Installation/Owner's Manual
Use this manual for circuit board 4100-010 Revision AA or higher.
EXTERNAL ENTRAPMENT PROTECTION MUST be
installed or the gate operator WILL NOT function.
AC Powered
Date Installed:
Installer/Company Name:
Phone Number:
Leave Manual with Owner
UL 325 Compliant
Model 9024-080
Model 9024-080
Model 9024-080
AC Powered Vehicular Slide Gate Operator
Circuit Board
Serial Number
and Revision Letter:
Copyright 2016 DoorKing, Inc. All rights reserved.
For Solar Power, See 9024-066 Solar Manual
AC Powered
Copyright 2009 DoorKing, Inc. All rights reserved.
9024-065-Q-8-16
