- Page 1 Model 9050 Model 9050 Model 9050 Installation/Owner’s Manual Vehicular Slide Gate Operator Use this manual for circuit board 4702-010 Revision A or higher. 9050-065-P-9-11 V I N e ra d fr ll o e ra a re il d tr u a is te .
-
Page 3: Specifications
Vehicular Slide Gates Only Horsepower 1/2 HP Voltage / Phase 115 VAC Single-Phase Use this manual for the Model 9050 Current 4.3 Amps @ 120V operator with circuit board 4702-010 Rev A or higher ONLY. Max Gate Weight (Installed level) 300 Lbs. -
Page 4: Table Of Contents
1.7 Mounting Operator and Chain 17-18 1.8 Installation of Warning Signs SECTION 2 - AC POWER TO OPERATOR(S) 2.1 High Voltage Wire Runs 2.2 High Voltage Terminal Connection SECTION 3 - ADJUSTMENTS 3.1 4702 Circuit Board Description and Adjustments 3.2 DIP-Switch Settings 9050-065-P-9-11... - Page 5 6.3 Manual Gate Operation 33-34 Fail-Safe Manual Release System (Factory Installed) Fail-Secure Manual Release System (Owner Installed) Emergency Vehicle Access Conditions SECTION 7 - MAINTENANCE AND TROUBLESHOOTING 7.1 Maintenance 7.2 Troubleshooting 36-37 7.3 Accessory Items Model 9050 Wiring Diagram 9050-065-P-9-11...
-
Page 6: Astm 2200 Standard For Gate Construction
2. Care shall be exercised to reduce the risk of nuisance tripping, such as when a vehicle trips the sensor while the gate is still moving in the opening direction. 3. One or more non-contact sensors shall be located where the risk of entrapment or obstruction exist, such as the perimeter reachable by a moving gate or barrier. 9050-065-P-9-11... -
Page 7: Important Notices
Do not allow children to play in the area of the operator or to play with any gate-operating device. • To remove the gate operator from service, operate the gate to the full open position and then shut off power to the operator at the service panel. 9050-065-P-9-11... -
Page 8: Ul325 Entrapment Protection
C - Inherent adjustable clutch or pressure relief device. D - Provision for connection of, or supplied with, an actuating device requiring continuous pressure to maintain opening or closing motion of the gate. E - An inherent audio alarm. 9050-065-P-9-11... -
Page 9: Glossary
ENTRAPMENT - The condition when an object is caught or held in a position that increases the risk of injury. 9050-065-P-9-11... -
Page 10: Slide Gate Requirements
A contact sensor should screened wire mesh to a be installed in this area non-compliant for safety. gate AND (See non-compliant on next adjacent fence page). that covers open gate position (See above). Gate Frame and Adjacent Fence Area 9050-065-P-9-11... -
Page 11: Slide Gate Protection
Do not let children operate the gate or play in the gate area. This entrance is for vehicles only. Separate Pedestrians must use separate entrance. Pedestrian Walkway Located so pedestrians cannot come in contact with the vehicular gate. 9050-065-P-9-11... -
Page 12: Section 1 - Installation
1.2 Physical Stops for the Gate Rubber bumper faces toward The 9050 automatic open/close gate limits must have a physical operator. it will make contact stop on the open and close positions of the gate. This can be the... -
Page 13: Typical Gate Types
1.3 Typical Gate Types The Model 9050 operator is designed to be installed on these gate types. See the next 4 pages for specific operator mounting positions. Individual installations and physical stops can vary. • 300 lb max. weight per gate. -
Page 14: Operator Mounting Positions
1.4 Operator Mounting Positions The Model 9050 operator is designed to be installed in the front, rear, center or ceiling mounting positions shown on this page and the next 3 pages. V-wheel V-rail ornamental gates are shown as examples but other gate types on the previous page can use the same mounting setups. - Page 15 Rear Position with Post Mount Hides the chain from outside the property looking in. • Chain setup is the same as above. Additional hardware required. Post base plate (P/N 2600-418) 4 x 4 steel posts not available from DoorKing. 9050-065-P-9-11...
- Page 16 E t a i n Gate in Close Position d l e I d l E n d E n d l e s I d l e See page 18 for more information about endless idlers. 9050-065-P-9-11...
-
Page 17: Underground Conduit Requirements
Sweep • DoorKing recommends using 3/4-inch conduit. Elbow • Be sure that all conduits are installed in accordance with local codes. • Never run low voltage rated wire insulation in the same conduit as high voltage rated wire insulation. 9050-065-P-9-11... -
Page 18: Pad, Post Or Ceiling Mount Without/With J-Box Setup
DoorKing, Inc., Inglewood, CA same conduit. Fail-Secure Operator MUST Key Lock be level. High High Volt Volt Volt Volt Note: Operator must be mounted Conduit Knock-Out Sizes Pad, post or 1” min. away from gate. ceiling mount Conduit Conduit 9050-065-P-9-11... -
Page 19: Mounting Operator And Chain
Washer Use six (6) 1/2”-13 x 1 1/2” tighten the chain. The chain should sag no Washers bolts, lockwashers and nuts more than one (1) inch per 10 feet of travel. (not supplied). Do not over tighten the chain. 9050-065-P-9-11... -
Page 20: Installation Of Warning Signs
Endless Idler Assembly (On Select Installations) DoorKing offers an endless idler assembly with a protective cover designed for the Model 9050 installations (P/N 2600-818). Make sure the endless idler assembly is securely fastened to the wall or post (Depending on which type of installation will be used). -
Page 21: Section 2 - Ac Power To Operator(S)
Wire Size / Distance in Feet 12 AWG 10 AWG 8 AWG 6 AWG Single 9050: 4.3 Amp Motor Dual 9050’s, Single Power Source 2.2 High Voltage Terminal Connection • Route incoming AC power wire through the high voltage conduit and run wire in the operator as shown. -
Page 22: Section 3 - Adjustments
This feature is respectively. DIP-switch 3 must clockwise for maximum designed for bench Normal be set to control relay. sensitivity. See page 23. Min Max testing ONLY. Mode See next page and page 28. Sensitivity 9050-065-P-9-11... -
Page 23: Dip-Switch Settings
1, 2 or 3 inches short of the full close position. Needed only when using a reversing edge entrapment protection device on the closing edge of the gate with an end post as the physical stop. 9050-065-P-9-11... -
Page 24: Automatic Open / Close Limit Adjustment
Open and close gate positions are now set and will be remembered by the operator (until it loses AC power). Finished Gate will function normally after automatic “Multiple Gate Cycles” sequence has finished. Note: If gate encounters an obstruction during this sequencing, it will automatically continue after obstruction has been cleared. 9050-065-P-9-11... -
Page 25: Clutch Adjustment
If it does not, increase the reverse sensitivity (step ) and repeat this test until the correct sensitivity has been set. The operator will assume a soft shutdown after striking and reversing the gate which will require a key switch command to cycle operator again. 9050-065-P-9-11... -
Page 26: Section 4 - Entrapment And Safety Protection
Secondary Entrapment Protection Devices: In addition to the inherent reversing sensor system, the Model 9050 has a 6-pin UL 325 terminal for the connection of photo sensors-Type B1 and reversing edges-Type B2 secondary entrapment protection devices required by UL 325 standards. Entrapment protection devices must be installed to reduce the risk of injury. -
Page 27: Secondary Entrapment Protection Device Locations
STOP the gate, then resume closing the gate when the obstructed photo beam has been cleared. Common Photo Sensor Power Note: Photo sensors can be powered by the built-in convenience outlets located on the operator (See previous page). 9050-065-P-9-11... - Page 28 STOP and reverse direction. When 24 VAC Receiver a photo beam gets obstructed the gate will Normally Open STOP, then continue in the same direction Place receiver in operator. Common after obstructed photo beam has been cleared until the gate cycle is complete. 9050-065-P-9-11...
-
Page 29: Loop Detector Wiring
SELF TEST Note: Loop detector wiring is shown for DoorKing plug-in loop detector P/N 9410-010 (Single Channel) only. If other loop detectors are used, refer to the installation instructions supplied with those detectors for wiring and separate power instructions. 9050-065-P-9-11... -
Page 30: Section 5 - Main Terminal Wiring
• When Switch 3 is turned OFF, relay is activated when gate IS NOT closed. Relay contacts can be set for Normally Open (NO) or Normally Closed (NC) operation. Contact rating is 1 amp maximum at 24-volts DC. 9050-065-P-9-11... -
Page 31: Control Wiring For Single/Primary Operator
When gate is clear, timer will time-out and close gate. This CANNOT be used as UL 325 secondary entrapment protection. Stand-Alone Card Reader Note: All stand-alone, telephone entry and photo sensor devices must use a separate power source. N.O. 9050-065-P-9-11... -
Page 32: Bi-Parting Gates Wiring - Dual Gate Operators
Blue Interconnection Cable External Loop Detectors Sold separately from DoorKing. DKS plug-in loop detectors CANNOT be used in this primary / secondary arrangement. Use 5 wires used (8 - 18 AWG wires total). external detectors that have a normally open (N.O.) relay contact. -
Page 33: Section 6 - Operating Instructions
ON (toggle up) or OFF (toggle down). Every time the operator is powered up, the First open command will automatically run “Multiple gate cycles” that will locate and remember the gate’s open and close positions (See page 22). 9050-065-P-9-11... -
Page 34: Shutdown Conditions
To silence the alarm, press the reset button or after 5 minutes, the audio alarm will shut off but will “chirp” every 5 seconds. This indicates that the operator is in a hard shutdown condition (The reset button must be pressed to reset the operator and stop the alarm “chirping”). 9050-065-P-9-11... -
Page 35: Manual Gate Operation
Solenoid lock WILL retract and secure the clutch plate during AC power failure or turning AC power off. Gate can be normal operation ONLY if operator senses an unauthorized manual open attempt. Gate will NOT be allowed to move. immediately manually operated during these conditions. 9050-065-P-9-11... -
Page 36: Fail-Secure Manual Release System (Owner Installed)
AC power failure. ONLY the “Fail-Safe” release system allows the gate to be manually operated without unlocking the operator first and has been designed that way to allow emergency personnel to immediately manually operate the gate from either side under emergency situations. 9050-065-P-9-11... -
Page 37: Section 7 - Maintenance And Troubleshooting
Check for alignment. Check setscrews. Pulleys Check manual release for proper operation. Release ✓ Check secondary (external) reverse device(s) stop or reverse the Secondary Reverse Device ✓ gate when activated. Complete check of gate and gate operating system. Complete System 9050-065-P-9-11... -
Page 38: Troubleshooting
If the motor runs in both steps above, replace the control board. If the motor does not run, or runs in only one direction, problem can be a bad motor, motor capacitor, motor resistors, wire connections from the control board to the motor or a bad control board. 9050-065-P-9-11... - Page 39 • Operator has been in a “hard shutdown” condition in excess of 5 minutes. Reset button must be every 5 seconds. pushed to return operator to normal operation, see Section 6.2 Shutdown Conditions, pages 32-33. Operator will not run. 9050-065-P-9-11...
-
Page 40: Accessory Items
7.3 Accessory Items The following accessory items are available for the model 9050 slide gate operator. Contact Sensors - For use as a secondary entrapment protection device. Miller Edge, Inc., MGO20, MGR20, MGS20 Photo Cell - Non-contact (photocell) sensors for use as a secondary entrapment protection device. -
Page 41: Model 9050 Wiring Diagram
Model 9050 1/2 HP 115 VAC Convenience Outlets 1/2 HP 30uf Capacitor 4.3 Amp Blue Blue Black White White Power Ground Neutral White Black Brown MOV Assembly Black White Built-In Solenoid Lock Mounting 115 VAC Chassis Screw Ground Brown White... -
Page 42: 9050-065
Model 9050 Model 9050 Model 9050 Installation/Owner’s Manual Vehicular Slide Gate Operator Use this manual for circuit board 4702-010 Revision A or higher. 9050-065-P-9-11 www.doorking.com DoorKing, Inc. 120 Glasgow Avenue Inglewood, California 90301 U.S.A. Phone: 310-645-0023 Fax: 310-641-1586 Copyright 2009 DoorKing, Inc. All rights reserved.
