(6-4) Descriptions of the Camera Control Commands
Command No.
(Hexadecimal number)
H'0E: [The factory adjusted value for the digital gain for back up]
DGB_BK[7..0] Back up data for recovery of factory adjusted digital gain value (command No.H'31)
H'0F: [The factory adjusted value for the gain offset for back up]
GOFS_BK[7..0] Back up data for recovery of factory adjusted gain offset (command No.H'32)
H'10: [ The camera operation mode setting 1 ]
This sets the following camera operation mode. The bit map in the register is as follows.
MOD1 [7..0]
・D0-D2
= V Reset Mode =
・D3
= Blanking compression =
・D4
= Binning scan (2-lines addition mode)=
・D5
= Asynchronous shutter =
・D6
= Trigger polarity
・D7
= Low speed shutter =
H'11: [ The camera operation mode setting 2 ]
This sets the following camera operation mode. The bit map in the register is as follows.
MOD2 [7..0]
・D0-D2
= Partial scanning =
・D3
= Normal / Trigger manual select =
・D4-D6
= Frame rate =
・D7
= Synchronizing signal I/O =
米
1] (Low speed shutter).
D[7..0]
D7 D6 D5
000: V Reset ON
001: V Reset OFF
010-111: No Function (Prohibited setting. Do not set these values.)
0: OFF 1: ON
0: OFF 1: ON
0: Preset shutter 1: Pulse width control
0: Positive 1: Negative
0: OFF 1: ON
D[7..0]
D7 D6 D5
000: Normal scan 010: 1/4 partial scan
001: 1/2 partial scan 111: Variable partial scan
0: Trigger 1: Normal
1
米
00: 60 fps 01: 90 fps
10: 30 fps 11: 60 fps
0: VD/HD in 1: VD/HD out
Normal / Trigger manual select becomes effective when setting MOD1(D7) =1 at [Camera operation mode setting
1
Command Descriptions
D4 D3 D2 D1 D0
D4 D3 D2 D1 D0
