Page 1: Table Of Contents
6. How to change settings ………………………………………………… 15 7. Serial communication control ………………………………………………… 25 8. Timing chart ………………………………………………… 31 9. Note …………………………………………………35 10. Specifications ………………………………………………… 35 11. Dimensions ………………………………………………… 36 TAKENAKA SYSTEM CO., LTD. Document No. K11208a FC1600FCL Instruction Manual (7 Version) - 1 -...
Page 2 K11208a;2/36 [Revision history] Version Revised contents Articles Date Remarks Document No. version First edition- 2007-06-13 K07613 FC1600FCL Error correction K07613b version Error correction 2008-04-05 K08405 version Error correction Correction in External dimensions 2008-10-31 K08A30 version Error correction Correction of Initial setting and Group notation...
Page 3: Features
K11208a;3/36 1. Features FC1600FCL is a progressive scan camera incorporated with 1.45 megapixel, 2/3”-size CCD image sensor. ● A full frame shutter image can be obtained at a rate of 30 frames per second. ● 10 (or 8) bit format digital image signal output complying with Camera Link (Base Configuration).
Page 4: Description Of Each Component
K11208a;4/36 3. Description of Each Component Camera link connector Camera Link (3-1) Description of rear panel of camera Shutter switch Panel to set up operation mode, electronic shutter speed and other Mode switch MODE EXP. parameters and to connect each output connector POWER Operation (3-2) Camera connector (HRS HR10A-10R-12PB)
Page 5 K11208a;5/36 [Table of Camera Link bit assignment] (showing correspondence relation between before and after encoding) Camera Link port Camera signal Remark (Node name) name Strobe Pixel clock LVAL Horizontal synchronous timing FVAL Vertical synchronous timing DVAL (Fixed to H level) Spare (Fixed to H level) PORTA0 / PORTB0...
Page 6: How To Operate
K11208a;6/36 4. How to Operate (4-1) Connection method ● Connection Refer to the connection example between the camera and peripheral devices (Fig. 4-1). (1) Remove the cover of the lens attachment section and attach a lens (option). FC Camera Camera Link cable (2) Connect the camera head to a power supply unit (option) with a camera cable (option).
Page 7 K11208a;7/36 (4-2) Input of Vinit signal (asynchronous trigger signal) ● How to input Vinit signal If the camera is used in the asynchronous shutter mode, the Vinit signal (asynchronous trigger signal) must be input from the user side unit. The Vinit signal is input from Pin (6) of the “POWER” connector (12 pin connector) on the rear of the camera, or is input as the CC1 signal from the “Camera Link”...
Page 8 K11208a;8/36 ● Example of drive circuit for Vinit1 input circuit Inside of camera Vinit1 IN 3.3V [Example of user circuit] 3.3V TC74LVX14 4.7k VC C (or equivalent) Camera connector 74AC04 or To internal circuit 3.9 ZD others NORMAL VCC is +5V or +3V CC1 (Vinit2) input Setting of Vinit2 polarity INVERTED...
Page 9 K11208a;9/36 Example of external sync input circuit and drive circuit ● In side the c amera Example of user circ uit 3.3V 3.3 V Camera ＶＣＣ c onnector １０Ｋ 74AC04 or ７５Ω 22µ F Ext-VD ４．７ＫＴ...
Page 10 K11208a;10/36 (Note) A numerical value of 1 is incrementally added for every horizontal pixel in the range of 0 to 1023 for the case of 10bits output and 0 to 255 for the case of 8 bits output. (Note) The value does not start with 0 at the edge of the effective image area. (Note) The output values of the test pattern are not affected by the values of the gain setting or offset setting of the camera.
Page 11 K11208a;11/36 [Explanation] Example of conversion algorithm from data in the complement number system to signed data The following example shows how to convert 10 digit data in the complement number system into ordinary signed data: (1) Whether the value is positive or negative is determined by checking the uppermost bit (MSB) out of the 10 digit number.
Page 12: Various Settings
K11208a;12/36 5. Various Settings (5-1) Operation mode Electroni c shutter operation mode ● CCD output Single output Shutter ・・・・・ swi tch = 0 Shutter switch = 1 to 9 (Single line output) No shutter Elec tr onic shutter ● Electronic shutter operation mode oper ation operation Shutter mode...
Page 13 → Refer to the next section (Section 6) for the specific setting method. (!) Since FC1600FCL is equipped with the independent shutter setting switch and mode setting switch, it does not require the setting manipulation for the current shutter speed unlike the FC20 series products.
Page 14 K11208a;14/36 The MGC setting value of this equipment is controlled by giving 24 to 224. The correlation between this setting value and the MGC gain (integrated gain including the gain of the variable gain amplifier and that of the fixed gain amplifier) is shown in the right graph.
Page 15: How To Change Settings
K11208a;15/36 (6-1) How to set shutter speed The shutter speed is determined mainly by the setting positions of the shutter switch from “0” to “9”. Table 6-1 Setting value of shutter speed Position of High speed shutter (continuous/asynchronous) Low speed shutter (continuous) shutter switch No shutter (continuous) (1/30 sec)
Page 16 K11208a;16/36 (Note) When any setting item is changed, it must be saved in one of the program pages from “A” to “F” before turning off the power to store the data in the memory of the camera. Carefully note that the new setting is not automatically saved and that the prior setting will be effective at the next time of power-on if the power is turned off before storing it.
Page 17 K11208a;17/36 UP/DOWN switch Position of Item to be changed mode switch UP position DOWN position Menu display (MENU) <* C> Test pattern (PATTERN) <* C> Output bit (BIT) <* C> 10bit 8bit 4 to 7 (Not used) ( - ) * Notes in common with all setting groups (Note) The standard factory mode (default) is underlined.
Page 18 MF=0000.0001 MENU: Current menu status is displayed. When the menu is being displayed, “ON” is kept displayed. FC1600FCL [VX.XX] When “(CYCLIC)” is displayed on the right, the camera is cyclically outputting the asynchronous shutter image using the internal Menu display of Setting Group 1 trigger to refresh the image.
Page 19 MS=A SS=7 MF=0008.0000 PWC: Whether the position “9” of the shutter switch for the asynchronous FC1600FCL [VX.XX] shutter operation is used (ENABLED) or not used (DISABLED) is selected. Menu display of Setting Group 2 This is to switch between (ON) and (OFF) for the confirmation sound to be activated when switch manipulation is made.
Page 20 K11208a;20/36 [ID information display] The ID code and other information set by the user for each camera can be saved in the camera (with the use of the serial communication). The settable maximum number of characters are 15, and alphanumeric characters (both upper and lower cases) and some special symbols such as”+”...
Page 21 K11208a;21/36 [Description of CR data] Abbrev. Content Logic Remark MENU Disabled display of menu screen 1: Disabled (OFF) Disabled buzzer output 1: Disabled (OFF) PATTERN ON/OFF selection for test pattern 1: Test pattern ON Selection of output data format 1: 8bit format 0: 10bit format (Not used) (Not used)
Page 22 K11208a;22/36 (6-7) Description of scan mode and functional limitation ● Description of scan mode This camera has the following 2 scan modes which are selectable by setting: Scan mode Operation Frame rate Normal scan mode (NORMAL) Readout of all 1.45 megapixels 30fps Partial scan mode (PARTIAL) Read out of approx.
Page 23 K11208a;23/36 (6-8) Typical setting procedure (Example 1) This is the procedure for setting the gain for the START asynchronous shutter operation (1/250 sec.). Turn on power. [Explanation] Be ready for switching between The left example of the setting procedure is for using the Set mode switch to “5”.
Page 24 K11208a;24/36 Read out of factory default (6-9) Setting items to be read out to RAM This procedure is for reading out the factory default (initial setting [Electronic shutter operation mode] before shipment) in order to initialize the setting that was changed •...
Page 25: Serial Communication Control
STX: ACK: “R”: MGC setting value: AGC setting value: (VRT setting value): (VRB setting value): OFFSET setting value: ETX (!) FC1600FCL does not use the values in parentheses. This camera returns the fixed values instead. 2) Camera version report Transmission from host: STX: “R”: “V”: ETX Return by camera: STX: ACK: “R”:...
Page 26 K11208a;26/36 4) Shutter mode report Transmission from host: STX: “R”: “S”: ETX □ □ □ Return by camera: STX: ACK: “R”: “ ” * : “ ” * : “ ” * : Exposure time * : ETX 1 to 3 : Refer to (4) command “S”...
Page 27 STX: ACK: ETX (transaction completion), or STX: NAK: ETX (transaction rejection) The factory default is stored in the Page H, which will be used when resetting to the default setting. <The following commands are exclusively for FC1600FCL, and not common with other FC cameras.> (9) Command “WMC”...
Page 28 K11208a;28/36 (12) Command “RMF” Function: Command for reading mode flag register (FR) (Read Mode Flag) Transmission from host: STX: “RMF”: ETX Return by camera: STX: ACK: “RMF”: flag setting value: ETX (transaction completion), or STX: NAK: ETX (transaction rejection) The current content of the mode flag register (2 bytes/4 characters) is returned in the hexadecimal system. (13) Command “SMC”...
Page 29 STX: ACK: ETX (transaction completion), or STX: NAK: ETX (transaction rejection) (!) FC1600FCL does not use the values in parentheses. Transmit “00” to this camera. A 2 digit ASCII code from “00” to “FF” in the hexadecimal system is used for the MGC setting value.
Page 30 K11208a;30/36 Example) If level 90 (decimal) is set: “5A” Example) If level 90 (decimal) is set as a MGC setting value. STX: “WMG”: “5A”: “00”: ETX (25) Command “ROF” Function: Command for reading offset (Read OFFSET) Transmission from host: STX: “ROF”: ETX Return by camera: STX: ACK: “ROF”: OFFSET setting value: (OFFSETB setting (right screen)): ETX (26) Command “WOF”...
Page 31: Timing Chart
8 or 10 bit x 2 tap output is employed for FC1600FCL. Therefore, there is no compatibility with the conventional parallel type camera FC2000CL etc. and so dedicated setting files are required.
Page 32 K11208a;32/36 ● Vertical timing: Continuous shutter １Ve rti cal dur ati on （１Ｖ）＝１fram e t ime １０６８；Nor mal sc an ９５３４；Par tia l s can ＶＤ（ I nter na lv ertica l synch signa l ）...
Page 33 K11208a;33/36 ● Vertical timing: High speed/pulse width control/asynchronous shutter/normal scan ｍＶｉｎｉｔＨＤ (I n te r n al ho rizon tal ） synch sign al (SG) End of expos ure （ｍＨ） E xpos uretim e （ｍＨ） E xposure time ＳＴＲ...
Page 34 K11208a;34/36 ● Vertical timing: High speed/preset shutter/asynchronous shutter/normal scan/with H-reset Ｖｉｎｉｔ４２～４３ＣＬＫＨＤ (I n te r n al ho rizon tal sync signa l) End fo exposure(SG) １０２ＣＬＫ Exposure time（ｎＨ） Exposure period（ｎＨ）...
Page 35: Note
K11208a;35/36 9. Notes ● More stable image (suitable for highly accurate measurement) can be obtained by leaving the equipment for 20 or 30 minutes after the power is turned on. ● A longer exposure time in the pulse width control mode is accompanied by the degradation of S/N ratio due to a decrease in the dynamic range of CCD, accumulation of thermal noise components of the CCD imager device in proportion to the exposure time.
Page 36: External Dimensions
C am e r a L i nk EXP. M O DE PO W ER ２×２－Ｍ３ Depth６（Right and left sides） M3 Depth４２×２－Ｍ３ Depth 6 （Same as top side）２－Ｍ６ Depth７１／４”－２０ＵＮＣ Depth７ 13 .5 Fig.11-1 FC1600FCL external views - 36 -...
