CAMERA LINK FC300ACL Instruction Manual page 16

H'12: [ The camera operation mode setting 3 ]
MOD3 [7..0] This sets the following camera operation mode. The bit map in the register is as follows.
・D0-D2
= No Function =
・D3-D4
= Exposure Start Mode=
・D5
= Trigger-in connector selection =
0: Camera Link connector (CC1)
・D6-D7
= Output format =
H'13: [ The camera operation mode setting 4 ]
MOD4 [7..0] This sets the following camera operation mode. The bit map in the register is as follows.
・D0-D3
= External Sync Phase Adjust =
・D4-D6
= No Function =
Set always "000"
・D7
= Synchronizing signal Input selection =
H'14: [ The communication mode ]
UART [7..0]
・D0-D1
= Baud rate =
00: 38,400 bps
10,11: Setting disable
・D2-D7
= No Function =
H'20: [ The preset shutter speed setting by the H.]
SVR [7..0] H'20 and H'21 set the preset value for electronic shutter speed.
H'21: SVR[15..0] represents the setting value(in the H) of the shutter speed.
SVR [15..8] ＊The value is replaced by 4095 automatically when the value greater than 4095 is set.
The preset shutter speed is defined by the following formula.
Shutter speed = SVR[15...0] × (1H cycle time)+SHR[15...0] × (1CLK cycle time).
＊The exposure time is one frame time(No shutter) when both SVR and SHR are set at "0".
* The camera works with the minimum shutter speed when the value of SHR is set to 0 or between 1 and 306.
D[7..0]
D7 D6 D5
Set always "000"
00: Normal trigger 01: No function (Prohibited setting.).
10,11: H reset triggger
00: 10 bit 01: 8 bit 10 11: No function
D[7..0]
D7 D6 D5
0111: 7CLK 0110: 6CLK
0011: 3CLK 0010: 2CLK
1111:-1CLK 1110: -2CLK
1011:-5CLK 1010:-6CLK
0: Camera Link connector CC2: HD
1: 6 pin connector 2 pin: VD
D[7..0]
D7 D6 D5
01: 9,600 bps
Set always "000000"
D4 D3 D2 D1 D0
1: 6pin connector (No.2 Pin)
D4 D3 D2 D1 D0
0101: 5CLK 0100: 4CLK
0001: 1CLK 0000: 0CLK
1101:-3CLK 1100:-4CLK
1001:-7CLK 1000:-8CLK
CC3: VD
3 pin: HD
D4 D3 D2 D1 D0
