Patton electronics GoCard 1058 Quick Reference Manual

12.5 mbps vdsl modem
Hide thumbs Also See for GoCard 1058:

Advertisement

Quick Links

Product Model

Product Name

Product Manager

Who are the customers for the Model 1058?

The Patton Model 1058DV Variable Rate VDSL Modem
enables the utilization of existing copper infrastructure
for the delivery of high-speed broadband services. The
1058DV includes seven asymmetrical and symmetrical
settings, which include an option for line rates up to
16.67 Mbps!
The Model 1058DV's built in POTS/ISDN splitter allows
users to simultaneo usly talk on the phone while surfing
the web, downloading files, or receiving emails. This
incredible bandwidth and line sharing capabilities are
provided over a single twisted pair of voice-grade wire.
The Model 1058DV solution is targeted to users or
service providers that need high-speed Ethernet data and voice links over their existing copper
infrastructure. These organizations include but are not limited to CLEC's, ISP's, Educational Facilities
(Campus), MTU/MDU's, and corporate/government offices. Popular applications for symmetrical VDSL
include Ethernet extension, medical imaging, video-conferencing, Ethernet Bridging, and connecting
remote devices or networks to a central LAN. The variable symmetrical data rates ensure the highest
possible data rate is achieved over various lengths and types of copper wire and environments.
Variable asymmetrical line rates make the Model 1058 ideal for service providers who want to
differentiate their services and extend the reach of their customer base using VDSL services. The
Model 1058DV allows service providers to offer unparalleled performance for applications such as:
always on Internet access, real time bi-directional video streaming, and various multimedia
applications.
Typical applications include:
LAN-to-LAN Bridging: The Model 1058 connects remote LANs over a high-speed, symmetrical or
asymmetrical link. The 1058 CP unit is placed at the remote location and the 1058 CO unit is placed at
the central site to provide a LAN-to-LAN connection over a voice-grade wire. This application will
generally be made over a symmetrical link.
Ethernet Extension: The Model 1058 overcomes the 328 ft (100m) limitations of Ethernet with a
symmetrical or asymmetrical data link at distances up to 6,656 ft (2.03 km) and speeds up to 16.67
Mbps. The Model 1058 point-to-point solution does not use or require Ethernet repeaters. This
application will generally be made over a symmetrical link.
Model 1058 12.5 Mbps VDSL Modem
12.5 Mbps VDSL Modem
John Grant
Contact
1 1 1 1
G G G G
oCard
oCard
oCard
oCard
Jgrant@patton.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GoCard 1058 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Patton electronics GoCard 1058

  • Page 1 Product Model Model 1058 12.5 Mbps VDSL Modem Product Name 12.5 Mbps VDSL Modem Product Manager John Grant Who are the customers for the Model 1058? The Patton Model 1058DV Variable Rate VDSL Modem enables the utilization of existing copper infrastructure for the delivery of high-speed broadband services.
  • Page 2 Dedicated Internet and Voice Services: The Model 1058 VDSL technology enables ISP’s to deliver dedicated high-speed Internet access and voice services from a Point-of-Presence (POP) to a customer premise. A 1058CO is used at the POP and a 1058CP is used at the customer premise. The Model 1058DV’s built-in POTS/ISDN splitter allows users to simultaneously use the phone or fax machine, while surfing the web, downloading files or receiving e-mails.
  • Page 3 Optional parts for the Model 1058 DC Power Supplies • Rack cards are compatible with Patton’s Model 1001R High-Density Telco Rack Chassis and Cluster • Boxes. Model 3324/DV/GE/UI 24 Port VDSL Concentrator • Optional DC Power Supplies for Standalone Units Part Number Description 48V-PSM...
  • Page 4 Physical Specifications Dimensions: Standalone: Rack Card: Color: Standalone: Rack Card: Case material: Standalone: Plastic, Fire retardant Rack Card: Iridite Aluminum Environmental Operating Temp: 32 to 122° F (0 to 50° C) Relative Humidity: Up to 90% RH, non-condensing Altitude: 0 –15,000 feet (3,048 meters) Ventilation requirements: None, units do not require cooling fans.
  • Page 5 Model 1058DV/CO/E 12.5 Mbps VSDL Modem; Central Office (RJ45); No Power Supply 1058DV/CP/E 12.5 Mbps VSDL Modem; Customer Premise (RJ45); No Power Supply 1058DV/E-2PK 12.5 Mbps VSDL Modem Kit; Central Office and Customer Premise (RJ45); No Power Supply 1058DV/CO/EUI * 12.5 Mbps VSDL Modem;...
