9.3.2.3 mvBlueLYNX-X102e (SXGA 1280 x 1024)

The sensor uses a full frame shutter (ShutterMode = FrameShutter), i.e. all pixels are reset at the same
time and the exposure commences. It ends with the charge transfer of the voltage sampling.
Feature
Manufacturer E2V
Sensor name EV76C560
Max. frames 60
per second
Device CMOS image sensor
Structure
SNR 41 dB
DNR (normal / 62 dB /
HDR)
Image size Type 1/1.8
Number of 1280 (H) x 1024 (V)
effective pixels
Unit cell size 5.3µm (H) x 5.3µm (V)
ADC 10 bit (10-8 companding) → 10, 8 bit
resolution /
output

9.3.2.3.1 Spectral Sensitivity

9.3.2.3.1.1 Spectral response and quantum efficiency
MATRIX VISION GmbH
mvBlueLYNX-X Technical Manual
Description
Figure 43: mvBlueLYNX-X102e
22 April 2016 Version - 1.49 73
