Mailing system Optimail 30 – Service documentation

S5: Scale

The internal scale can be calibrated and zeroed.
Option:
Button Name
S1 Calibration
S2 Zero Adjust
S6: Consumable Protection
The consumable protection chip of the ink cartridge is tested.
The result will be shown as successful or failed
Option: None
Note: The consumable protection chip not only protects the cartridge but more importantly controls the quality of
imprint.
S7: Sensor test
All sensors on the Optimail30 can be tested.
Sensor Function
End of letter Exit detection
Print start Letter input detection
Cartridge Cassette door and encoder contact
detection
Roller Pressure roller movement
Option:
Button Name
S1
Encoder Test
S4
Move Roller
Zac Moody/Andrew Nagel Revision June 2005 optimail30 service mode chapter2 (dealer)
Function
10lb weight is required to Calibrate the internal scale
Zeroes the scale
Function
Encoder test – The cassette motor will run briefly ( the cassette must be
installed and the roller must be in the lower position)
Roller movement (up/down)
Symbol Symbol
inactive active
(Door Closed) (Door open)
(Roller down) (Roller up)
