- Page 1 Owner’s Manual P/N 9310-065 Rev D 5/05 Copyright 2003 DoorKing, Inc. All rights reserved. Model 9310 Vehicular Slide Gate Operator DoorKing, Inc. 120 Glasgow Avenue Inglewood, California 90301 Phone: 310-645-0023 Fax: 310-641-1586 www.doorking.com U.S.A.
- Page 3 Use this manual with the following models only. All 9310 models with circuit board 4403-010. IMPORTANT! The 4403 circuit board used in the model 9310 IS NOT interchangeable with the 4402 circuit board used in the earlier model 9300 operators.
-
Page 4: Quick Start
QUICK START Mount operator to pad using 3/8 or 1/2 sleeve anchors. See page 14-15. Attach chain. Adjust chain to allow approximately 1-inch of sag per 10-feet of gate width. Be sure to remove the pin from the breather plug. See page 16-17. - Page 5 1 DIRECTION 2 TIMER LIMIT SWITCH 9406 CONNECTOR EXIT LOOP POWER REV SENS OPEN 9406 REVERSE LOOP REVERSE LOOP EXIT LOOP TIMER Secondary Entrapment Protection Devices TIME DELAY REV SENS CLOSE RELAY CONTACT Current Sensor Donut Volt-Ph Turns Sgl Ph 208-3 230-3 460-3...
-
Page 6: Table Of Contents
TABLE OF CONTENTS Important Notices...8 Important Safety Instructions ...9 Restrictions and Warnings...10 Entrapment Prevention ...11 Glossary ...12 Section 1 – Installation Specifications ...13 Concrete Pad...14 Operator Installation ...15 Chain Installation ...16 Front Mount Installation ...17 Rear Mount Installation...18 Warning Sign Installation...19 Section 2 –... - Page 7 Section 4 – Operating Instructions Power and Reset Switches ...39 Shutdown Conditions ...40 Soft Shutdown ...40 Resetting a Soft Shutdown ...40 Hard Shutdown...41 Resetting a Hard Shutdown ...41 Manual / Emergency Gate Operation...42 Section 5 – Maintenance and Troubleshooting Maintenance Schedule ...45 Operator Diagnostics...46 Trouble Shooting ...47 ½...
-
Page 8: Important Notices
IMPORTANT NOTICES Vehicular gate systems provide convenience to their users and limit vehicular traffic onto your property. These systems can produce high levels of force; therefore it is important that you are aware of possible hazards associated with your gate operating system. These hazards may include pinch points, entrapment, absence of controlled pedestrian access or traffic backup. -
Page 9: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING - To reduce the risk of injury or death: 1. READ AND FOLLOW ALL INSTRUCTIONS. 2. Never let children operate or play with gate controls. Keep the remote control away from children. 3. Always keep people and objects away from gate. NO ONE SHOULD CROSS THE PATH OF THE MOVING GATE. -
Page 10: Restrictions And Warnings
RESTRICTIONS AND WARNINGS Install The Gate Operator Only If: • The operator is appropriate for the usage Class of the application and the gate is within the weight and length limitations specified for the operator. • All openings of a horizontal slide gate are guarded or screened from the bottom of the gate to a minimum of 4 feet (1.2 m) above the ground to prevent a 2 ¼... -
Page 11: External Entrapment Prevention
ENTRAPMENT PREVENTION This vehicular gate operator is equipped with an inherent (Type A) entrapment sensing system. This system will sense an obstruction in both the opening and closing gate cycles, and will cause the gate to reverse direction should an obstruction be encountered. If the system detects a second obstruction before reaching the full open or close limit after the initial reversal, an alarm will activate and the operator will require a reset before resuming normal operation. -
Page 12: Glossary
GLOSSARY GATE – A moving barrier such as a swinging, sliding, raising, lowering, or the like, barrier, that is a stand-alone passage barrier or is that portion of a wall or fence system that controls entrance and/or egress by persons or vehicles and completes the perimeter of a defined area. RESIDENTIAL VEHICULAR GATE OPERATOR-CLASS I - A vehicular gate operator (or system) intended for use in a home of one-to four single family dwelling, or garage or parking area associated therewith. -
Page 13: Section 1 - Installation
SECTION 1 - INSTALLATION Prior to beginning the installation of the slide gate operator, we suggest that you become familiar with the instructions, illustrations, and wiring guide-lines in this manual. This will help insure that your installation is performed in an efficient and professional manner. The proper installation of the vehicular slide gate operator is an extremely important and integral part of the overall access control system. -
Page 14: Concrete Pad
Concrete Pad The model 9310 vehicular gate operator is designed to be mounted on a concrete pad. 1. Construct a form for the mounting pad according to the specifications shown below. Note that the pad for the 1 HP operator extends an additional 6 inches to the right to accommodate the larger cover. -
Page 15: Operator Installation
Operator Installation • Position the operator on the pad so that there is a minimum clearance of one (1) inch between the back of the operator housing and the gate. • IMPORTANT!! Be sure that the operator is parallel to the gate! operator in any other manner will cause excessive chain noise, chain wear and stretching, and premature idler failure. -
Page 16: Chain Installation
Chain Installation 1. Secure the chain brackets to each end of the gate so that the brackets are level with the top chain cutouts in the operator housing. Brackets should be attached to the inside of the frame so that the chain bolts, when attached, do not protrude beyond the frame of the gate. -
Page 17: Front Mount Installation
Front Mount Installation REMOVE BREATHER PLUG PIN CONCRETE PAD GROUND LEVEL... -
Page 18: Rear Mount Installation
Rear Mount REMOVE BREATHER PLUG PIN CONCRETE PAD GROUND LEVEL Gate Brackets Idler Assembly P/N 2600-818... -
Page 19: 1.7 Warning Sign Installation
1.7 Warning Sign Installation This DoorKing slide gate operator is shipped with two warning signs. The purpose of the warning signs is to alert uninformed persons, and to remind persons familiar with the system, that a potential hazard may exist so that appropriate action can be taken to avoid the hazard or to reduce exposure to the hazard. -
Page 21: Section 2 - Wiring
Before attempting to connect any wiring to the operator, be sure that the circuit breaker in the electrical panel is in the OFF position. A separate power disconnect must be installed at the operator location. Permanent wiring must be installed to the operator as required by local electrical codes. -
Page 22: High Voltage Connections
High Voltage Connections Use Table 1 to determine high voltage wire size requirements. The distance shown in the chart is measured in feet from the operator to the power source. If power wiring is greater than the maximum distance shown, it is recommended that a service feeder be installed. A separate power disconnect must be installed at the operator. -
Page 23: 2.3 Control Wiring
2.3 Control Wiring Controls must be far enough from the gate so that the user is prevented from coming in contact with the gate while operating the controls. Outdoor or easily accessible controls should have a security feature to prevent unauthorized use. •... -
Page 24: Secondary Entrapment Non-Contact Sensors
Secondary Entrapment Non-Contact Sensors • Before connecting non-contact or contact sensors, refer to page 32 for operational description of these sensors. • Disconnect power to the gate operator before installing the non-contact sensors. • See diagram below for suggested placement of sensors. (Diagram is for illustration purposes only. -
Page 25: Secondary Entrapment Contact Sensors
Contact Sensors • Before connecting non-contact or contact sensors, refer to page 32 for operational description of these sensors. • Disconnect power to the gate operator before installing the contact sensors. • Connect the contact sensors as shown below to the auxiliary terminal strip located on the 4403 control board. -
Page 26: Loop Detectors
EXIT LOOP REVERSE LOOP REVERSE LOOP Reverse loops are wired in series! Loop Detector P/N 9406-010 Exit Loop Detector P/N 9406-010 Reverse DOORKING, INC., INGLEWOOD, CA 90301 Title: Loop and Loop Detector Wiring 9310 Operator Date: 9/03 Dwg. No. M9310-065-4 Rev. -
Page 27: Gate Tracker™ Connections
Gate Tracker This gate operator is equipped with outputs from the circuit board that will report operator status to a companion DoorKing Access Control System (Model 1833, 1835, 1837 or 1838) when equipped with an optional Tracker expansion board. This report includes items such as gate operator cycle count, any shorted inputs, loop detector problems, any attempts to force the gate open, if the gate has struck anything during the open or close cycle, power interruptions, etc. -
Page 28: Alarm Reset Switch
Alarm Reset Switch The gate operator is equipped with a built-in reset switch that will silence the entrapment alarm and return the operator to normal operation after a hard shutdown occurs. An auxiliary reset button may be added provided that the following condition is met. •... -
Page 29: Master / Slave Wiring Interface
2.10 Master / Slave Wiring The interface wiring between the two operators requires four (4) 18 AWG wires for control. Each operator must be connected to it's own power source as described in section 2.2. Be sure that both operators are wired to the same phase in the breaker panel. measuring voltage from HOT to HOT. -
Page 30: Secondary Entrapment Protection For Master / Slave Configuration
2.11 Secondary Entrapment Protection for Master / Slave Configuration Secondary entrapment protection for slide gate operators connected in a master / slave configuration will require three sets of photo-beams to insure protection. • One photo-beam is directed across the roadway and connected to the CLOSE photo-beam input on the auxiliary terminal strip of both the master and slave operator. -
Page 31: Terminal Identification And Description
2.12 Main Terminal (P1) Description 24 VOLT COMMON Same as terminal 13. OPEN / RADIO RELAY Functions same as terminal 4. 24 VOLT RADIO POWER FULL OPEN / CLOSE INPUT When gate is closed, input will open gate to full position. When gate is open and auto close timer is turned on, input will re-set and hold timer. -
Page 32: Secondary Device Terminal Description
2.13 Secondary Device Terminal (P3) External entrapment prevention devices are connected here. 1. OPEN PHOTO-BEAM This input is only active when the gate is in the opening cycle. An open photo-beam input during the opening cycle will cause the gate to stop. The gate will remain stopped until the photo-beam input is cleared, at which time the gate will resume the open cycle. -
Page 33: Section 3 - Adjustments
SECTION 3 - ADJUSTMENTS The switch settings and adjustments in this chapter should be made after your installation and wiring to the operator(s) is complete. Whenever any of the programming switches on the circuit board are changed, power must be shut-off, and then turned back on for the new setting to take effect. Circuit Board Adjustments •... -
Page 34: Switch Settings
Switch Settings The two DIP-switches located on the circuit board are used to program the operator to operate in various modes and to turn on or off various operating features. changed, power to the operator must be turned OFF and then turned back on for the new setting to take affect. -
Page 35: Programming Switch Description And Function
Switch 3: Sets the circuit board to function with slide gate operators (switch OFF) or overhead gate operators (switch ON). This switch must be left in the OFF position for model 9310 Slide Gate Operator. Switch 4: This switch should be left in the OFF position when the slide gate is running on a level or small incline track and the gate does not coast. -
Page 36: Limit Switch Adjustment
IMPORTANT! 3-Phase Power Limit Switch Test This test MUST be performed if the 9310 is powered from a 3-phase power source. Activate the operator and watch the limit nut movement. Manually activate the limit switch that the limit nut is moving towards. If the operator does not shut off, immediately turn the operator power off and shut off power at the breaker panel. -
Page 37: Reverse Sensitivity Adjustment
Reverse Sensitivity Adjustment This vehicular gate operator is equipped with an inherent (Type A) entrapment sensing system. This system will sense an obstruction in either the opening or closing gate cycles and will cause the gate to reverse direction should an obstruction be encountered. For this system to function correctly, the gate must be properly installed and work freely in both directions. -
Page 39: Section 4 - Operating Instructions
SECTION 4 – OPERATING INSTRUCTIONS WARNING - To reduce the risk of injury or death: READ AND FOLLOW ALL INSTRUCTIONS. Never let children operate or play with gate controls. Keep the remote control away from children. Always keep people and objects away from gate. NO ONE SHOULD CROSS THE PATH OF THE MOVING GATE Test the operator monthly. -
Page 40: Shutdown Conditions
Shutdown Conditions Under various entrapment conditions the operator will assume either a soft or hard shutdown (alarm) condition. To determine what type of reset action is required, you will need to understand how the different entrapment conditions affect the gate operator. Soft Shutdown This occurs in various situations where the inherent or secondary entrapment protection devices have been activated. -
Page 41: Hard Shutdown
Hard Shutdown A hard shutdown condition occurs when the inherent entrapment protection system has sensed two consecutive obstructions before the gate reaches the full open or full closed position. It can also be an indication that the gate is too heavy or that the gate hardware (wheels, rollers) is in poor condition and needs to be corrected. -
Page 42: Manual / Emergency Gate Operation
Manual Gate Operation This operator is equipped with a manual release system that will allow the gate to be pushed open in the event of a power outage or equipment failure. There are two manual release systems that are available on this gate operator. The standard type release is the FAIL-SAFE system (required by many city codes), while an optional release is the FAIL-SECURE system. - Page 43 Fail-Secure Manual Operation The FAIL-SECURE option locks the gate when primary (AC) power is removed and requires a keyed release to place the gate in manual operation. The FAIL-SECURE option is typically used in CLASS III and CLASS IV applications. •...
-
Page 45: Section 5 - Maintenance And Troubleshooting
SECTION 5 – MAINTENANCE AND TROUBLESHOOTING Inspection and service of this gate operator by a qualified technician should be performed anytime a malfunction is observed or suspected. High cycle usage may require more frequent service checks. Maintenance When servicing the gate operator, always check any secondary (external) reversing devices (loops, photo eyes, etc.) for proper operation. -
Page 46: Operator Diagnostics
Operator Diagnostics This gate operator is designed with built-in diagnostics that will alert you to potential or existing problems that the microprocessor has detected. operator will signal that a fault exist through the built-in alarm. Constant tone is heard when power is applied: •... -
Page 47: Trouble Shooting
Trouble Shooting Have a good VOM meter to check voltages and continuity. A Meg-Ohm meter capable of checking up to 500 meg-ohms of resistance is necessary to properly check the integrity of the ground loops. When a malfunction occurs, isolate the problem to one of three areas: 1) the operator, 2) the loop system, 3) the keying devices. - Page 48 • Disconnect the gate from the gate operator and check that the gate slides freely without Gate opens a short any binding. distance, then • stops and reverses. Re-adjust the open reverse sensitivity. • Replace the circuit board. • Check the input LEDs. Any ON will hold the gate open and indicates a problem with a Gate opens but will keying device.
-
Page 49: ½ Hp 115 Vac Wire Diagram
Blue White White Black Black Operator Power Black 115 VAC DOORKING, INC., INGLEWOOD, CA 90301 White Input Title: Model 9310 Wire Diagram Green ½ HP 115 VAC Date: 5/05 Dwg. No. Alarm Alarm Reset Solenoid 115 VAC Convenience Outlets White... -
Page 50: Circuit Board
White 115 VAC Convenience Outlets White Black White Black For 3 Phase power input, use 2 power legs and cap the third. DOORKING, INC., INGLEWOOD, CA 90301 Model 9310 Wire Diagram ½ HP 208/230/460 VAC 5/05 Dwg. No. 4403-05-202346 Rev. -
Page 51: Hp 115 Vac Wire Diagram
460 - 3 Blue White White Black Black Operator Power Black 115 VAC DOORKING, INC., INGLEWOOD, CA 90301 White Input Title: Model 9310 Wire Diagram Green 1 HP 115 VAC Date: 5/05 Alarm Alarm Reset White Yellow Solenoid Black White 115 VAC... -
Page 52: Single Phase Input
Input Green Title: Date: Alarm Alarm Reset White Yellow Solenoid Black White 115 VAC Convenience Outlets White Black White Black DOORKING, INC., INGLEWOOD, CA 90301 Model 9310 Wire Diagram 1 HP 208/230 VAC Single Phase 5/05 Dwg. No. 4403-1-2023-1 Rev. -
Page 53: Hp 208/230/460 Vac Three Phase Wire Diagram
Three Phase Black Input Green Title: Date: Alarm Alarm Reset White Yellow Solenoid Black White 115 VAC Convenience Outlets White Black DOORKING, INC., INGLEWOOD, CA 90301 Model 9310 Wire Diagram 1 HP 208/230/460 VAC Three-Phase 5/05 Dwg. No. 4403-1-202346-3 Rev. -
Page 54: Accessories
Accessories The following accessory items can be used with the model 9310 slide gate operator. Contact Sensor Contact sensors for use as a secondary entrapment protection device. Miller Edge, Inc. ME120, ME123, MG020, MGR20, MGS20 Photo Cell Non-contact (photo cells) sensors for use as a secondary entrapment protection device.
