14.1.8 mv X Lamp Control

The "mv X Lamp Control" contains features like
Feature Property name (acc. to
name (acc. mvIMPACT Acquire)
to SFNC)
mvXLampSource
mvXLampActivationSourceSelector Determines the activation source.
mvXLampLEDPairSelector
related to the mv X Lamp Control.
The use case Controlling the mvXLamp using GenICam shows how you can work with the mvXLamp.

14.1.9 User Set Control

The "User Set Control" contains features like
Feature name (acc. to SFNC) Property name
UserSetSelector
UserSetLoad[UserSetSelector] userSetLoad
UserSetSave[UserSetSelector] userSetSave
UserSetDefault
related to the User Set Control to save and load the user device settings.
The camera allows the storage of up to five configuration sets in the camera. This feature is similar to the
storing settins in the registry but this way in the camera. It is possible to stored
exposure,
•
• gain,
• AOI,
• frame rate,
• etc.
permanently. You can select, which user set comes up after hard reset.
The storage of user data in the registry can still override user set data!
Additionally, there is the property mvUserData. This string can be used to store arbitrary user data into the
device's non-volatile memory.
120
mvBlueLYNX-X Technical Manual
Is the "flash" signal. When it is high, all flash LEDs are
on which have been enabled.
Determines the LED pair. In this section you can set the
behavior of the specified LED pair.
(acc. to
mvIMPACT
Acquire)
userSetSelector Selects the feature User Set to load, save or configure.
Loads the User Set specified by UserSetSelector to the
device and makes it active.
Endianess of the device registers.
userSetDefault Selects the feature User Set to load and make active when
the device is reset.
