Patton electronics 1053 User Manual

Patton electronics idsl modem with rs-232 user manual 1053
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Part# 07M1053-UG
Doc# 05815U2-001 Rev. A
Revised 11/10/04
An ISO-9001
Certified
Company
USER
MANUAL
MODEL 1053
iDSL Modem with
RS-232 Interface
SALES OFFICE
(301) 975-1000
TECHNICAL SUPPORT
(301) 975-1007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1053 and is the answer not in the manual?

Questions and answers

Related Manuals for Patton electronics 1053

Summary of Contents for Patton electronics 1053

  • Page 1 Part# 07M1053-UG Doc# 05815U2-001 Rev. A Revised 11/10/04 An ISO-9001 Certified Company USER MANUAL MODEL 1053 iDSL Modem with RS-232 Interface SALES OFFICE (301) 975-1000 TECHNICAL SUPPORT (301) 975-1007...

  • Page 2: Table Of Contents

    Configuring DIP switch S2... 10 Installation... 11 Connecting the Twisted Pair Interface... 11 Connecting the Model 1053/A (RS-232)... 12 Connecting the Model 1053/A (RS-232) to a DTE Device ... 12 Power Connection ... 12 Universal AC Power (100–240 VAC)... 13 DC Power ... 13 Operation...
  • Page 3 Model 1053/A Factory Replacement Parts and Accessories ... 17 Model 1053/A Interface Pin Assignments... 18...

  • Page 4: Warranty Information

    1.0 WARRANTY INFORMATION Patton Electronics warrants all Model 1053 components to be free from defects, and will—at our option—repair or replace the product should it fail within one year from the first date of shipment. This warranty is limited to defects in workmanship or materials, and does not cover customer damage, abuse or unauthorized modification.

  • Page 5: Service

    Packages received without an RMA number will not be accepted. Patton Electronics’ technical staff is also available to answer any ques- tions that might arise concerning the installation or use of your Model 1053. Technical Service hours: 8AM to 5PM EST, Monday through Friday.

  • Page 6: General Information

    • CE marked 2.2 DESCRIPTION The Patton Model 1053 is a high speed, AC powered short range modem that is able to operate synchronously or asynchronously—full duplex— over a single twisted pair. Supporting data rates up to 128 kbps (syn- chronous) or 115.2 kbps (asynchronous), the Model 1053 is capable of...

  • Page 7: Configuration

    S1 and S2 each contain eight internal DIP switches (see Figure 1) that are used for configuration reset purposes only. To access switch sets, use a small flat blade screwdriver to open the Model 1053’s case as shown in Figure 2 on page 8.

  • Page 8: Configuring Dip Switch S1

    DIP switches S1-1 through S1-8. Detailed descriptions of each switch follow the table. Switches S1-1 and S1-2: Data Rate. Use switches S1-1 and S1-2 to configure the asynchronous or synchronous data rate of the Model 1053.

  • Page 9: Switch S1-3: Must Be Set To The On Position (Reserved)

    Model 1053 for async/sync operation. For synchronous data rates set switch S1-5 OFF. For asynchronous rates set switch S1-5 ON. Switches S1-6 and S1-7: System Clock Mode. Use Switches S1-6 and S1-7 to configure the 1053 for internal, or receive recover clock mode. S1-6 S1-7...

  • Page 10: Switch S1-8

    Therefore, you must set these switches whether your application is async or sync. For Sync or Async applications, please configure one Model 1053 for internal clock mode and the other Model 1053 for receive recover clock mode. Important Switch S1-8: Must be set to the OFF position (Reserved).

  • Page 11: Installation

    Once the Model 1053 has been configured, it is ready to connect to the twisted pair interface, the serial port, and the power source. This section tells you how to make these connections. 4.1 CONNECTING THE TWISTED PAIR INTERFACE The Model 1053 supports communication between two DTE devices at distances to 5 miles (8 km) over 24 AWG (0.5 mm) twisted pair wire.

  • Page 12: Connecting The Model 1053/A (Rs-232)

    DB-25 female connector. As a DCE, this inter- face is designed to connect to DTE equipment, such as a router. When connecting the RS-232 interface of the Model 1053/A to your DTE device, use an RS-232 straight-through cable (see Figure 5). Appendix C on page 18 describes pin assignments and signal sources for the Model 1053/A RS-232 interface.

  • Page 13: Universal Ac Power (100-240 Vac)

    (Refer to Appendix B on page 17 for country-specific power cords. The Model 1053 powers up as soon as it is plugged into an AC outlet—there is no power switch.The Universal AC supply is equipped with a male IEC-320.

  • Page 14: Operation

    Once the Model 1053 is properly configured and installed, it should oper- ate transparently. This sections describes power-up, reading the LED status monitors. 5.1 POWER-UP Before applying power to the Model 1053, read section 4.3, “Power Con- nection” on page 12 to ensure that the unit is connected to the appropri- ate power source.

  • Page 15: Model 1053 Specifications

    APPENDIX A MODEL 1053 SPECIFICATIONS A.1 TRANSMISSION FORMAT Synchronous or asynchronous A.2 TRANSMISSION LINE Single unconditioned twisted pair A.3 CONTROL SIGNALS CD and RTS A.4 CLOCKING Internal, external, or receive recover A.5 DISTANCE Distance, max, all data rates: • 10.1 miles (16.4km) on 19 AWG (0.9 mm) wire •...

  • Page 16: Temperature Range

    A.10 TEMPERATURE RANGE 32–122°F (0–50°C) A.11 ALTITUDE 0–15,000 feet (0–4,572 meters) A.12 HUMIDITY 5–95% non-condensing A.13 WEIGHT 2.01 lbs. (1.0 kg) A.14 LINE INTERFACE Transformer coupled 1500 VAC isolation...
  • Page 17 MODEL 1053/A FACTORY REPLACEMENT Model # 1053/A 12V-PSM 24V-PSM 48V-PSM 08055DCUI 100–240VAC (+5V ±5% reg. DC/2A) Universal Input Adapter 0805EUR 0805UK 0805US 0805AUS 0805DEN 0805FR 0805IN 0805IS 0805JAP 0805SW 07M1053 APPENDIX B PARTS AND ACCESSORIES Description RS232 iDSL Modem 12 VDC Power Supply Module...
  • Page 18 APPENDIX C MODEL 1053/A INTERFACE PIN ASSIGNMENTS RS-232 INTERFACE (DB-25 Female Connector) (DCE Orientation) Pin # TD (Transmit Data) (DTE Source) RD (Receive Data) (DCE Source) RTS (Request to Send) (DTE Source) CTS (Clear to Send) (DCE Source) DSR (Data Set Ready) (DCE Source)
