Firmware Upgrading
You can use the HomeWorks
software to upgrade the firmware in the
Dynamic Keypad.
Make sure the device running the
HomeWorks QS Designer software is
plugged into the mini-B USB port on the
Dynamic Keypad that you're upgrading.
The Dynamic Keypad can't be powered
from the USB port. Power must be
supplied through the 4-pin power and
communications connector.
Information
The information button will open the information page,
which shows the current firmware revision and link type.
QS Designer
®
USB 2.0 mini-B for
firmware upgrades
9D10
MUX
Power and
MUX
+24 V
communications
COM
PELV/Class 2
Model | Modelo | Modèle :
HQ-J-DK420
24 V
113 mA
4
