Disassembly-Assembly: Propeller - Htc - AUTO GYRO CAVALON Manufacturer Maintenance Manual

61-10-00 4-2

DISASSEMBLY-ASSEMBLY: PROPELLER - HTC

GENERAL, REFERENCES AND REQUIREMENTS
Task may only be performed by an organization or individual trained and entitled to carry out 'Line Maintenance'!
Propeller must be removed, see
SPECIAL TOOLS AND CONSUMABLE MATERIALS
PRECAUTIONS AND SAFETY MEASURES
PROCEDURES
Disassembly
1 Mark inner and outer propeller hub to indicate relative installation position.
2 Place propeller assembly on a horizontal and clean surface and support propeller hub so that assembly does
not lie on propeller blades.
3 Unscrew and remove bolts (4).
4 Remove outer propeller hub and remove individual blades.
Assembly
5 Place inner propeller hub on horizontal and clean surface and support propeller hub.
6 Insert individual blades in correct position.
7 Attach outer propeller hub, insert bolts (4) and hand-tighten.
8 Torque-tighten bolts (4) with 10 Nm in crosswise sequence.
PARTS LIST
Fig. Pos. Description
1 1 spinner HTC3B, painted
1 2 M8x110
1 3 U8/24
1 4 M6x40
1 4 M6x40
1 5 Propeller hub front
1 5 Propeller hub rear
1 6
1 6
1 7 Propeller hub rear
1 7 Propeller hub front
1 8 Spinner Plate
1 9
1 10 U4, Poly
1 11 torque bush spacer
1 12 spacer propeller
MMM-CV-E_16-06-13
Manufacturer
Maintenance Manual
61-10-00 4-1
PC PIT
Part E - 61-10-00 4-2
Remark
L2 53-00-00-C-30587
NPI
NPI
NPI ROTAX 912
NPI ROTAX 914
L3 61-00-00-M-21190 ROTAX 914
L3 61-00-00-M-21191 ROTAX 912
61-00-00-V-32203 ROTAX 912
61-00-00-S-32464 ROTAX 914
L3 61-00-00-V-21191 ROTAX 914
L3 61-00-00-V-21190 ROTAX 912
NPI
71-00-00-V-31051
NPI
NPI
NPI
