CHECK-ADJUSTMENT: RUDDER CONTROL ANGLES

GENERAL, REFERENCES AND REQUIREMENTS
Task may only be performed by an organization or individual trained and entitled to carry out 'Line Maintenance'!
Secure gyroplane against unauthorized or unintended operation!
SPECIAL TOOLS AND CONSUMABLE MATERIALS
PRECAUTIONS AND SAFETY MEASURES
PROCEDURES
NOTE: Measure points are aft rudder edge and left/right radius between stabilizer and
vertical outer fins.
1 Adjust pedals in neutral position
Note that the nose wheel should be pointed 3° to the left with pedals neutral.
2 Check/adjust N1 = 900 mm (+/- 10 mm) and N2 = 840 mm (+/- 10 mm). See Fig. 1 for reference.
3 Press full left pedal (with nose wheel slightly unloaded for ease of movement) and check/adjust L = 630 mm
(+/- 50 mm). See Fig. 1 for reference.
4 Press full right pedal (with nose wheel slightly unloaded for ease of movement) and check/adjust R = 530 mm
(+/- 50 mm). See Fig. 1 for reference.
5 Check push-pull control cables (threaded articulation rods) tight and secure.
