Specifications

[Specifications]
Imaging device
Total pixels
Effective pixels
Read out scanning
Minimum Illuminance
S/N ratio(Standard deviation)
Video output signal
Electronic shutter
Trigger input
Sync system
Gamma characteristic
Serial communication
Lens mount
Power supply
Operation ambient temperature
Storage temperature
Anti-shock
Anti-vibration
External dimension
Weight
Optical Filter
RoHS
Progressive scanning, interline transfer CCD, 1/3 inch in size
692 (H)×504(V)
659 (H)×494(V) square grid pattern
Horizontal scanning frequency:
Vertical scanning frequency:
Pixel clock frequency:
Digital 10 or 8 bit Camera Link
OFF, 1/2 to 1/100,000 sec (Variable at every H and CLK)
UART built-in asynchronous communication method 9600bps or 38400bps
C mount (flange back fixed)
Consumption: less than 1.8W
-5° C to 45° C; at Re lative humidity: 0 to 85% (No condensation)
-30° C to 65° C; at Relative hu midity: 0 to 90% (No condensation)
Acceleration 70G, half amplitude 6ms, 3 direction 3times each
20Hz to 200Hz to 20Hz (5min./cycle), Acceleration 10G, 3 direction 30 min. each
28(W) × 28(H) × 46.3(L) mm (excluding connector and tripod)
Approx. 43g (excluding tripod attachment)
- 33 -
f = 47.2028 KHz
H
f = 94.41 Hz
V
f = 36.818 MHz
CLK
1 Lx F1.4
@
≦ 10digit (GAIN 0dB)
via CC1
・
Internal
= 1 Fixed
γ
DC12V±10%, 100mA
No IR cut filter
RoHS Compliant
