. Operating Time This indicates total hours that the monitor operated.
Error Message when USB Message when file on USB access or file not exist detected You can also use Serial Port and your PC to update the firmware. Please request for help to your local dealer or directly to BON Electronics.
External Remote Control Connecting GPI Port(RJ-45) Update Port (RJ-11) Update (RJ-11) Update Terminal Assignment 1 PIN 4 PIN 2 PIN 5 PIN 3 PIN 6 PIN * Turn power off first and connect update cable when you update monitor firmware. Remote Control / GPI Port Pin Assignments Remote (RJ-45) Remote PIN Assignment...
Page 26
Assignable functions are listed below. Function Name Description SDI-1 Input Switches the input to SDI-1 SDI-2 Input Switches the input to SDI-2 HDMI Input Switches the input to HDMI YPbPr Input Switches the input to YPbPr CVBS-1 Input Switches the input to CVBS-1 CVBS-2 Input Switches the input to CVBS-2 CVBS-3 Input...
Specifications BSM-182 i BSM-212 i BSM-242 i 2 x BNC HD/SD-SDI, 1.485G/270M 3 x BNC Analog(YPbPr/CVBS/S-Video/RGB) Input 1 x HDMI HDMI (with HDCP v.1.1), 19pin Female 1 x DVI DVI-I, 24pin, Female 3 x BNC Analog(YPbPr/CVBS/S-Video/RGB) Output 2 x BNC HD/SD-SDI, 1.485G/270M 1 x Phone Jack In Line In(Stereo)
Dimensions BSM-182i (WxHxD) 438.4 x 310.8 x 66.4mm (17.2 x 12.2 x 2.6 inches) BSM-212i (WxHxD) 505.6 x348.0 x 59.2mm (19.9 x 13.7 x 2.3 inches) BSM-242i (WxHxD) 553.4 x 403.5 x 62.5 mm (21.7 x 15.8 x 2.4 inches)
(Call for Service if the Symptom appeared more than 3 times) in startup process Screen is Black on Startup and there's neither BON Logo nor "No Reconnect the Power and Restart the Monitor. Signal" Display, but Buttons are (Call for Service if the Symptom appeared more than 3 times)
Page 32
Strange Color on BON Logo on Reconnect the Power and Restart the Monitor. Startup (Call for Service if the Symptom appeared more than 3 times) Make Monitor "Factory Default" and Try again. Select Test Pattern(Internal Pattern) in the menu and See if R,G,B Color is Correct.
• damage caused by service performed by anyone who is not an authorized service provider • damage to a product that has been modified or altered without the written permission of BON Service to be Charged If the product needs to be repaired after 12 months from the purchase.
Page 34
Corporate Headquarters Tresebelle-Sky 2F, 1479 Gayang-2, Gangseo-gu, Seoul, South Korea Research / Service Center Vision Tower 7F, 1481 Gayang-2, Gangseo-gu, Seoul, South Korea Telephone +82 2 2659 0333 +82 2 2659 8133 http://www.bon -electronics.com Email ales@bon-electronics.com...
