Multi-Format Broadcast Monitor
BXM-183L3G, BXM-243L3G,
BXM-243T3G, BXM-323L3G
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BXM-183L3G and is the answer not in the manual?

Questions and answers

Related Manuals for bon BXM-183L3G

Summary of Contents for bon BXM-183L3G

  • Page 1 Multi-Format Broadcast Monitor BXM-183L3G, BXM-243L3G, BXM-243T3G, BXM-323L3G User’s Guide...

  • Page 2: Table Of Contents

    Contents Safety Instructions........................3 Front............................4 Rear.............................6 MENU Description........................7 VIDEO............................8 DISPLAY 1..........................9 DISPLAY 2..........................10 DISPLAY3..........................12 COLOR.............................14 ADDITIONAL COLOR MENU for BXM-243T3G ...............15 MARKER..........................16 OSD............................18 AUDIO............................20 GPI............................22 SYSTEM...........................24 USB Firmware Update......................26 External Remote Control......................27 List of Compatible Video Formats (HDMI/Composite)............29 List of Compatible Video Formats (SDI)..................30 Specifications..........................32 Dimensions..........................35 Troubleshooting........................36...

  • Page 3: Safety Instructions

    Safety Instructions • To help avoid damaging your monitor, connect only one power (AC or DC) in operation. • Rough handling of product may cause physical damage or malfunction. • Never insert anything metallic into the monitor openings. Doing so may create the danger of electric shock.

  • Page 4: Front

    Front BXM-183L3G, 243L3G, 243T3G Front BXM-323L3G Front 1) Power (Standby) 2) HDMI/DVI Input 3) Analog Switches to an analog input in the order of CVBS1, CVBS2, CVBS3, SVIDEO, RGB, YpbPr, VGA by pressing the button. 4) WF/VS Displays Waveform or Vector Scope. The scope sizes such as normal size and...
  • Page 5 5) Audio Level Meters Display 6) Marker Displays a marker. Marker type can be selected on the Menu. 7) Function Keys User can assign a function on each function key on the Menu. 8) Enter Selection button on the Menu. 9) Scan Change scan mode in the order of Zero(Normal) Scan, Under Scan, Over Scan, and Pixel to Pixel.

  • Page 6: Rear

    Rear 1) AC Power 2) SDI Input 3) SDI Loop-Through Out 4) Component YPbPr/RGB or CVBS 1,2,3 Port 5) Component YPbPr/RGB or CVBS 1,2,3 Port Loop-Through Out 6) External Sync 7) External Sync Loop-Through Out 8) DVI 9) HDMI Port 10) Ethernet Port External control via PC is able with this port by using 'Wall Control Program'.

  • Page 7: Menu Description

    11) Update Port The Serial communication terminal that for changing the operating program(Firmware) of the body or controlling the monitor. 12) Remote Ethernet Port 13) USB Update Port 14) Audio In/Out Port MENU Description General Cautions for OSD menu or Display The menu may not be displayed even when user pressed Menu button if there's No Signal, or in unclear signal status.

  • Page 8: Video

    VIDEO Brightness, Contrast, Chroma, Phase, Sharpness Adjust color representation values. NTSC Setup Select IRE among 0 or 7.5 (Default) SDI Switching Normal : Use Normal in general condition but the screen might be blinking on screen change when you use Matrix or Routing Switcher. Fast : Use Fast to minimize blinking on screen change.

  • Page 9: Display 1

    DISPLAY 1 Aspect Set the aspect ratio of the screen. 16:9, 4:3, Native(Original) are selectable. Pixel to Pixel 1:1 Scan Set this on to display picture in 1:1 pixel mapping. Set this mode to set aspect ratio. SDI Mode Select Single Mode normally. Select Dual Mode for using two SDI(SDI1/SDI2) input ports for a single screen.

  • Page 10: Display 2

    DISPLAY 2 P&P MENU Displays two pictures in a screen in the way of Picture in Picture, Picture by Picture, or Blending. On its sub menu, user can select Main picture and Sub picture, and the position for Picture-in-Picture mode. Blending transparency can be adjusted when Blending selected.
  • Page 11 WF Intensity Adjust color saturation of the waveform between 0 to 63. WF & Vector Size Select size of Waveform or Vector Scope. WF & Vector Blend Adjust transparency of the scope. P&P Combination Table...

  • Page 12: Display3

    DISPLAY3 Exposure Range Check (Video Range Check) Checks Y, C level and displays over-exposed or under-exposed area on screen. The base value can be Y, Cb, or Cr. Y Range Max / Min Set Y range value for range check. C Range Max / Min Set C range value for range check.
  • Page 13 Focus Assist Display Turns on Focus Assist mode. This mode can be set also by pressing Focus Assist button in front. Focus Assist Level The sensitivity of the focus assist function can be set between 0 to 48. Focus Assist Color Set brush color of focus assist mode among Blue, Green, and Red.

  • Page 14: Color

    COLOR Color Temperature Select color temperature among 3200K, 5400K, 6500K, 9300K or USER. (Gain and Offset menu are displayed on USER temperature only) Red/Green/Blue Gain (USER mode only) R,G,B gains are adjustable on User mode. Red/Green/Blue Bias (USER mode only) R,G,B bias are adjustable on User mode.

  • Page 15: Additional Color Menu For Bxm-243T3G

    ADDITIONAL COLOR MENU for BXM-243T3G Gamma Select Gamma selectable between 2.2, 2.35, 2.6, DICOM, Adjust(User). The common value is 2.2. Color Space Select Color Space is selectable between Auto, NTSC, PAL/EBU3213, SMPTE-C/240M, BT.709(Rec.709), Native, Adjust(User). D-Cinema mode is also selectable but its color range is smaller than original D-Cinema.

  • Page 16: Marker

    MARKER Marker Ratio Select one of preset markers or user marker. To display marker, press Marker button in front of the monitor. Safety Area 16:9 Adjust size of the safety area when marker displayed on 16:9 screen. Safety Area 4:3 Adjust size of the safety area when marker displayed on 4:3 screen.
  • Page 17 User Marker H1 / User Marker H2 / User Marker V1 / User Marker V2 Set user marker’s position. H1 for left, H2 for right, V1 for top, V2 for bottom. The positions are saved as the selected marker name such as USER1.

  • Page 18: Osd

    Timecode Display On/Off Timecode Position Set the position of timecode. OSD Display Time Set menu display time (seconds) OSD Blend Set transparency of the menu. MENU Position Set menu position among Left Top, Right Top, Left Bottom, Right Bottom and Center.
  • Page 19 Captions. In special condition such as menu display status, captions are not displayed. The list of its sub menus are below. V-Chip SD-SDI, Composite signal might contain V-Chip data. Turn this mode on to display V-Chip information on screen. CC708 Service Select one of CC service as your preference.

  • Page 20: Audio

    AUDIO Audio Group Audio group can be assigned between 1 to 4. Play Channel L Select audio channel for left Play Channel R Select audio channel for right Level Meter Select Turns on/off audio level meters. Level Meter Size Select the size of the meters : Small or Large. Level Meter Position Select the position of the meters : Upper or Lower.
  • Page 21 3G Level B Audio Select one Audio source if 3G SDI is used, which has two audio sources. Speaker Source Select the speaker output among Auto / SDI / Line In. For HDMI, use Auto mode. Speaker Volume Set volume of speaker. Be noted that Line Out level won't be affected.

  • Page 22: Gpi

    GPI Control Turns on/off external monitor control function. GPI Port 1,2,3,4,5,6 Assigns each GPI port’s function. (e.g. SDI 1 input, HDMI input, Tally Red) See EXTERNAL REMOTE CONTROLLING section for details. Remote ID Number Assigns the ID for the monitor to control through serial port. 0 to 99 can be assigned.
  • Page 23 one. If you use a single monitor to control, you can leave it unchanged. MAC Address This address is unique address for each network device. User does not need to change it.

  • Page 24: System

    SYSTEM Function 1,2,3,4 Assigns a function to each function button. See FRONT section for detail. Backlight Set the backlight intensity from 0 to 40. An LCD panel requires more than 30 minutes to be settled to a new backlight value. Test Pattern Displays selected test pattern in 1080/30P.
  • Page 25 F/W Update Turns update mode on. Select Serial or USB port for update. After firmware update, the monitor should be turned off/turned on, and Factory Default should be loaded before use. Firmware Version This version number is required when you request for service. Operating Time This indicates total hours that the monitor operated.

  • Page 26: Usb Firmware Update

    Error Message when USB access Message when file on USB or file not exist detected You can also use Serial Port and your PC to update the firmware. Please request for help to your local dealer or directly to BON Electronics.

  • Page 27: External Remote Control

    External Remote Control Connecting GPI Port(RJ-45) Update Port (RJ-11) Update (RJ-11) Update Terminal Assignment 1 PIN 4 PIN 2 PIN 5 PIN 3 PIN 6 PIN * Turn power off first and connect update cable when you update monitor firmware. Remote Control / GPI Port Pin Assignments Remote (RJ-45) Remote PIN Assignment...
  • Page 28 Assignable functions are listed below. Function Name Description SDI-1 Input Switches the input to SDI-1 SDI-2 Input Switches the input to SDI-2 HDMI Input Switches the input to HDMI YPbPr Input Switches the input to YPbPr CVBS-1 Input Switches the input to CVBS-1 CVBS-2 Input Switches the input to CVBS-2 CVBS-3 Input...

  • Page 29: List Of Compatible Video Formats (Hdmi/Composite)

    List of Compatible Video Formats (VGA/DVI) The output resolution can be automatically changed in DVI by PC Graphic Card settings.

  • Page 30: List Of Compatible Video Formats (Sdi)

    List of Compatible Video Formats (SDI) The output resolution can be automatically changed in DVI. The input signal frame rate displayed on screen can be different. The edge of the picture might be cut by one or two lines on some modes.

  • Page 31: Specifications

    Specifications...

  • Page 34: Dimensions

    Dimensions BXM-183L3G 438 x 310 x 60 (mm) 17.3 x 12.2 x 2.3 (inch) BXM-243L3G 554 x 406 x 63 (mm) 22 x 16 x 2.5 (inch) BXM-243T3G 552 x 408 x 91 (mm) 21.7 x 16.0 x 3.5 (inch)

  • Page 35: Troubleshooting

    (Call for Service if the Symptom appeared more than 3 times) in startup process Screen is Black on Startup and there's neither BON Logo nor "No Reconnect the Power and Restart the Monitor. Signal" Display, but Buttons are (Call for Service if the Symptom appeared more than 3 times)
  • Page 36 Strange Color on BON Logo on Reconnect the Power and Restart the Monitor. Startup (Call for Service if the Symptom appeared more than 3 times) Make Monitor "Factory Default" and Try again. Select Test Pattern(Internal Pattern) in the menu and See if R,G,B Color is Correct.

  • Page 37: Warranty Information

    • damage caused by service performed by anyone who is not an authorized service provider • damage to a product that has been modified or altered without the written permission of BON Service to be Charged If the product needs to be repaired after 12 months from the purchase.
  • Page 38 Corporate Headquarters Tresebelle-Sky 2F, 1479 Gayang-2, Gangseo-gu, Seoul, South Korea Research / Service Center Vision Tower 7F, 1481 Gayang-2, Gangseo-gu, Seoul, South Korea Telephone +82 2 2659 0333 +82 2 2659 8133 http://www.bon.co.kr Email salesbon@bon.co.kr...

This manual is also suitable for:

Bxm-243l3gBxm-243t3gBxm-323l3g
