  • Page 1 Lutron Homeworks ® ® Integration Guide Luxor® Controllers with ZD Technology® and ZDC Technology® LUXOR Lighting Accessories by Hunter Industries...

  • Page 2: Table Of Contents

    Table of Contents System Requirements Getting Started Adding Devices Link Assignments Edit Integration IDs 10 Telnet Logins LUXOR Program Keypads 12 Transfer Project Luxor Controller Configuration Enable Lutron Troubleshooting...

  • Page 3: System Requirements

    System Requirements Getting Started Lutron Homeworks QS Requirements Creating a Project Software: Homeworks QS 1. Name the project. 2. Click on the Activate tab. 3. Select "processors" in drop-down box. 4. Uncheck the "4HHuunntteerr" box. 5. Record the processor IP address.
  • Page 4 Getting Started 6. In the Design tab, select Controls from the drop-down box. 7. Press "+" next to Exterior to add the location. Note: The location name should correspond to the Luxor location (e.g., front yard, backyard, etc.).

  • Page 5: Adding Devices

    Adding Devices Adding Devices 1. In the Controls section, select the Dimmer/QSG tab. 2. Click "+" to add the HQR-3LD 300W Lamp Dimmer.
  • Page 6 Adding Devices 3. Enter "Luxor All Groups" in the Device Location field. 4. Enter "Luxor Zone All" in the Name field. 5. Click "Done."...
  • Page 7 Adding Devices 6. For the device named Luxor All Groups, click "+." 9. Enter "Luxor Zone 01" in the Name field. 7. Add HQR-3LD 300W Dimmer to the Luxor All 10. Click "Done." Groups device. Repeat steps 6–10 until a device has been added for 8.

  • Page 8: Link Assignments

    Link Assignments Link Assignments 1. Confirm all Luxor groups have been added as a device. 2. In the Design tab, select "link assignment" from the drop-down box. 3. Assign the link to Luxor Group devices.

  • Page 9: Edit Integration Ids

    Edit Integration IDs Edit Integration IDs 1. In menu bar, select "Tools" and click "Configure Integration." 2. Select "Zones" in the "Assign integration IDs to:" drop-down box. 3. Double-click the ID field for the "Luxor Zone All" group and enter 500. 4.

  • Page 10: Telnet Logins

    Telnet Logins Telnet Logins 1. From the menu bar, select "Tools" and click "Configure Integration." 2. In the Configuration Integration menu, select Telnet Logins. 3. At the bottom of the screen, click "+ Add Telnet Login." 4. Enter "hunter" in the Username field. 5.

  • Page 11: Program Keypads

    Program Keypads Program Keypads 1. From the Program tab, select Keypad to control Luxor Groups. 2. Select the Device Location. 3. Select the Keypad button. 4. Select "Luxor Groups" to be controlled by the Keypad button. 5. Set a dimmer level. Repeat steps 3–5, until all Luxor Groups have been assigned to the Keypad.

  • Page 12: Transfer Project

    Transfer Project Transfer Project 1. In the Transfer tab, click the "Start Transfer" button. 2. Wait until the transfer is complete. 3. Next, configure the Luxor controller (refer to pages 13–14). Note: Ignore all "Device not addressed" warnings. Luxor Group devices do not need to be activated since they are used as placeholders.

  • Page 13: Luxor Controller Configuration

    Luxor Controller Configuration Luxor Controller Configuration 1. From the Luxor home screen, select "Setup." 2. Select Wi-Fi (or LAN for hardwire connection).

  • Page 14: Enable Lutron

    Luxor Controller Configuration 3. Verify the router connection. 4. Select "Lutron." 5. Enter the Lutron IP address. Note: The IP address can be found on the Main Repeater (refer to page 4). 6. Enter 500 in the "Integration ID Start #" field. Enable Lutron 7.

  • Page 15: Troubleshooting

    Troubleshooting Connection Error "Bad Login" Message If the Luxor controller fails to connect, verify the The "Bad Login" error message occurs when Lutron IP address is correct. the Lutron login username and password do not match "hunter" and "4HHuunntteerr" (refer to page 10). If changes are made, the project will need to be transferred again (refer to page 12).
  • Page 16 Lutron and Homeworks are trademarks of Lutron Electronics Co. Inc., registered in the U.S. and other countries. © 2019 Hunter Industries Inc. Hunter, all related logos, and all other trademarks are property of Hunter Industries, registered in the U.S. and other countries.
