Part# 07MVLINK Rev. A
Doc# 058091U Rev. C
Revised 3/20/03
An ISO-9001Certified
Company
USER
MANUAL
VLINK MODEM
Model 1058 & 1068
SALES OFFICE
(301) 975-1000
TECHNICAL SUPPORT
(301) 975-1007

Advertisement

Table of Contents
loading

Related Manuals for Patton electronics 1058

Summary of Contents for Patton electronics 1058

  • Page 1 Part# 07MVLINK Rev. A Doc# 058091U Rev. C Revised 3/20/03 An ISO-9001Certified Company USER MANUAL VLINK MODEM Model 1058 & 1068 SALES OFFICE (301) 975-1000 TECHNICAL SUPPORT (301) 975-1007...

  • Page 2: Table Of Contents

    A.6 LED Status Indicators ... 22 A.7 Power Supply ... 22 A.8 Temperature Range ... 23 A.9 Humidity ... 23 A.10 Dimensions ... 23 Model 1058 Series Factory Replacement Parts and Accessories... 24 MODEL 1068 series Factory Replacement Parts and Accessories... 25...
  • Page 3 VLINK Series Interface Pin Assignment ... 26 D.1 10/100Base-T Interface ... 26 RJ-45 ... 26 D.2 VDSL Interface ... 26 RJ-45 ... 26 Terminal Block... 26 D.3 POTS/ISDN Interface ... 26 RJ-45 ... 26 Distance Chart, Based on 24 AWG (0.5 MM) ... 27...

  • Page 4: Warranty Information

    1.0 WARRANTY INFORMATION Patton Electronics warrants all VLINK modem components to be free from defects, and will—at our option—repair or replace the product should it fail within one year from the first date of the shipment. This warranty is limited to defects in workmanship or materials, and does not cover customer damage, abuse or unauthorized modification.

  • Page 5: Fcc Part 68 (Dv Version Only)

    1.3 FCC PART 68 (DV VERSION ONLY) The Model 1058/1068D is not intended to be connected to the public telephone network. Caution The VLINK modem port is not intended to be connected to the public telephone network. The 1058/1068DV con- tains a POTS/ISDN connection that can be connected to the public telephone network.

  • Page 6: Industry Canada Notice

    If this equipment causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of ser- vice may be required. But if advance notice isn't practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary.

  • Page 7: General Information

    LAN extension and a VLINK/CP (customer premise) at the other end, these units can automatically forward LAN broadcasts, multicasts, and frames across a 2-wire voice-grade twisted-pair link. The data is passed Only Models 1058/1068DV/CO and 1058/1068DV/CP have POTS/ISDN splitters on board.
  • Page 8 transparently (unmodified) through the VLINK modems. The VLINK modems automatically add and delete MAC addresses, only passing packets across the VDSL link that are meant for the remote peered LAN. Figure 1. Typical application The VLINK/CO modem and VLINK/CP modem work together to create a transparent extension between two peered Ethernet LANs.

  • Page 9: Installation

    Because the VLINK modem requires no configuration, it can be installed quickly. If you are installing a standalone unit, refer to section 3.1 “Standal- one unit installation”. Otherwise, refer to section 3.2 “Rack card installation”. Note If asymmetric transmission or line rates other than 12.5 Mbps are required (Model 1068 only), refer to section 4.0, “Configura- tion (Model 1068 Only)”...

  • Page 10: Rack Card Installation

    3.2 RACK CARD INSTALLATION The VLINK modem rack card comprised a front card and a rear card.Do the following to install the cards into the rack chassis: 1. Slide the rear card into the back of the chassis along the metal rails. 2.

  • Page 11: Connecting The Twisted-Pair Line Interface

    6. Connect the Ethernet interface (refer to section 3.4, “Connecting the 10/100Base-T Ethernet Interface” on page 12). 3.3 CONNECTING THE TWISTED-PAIR LINE INTERFACE The VLINK modem supports communication between two peer Ethernet LAN sites over a distance of up to 6,000 ft (1.83 km) over 24 AWG (0.5 mm) twisted-pair wire.

  • Page 12: Connecting The 10/100Base-T Ethernet Interface

    The terminal block connector on the VLINK modem's twisted pair inter- face is polarity insensitive and is wired for a two-wire interface. The signal/pin relationships is shown in Figure 5. Figure 5. VLINK modem (terminal block version) twisted pair line interface. 3.4 CONNECTING THE 10/100BASE-T ETHERNET INTERFACE Ethernet The shielded RJ-45 port labeled...

  • Page 13: Connecting The 10/100Base-T Ethernet Port To A Hub

    Connecting the 10/100Base-T Ethernet Port to a Hub The VLINK modem 10/100Base-T interface is configured as DTE (Data Terminal Equipment), just like a 10/100Base-T network interface card in a PC. Therefore, it “expects” to connect to a 10/100Base-T Hub using a straight-through RJ-45 cable.

  • Page 14: Connecting Power

    work. The RJ-45 connector in the VLINK modem’s POTS/ISDN interface is wired as shown in Figure 9. Figure 9. VLINK (RJ-45) POTS/ISDN interface 3.6 CONNECTING POWER An external AC or DC power supply is available separately. This connec- tion is made via the barrel jack on the rear panel of the VLINK standalone modem.

  • Page 15: Configuration (Model 1068 Only)

    4.0 CONFIGURATION (MODEL 1068 ONLY) The VLINK modem has eight DIP switches for configuring the unit for a wide variety of applications. This section describes switch locations and explains the different configurations. 4.1 CONFIGURING THE HARDWARE DIP SWITCHES Using a small flat-tip screwdriver, remove the protective cover located on the underside of the VLINK modem (see Figure 10).
  • Page 16 Figure 11. Model 1068 standalone modem DIP switch orientation L i n L i n t i v i t y Figure 12. Model 1068 rack card DIP switch orientation Switch toggle Push toggle to left for ON position Push toggle to right for OFF position...

  • Page 17: Configuring Dip Switch S1

    4.2 CONFIGURING DIP SWITCH S1 DIP switch S1 is where you configure the VDSL line rate, symmetric or asymmetric, Ethernet full auto negotiation capability (100Base-T full or half duplex, 10Base-T full or half duplex) or limited auto sense (only 100Base-T half duplex, 10Base-T full or half duplex). Switch S1-1: Ethernet Auto Sense Use switch S1-1 to configure the unit for full auto sense capability or lim- ited auto sense capability.
  • Page 18 Table 3: Asymmetric VDSL Line Rates Selection Chart S1-2 S1-3 S1-4 Table 4: Reserved for future use S1-5 S1-6 S1-7 Asymmetric Line Rates DS/US 4.17 Mbps/1.56 Mbps (Mode 0) 9.38 Mbps/1.56 Mbps 16.67 Mbps/2.34 Mbps S1-8 Reserved for future use Reserved (Factory Default)

  • Page 19: Operation

    Once the VLINK modems are properly installed, they should operate transparently. No user settings required. This section describes reading the LED status monitors. 5.1 POWER UP Before applying power to the VLINK modem, please review section 3.6, “Connecting Power” on page 14 to verify that the unit is connected to the appropriate power source.
  • Page 20 Table 5: Front panel LED description for standalone modem Power On (green) when power is applied to the unit. Off when no power is applied to the unit. VLINK - Link On (green) when the end-to-end VDSL link between the units is established. Off when the link has not been established or when the link fails VLINK - QOL Flashes yellow at different rates to indicate the...
  • Page 21 Figure 14. VLINK modem rack card front panel Table 6: Front panel LED description for rack card modem Power Solid GREEN to indicate the unit is powered on. VLINK modem (Active Green) Solid green (ON) to indicate that the Link end-to-end VDSL link between the VLINK modems is established.

  • Page 22: Specifications

    A.3 VDSL LINE RATE Model 1068—16.67 Mbps, symmetric upstream/downstream. Additional symmetric and asymmetric rates are available via DIP switch settings. Model 1058—Fixed 12.5 Mbps, symmetric upstream/downstream. A.4 VDSL DISTANCE 6,000 ft (1.83 km) at 1.56 Mbps upstream/4.17 Mbps downstream Note Distances depend on selected line rate.

  • Page 23: Temperature Range

    A.8 TEMPERATURE RANGE 32–122°F (0–50°C) A.9 HUMIDITY Up to 90% non-condensing. A.10 DIMENSIONS 1.58H x 4.16W x 3.75D in. (10.6H x 4.1W x 8.8D cm)

  • Page 24: B Model 1058 Series Factory

    CO VDSL Modem, data only, no power supply CP VDSL Modem, data only, no power supply VDSL MODEM Kit: includes one central office (CO) and one customer premise (CP) Model 1058, data only, no power supply CO VDSL Modem, voice & data, no power supply CP VDSL Modem, voice &...

  • Page 25: Cmodel 1068 Series Factory

    REPLACEMENT PARTS AND ACCESSORIES Patton Model # Base Models 1068DRC/CO CO Variable Rate VDSL Rack Card; data only 1068DRC/CP CP Variable Rate VDSL Rack Card; data only 1068DVRC/CO CO Variable Rate VDSL Rack Card; voice and data 1068DVRC/CP CP Variable Rate VDSL Rack Card; voice and data 1068D/CO CO Variable Rate VDSL Modem, data only, no power supply 1068D/CP...

  • Page 26: D Vlink Series Interface Pin Assignment

    APPENDIX D VLINK SERIES INTERFACE PIN ASSIGNMENT D.1 10/100BASE-T INTERFACE RJ-45 • Pin 1: TX+ • Pin 2: TX- • Pin 3: RX+ • Pin 6: RX- • Pins 4, 5, 7, 8: no connection D.2 VDSL INTERFACE RJ-45 • Pin 4: RING •...
  • Page 27 16.67 Mbps Asymm Line Rate (DS/US) 4.17 Mbps/1.56 Mbps (Mode 0) 9.38 Mbps/1.56 Mbps 16.67 Mbps/2.34 Mbps Note Model 1058 is fixed at 12.5 Mbps, 4,000 ft (1,220 m). APPENDIX E Distance in feet (km) 4,500 (1.37) 4,150 (1.26) 4,000 (1.22) 3,300 (1.00)
  • Page 28 Notes _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ Copyright © 2003 Patton Electronics Company All Rights Reserved.

This manual is also suitable for:
