1.

Features

The full frame shutter camera incorporated with 3.2 megapixel, 1/3"-size CCD image sensor.
●
The smear noise in high speed shutter mode is extremely reduced compared to existing cameras by adopting the
●
newly-designed Interline-transfer CCD.
The 10-bit video signal is output in progressive scanning format (non-interlaced scanning) complying with Camera Link
●
standard (Base configuration).
The camera is reset in random timing (Asynchronous timing) whenever the external trigger signal is input, and the
●
electronic shutter image is captured at any given point in time. (Asynchronous shutter mode)
Capable of applying asynchronous trigger signal and implementing serial communication (note↓) via Camera Link
●
other than transmitting image data,
Small and lightweight camera with the size of 28(W)
●
FC300ACL is a monochrome camera and FS300ACL is a color camera(Bayer, RAW output).
●
FS300ACL is not equipped with a IR cutoff filter. If there is abnormality in a color tone under a influence of IR light, set a
※
IR cutoff filter on a lens, .
(Note) Each function of applying asynchronous trigger signal or implementing serial communication via Camera Link is available
only when CameraLink-compliant image capture board supports them.
2.

Outline

(2-1) Essential particular
Imaging device
Total pixels
Effective pixels
Horizontal
Read out
Vertical
scanning
Clock
Electronic shutter
Video output signal
Scanning mode
※1:The data on the list are for the case of 90fps. It is set to 60fps as the factory default.
１ ． ０
０ ． ９
０ ． ８
０ ． ７
０ ． ６
０ ． ５
０ ． ４
０ ． ３
０ ． ２
０ ． １
０ ． ０
４ ０ ０ ５ ０ ０
Progressive scanning, Interline transfer
1/3 inch
692(H) 504(V) approx.0.35 megapixels
×
648(H) 494(V) approx.0.32 megapixels
×
47.2028 kHz
94.41 Hz
※
36.818 MHz
～
1/100,000 1/2 sec.
(Continuous shutter / Asynchronous shutter)
Digital 10bit
Complied with Camera Link (Base Configuration)
Normal scan for all pixels (90fps)
1/2 partial scan
1/4 partial scan
Variable partial scan
Binning scan (2-lines addition mode
（ T y p i c a l v a l u e ）
６ ０ ０ ７ ０ ０ ８ ０ ０
Wavelength(nm)
ＦＣ３００ＡＣＬ
Typical spectral sensitivity
28(H) 46.3(L).
× ×
Ｇ
Ｒ
Ｇ Ｂ
※Color
coding
1
※
1
Ｖ
1
※
２
※ On l y f or F S 30 0 AC L
(120fps)
(360fps)
１ ． ０
０ ． ９
０ ． ８
０ ． ７
０ ． ６
０ ． ５
０ ． ４
０ ． ３
０ ． ２
０ ． １
０ ． ０
９ ０ ０ １ ０ ０ ０ ４ ０ ０
- 3 -
OB(Optical black)
Ef f ecti ve i mage pi ckup area
６５９
Ｈ
４ ５ ０ ５ ０ ０ ５ ５ ０
ＦＳ３００ＡＣＬ
N10316;3/36
２
４ ９４
８
３１
（ T y p i c a l v a l u e ）
６ ０ ０ ６ ５ ０ ７ ０ ０
Wavelength(nm)
