SureCall Flex Pro User Manual page 7

Note: With a signal booster kit with panel antenna, stay 6½ feet from the panel
based on new FCC rules.
Step 3. Mount the Booster (Optional)
1. Select a location for your booster.
2. Clean the intended surface and allow it to dry.
3. Peel the protective paper from the back of the hook sides of the Velcro. Press
the adhesive side of the Velcro strips into place on the bottom of the booster,
one strip on each end.
4. Wait 5 minutes, and then attach the loop side of the Velcro to the hook side.
The adhesive bond reaches maximum strength after 24 hours.
5. With both the Velcro loop and hook pieces attached to the back of the booster,
peel the protective paper off of the back of the loop strips.
6. Press the entire booster into its mounting place, and then wait 5 minutes for
the adhesive to set.
7. Be sure the booster is seated firmly.
To remove the booster, rotate it across the Velcro. Do not pull the booster or cables.
Step 4. Connect to AC Power
1. Connect the AC power cord to the booster (see page 4).
2. Connect the plug on the other end to a 110V AC power outlet. Be sure all
connections to the booster are tight and secure.
The booster turns on automatically.
The Power LED goes ON to show that the booster is ready for use (see
page 4).
The Alert LEDs flash up to 15 seconds on each band to show the band is
activated (see page 4).
The booster is rated for 5-20V input voltage. DO NOT use the booster with a
higher voltage power supply. This can damage the booster and/or cause
personal injury.
SureCall Flex Pro Home and Office Kit Cellphone-Mate, Inc.
All rights reserved.
INSTALLATION
Page 7
