Replacement: Rotor Brake Pad - AUTO GYRO CAVALON Manufacturer Maintenance Manual

63-51-00 8-1

REPLACEMENT: ROTOR BRAKE PAD

GENERAL, REFERENCES AND REQUIREMENTS
Task may only be performed by an organization or individual trained and entitled to carry out 'Line Maintenance'!
Secure gyroplane against unauthorized or unintended operation!
Gyroplane must be placed on level ground and restrained (blocks, chocks)
Mast cover must be removed, see
SPECIAL TOOLS AND CONSUMABLE MATERIALS
AG-BAS-02 Loctite 243 blue (88-00-00-S-30483)
SP IMPORTANT NOTE: Procedure involves spare parts. Check parts list below for ordering
details of affected components!
PRECAUTIONS AND SAFETY MEASURES
IMPORTANT NOTE: Procedure involves handling and disposal of special materials. For your health and
environmental aspects respect all applicable regulations!
PROCEDURES
NOTE: Brake pad can be replaced without disassembly of the rotor head.
1 Turn rotor so that bolts (1) can be accessed through the holes in the pre-rotator sprocket disc.
2 Unscrew bolts (1) and replace brake pad (2). Dispose of properly!
3 Install new brake pad.
4 Apply AG-BAS-02 on threads, install bolts (1) and tighten.
PARTS LIST
Fig. Pos. Description
1 1 M6x8 Countersunk
1 2 Brake pad assembly
1 3 brake pad ground plate
1 4 M6 35/8
1 6 Spacer 13-5,5/10-6/6
MMM-CV-E_16-06-13
Manufacturer
Maintenance Manual
52-00-00 4-1
PC PIT
L1 27-30-00-V-31054
Part E - 63-51-00 8-1
Remark
NPI
NPI
NPI
NPI
AutoGyro
Cavalon
LNE
Page 1 of 2
