ORDERING REPLACEMENT PARTS
To order replacement parts, contact the ICON Health & Fitness, Ltd. office, or write:
ICON Health & Fitness, Ltd.
Unit 4
Revie Road Industrial Estate
Revie Road
Beeston
Leeds, LS118JG
UK
Tel:
08457 089 009
Outside the UK: 0 (044) 113 387 7133
Fax: 0 (044) 113 387 7125
Please provide the following information when ordering replacement parts:
• the MODEL NUMBER of the product (WEEVSY39120)
• the NAME of the product (WEIDER
®
PRO 9450 weight system)
• the SERIAL NUMBER of the product (see the front cover of this manual)
• the KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST and EXPLODED DRAWING attached
at the centre of this manual)
WEIDER is a registered trademark of ICON Health & Fitness, Inc.
Part No. 185547 R0902A
Printed in Canada © 2002 ICON Health & Fitness, Inc.
Model No. WEEVSY39120
Serial No.
Write the serial number in the
space above for reference.
Serial Number Decal (Under Seat)
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts,
please call:
08457 089 009
Or write:
ICON Health & Fitness, Ltd.
Unit 4
Revie Road Industrial Estate
Revie Road
Beeston
Leeds, LS11 8JG
UK
email: csuk@iconeurope.com
CAUTION
Read all precautions and
instructions in this manual
before using this equipment.
Save this manual for reference.
USER'S MANUAL
Class HC Fitness Product
Visit our website at
www.iconeurope.com
Advertisement
Related Manuals for WeiderPro 9450
Summary of Contents for WeiderPro 9450
-
Page 1: Ordering Replacement Parts
• the MODEL NUMBER of the product (WEEVSY39120) Serial Number Decal (Under Seat) • the NAME of the product (WEIDER ® PRO 9450 weight system) QUESTIONS? • the SERIAL NUMBER of the product (see the front cover of this manual) As a manufacturer, we are com- •... -
Page 2: Table Of Contents
TABLE OF CONTENTS NOTES WARNING DECAL PLACEMENT ............2 IMPORTANT PRECAUTIONS . -
Page 3: Important Precautions
Military Press Cable (72) and Leg Press Cable (78) IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precau- tions before using the weight system. 1. Read all instructions in this manual and in 9. Keep hands and feet away from moving parts. Military Press Cable (72) the accompanying literature before using the weight system. -
Page 4: Before You Begin
(see the front do not touch or bind the cables. tem, the PRO 9450 weight system will help you to cover of this manual). achieve the specific results you want. -
Page 5: Assembly
TROUBLESHOOTING AND MAINTENANCE ASSEMBLY TIGHTENING THE CABLES Before beginning assembly, carefully read the • Tighten all parts as you assemble them, unless following information and instructions: instructed to do otherwise. Woven cable, the type of cable used on the weight system, can stretch slightly when it is first used. If there is slack in the cables before resistance is felt, the cables should be tightened. - Page 6 2. Slide the Rear Upright (74) and the Leg Press WEIGHT RESISTANCE CHART Upright (56) onto the indicated 5/16” x 2 1/2” Carriage Bolts (1) in the Stabiliser (5). The high side of the brackets on the Rear Upright and This chart shows the approximate weight resistance at each weight station.
- Page 7 ATTACHING AND REMOVING THE SEAT 4. Press a 2” Square Inner Cap (27) into the end of the Top Frame (55). Press a 1 3/4” Square Inner To attach the Seat (13), slide one of the three slots in Cap (44) into each end of the crossbar on the Top the bracket on the Front Seat Frame (36) onto the pin Frame.
-
Page 8: Adjustments
7. Press a Weight Tube Bumper (64) into the end of a ADJUSTMENTS Weight Tube (63). Insert the Weight Tube into the Holes front stack of Weights (25). Be sure that the pin The instructions below describe how each part of the weight system can be adjusted. Refer to the exercise on the Weight Tube is sitting in the pin grooves guide accompanying this manual to see how the weight system should be set up for each exercise. -
Page 9: Cable Diagrams
44. Make sure that all parts have been properly tightened. The use of the remaining parts will be explained in 9. Attach the upper ends of the Short Weight Guides ADJUSTMENTS, beginning on page 21 of this manual. (73) to the Top Frame (55) with a 5/16” x 6” Bolt (60), two 1/2”... - Page 10 12. Press a 1” Round Inner Cap (49) into one of the 41. Press a 1 1/2” Square Inner Cap (32) into the Leg Press Arms (46). Press a 1 3/4” Square Inner Cap Lever (29). (44) into the Press Arm. Lubricate the 5/16”...
- Page 11 15. See the inset drawing. Attach the Military Press Arm SEAT ASSEMBLY (84) to the Pivot Arm (80) with two 5/16” x 2 1/4” Bolts (33) and two 5/16” Nylon Locknuts (3). 37. Locate and open the parts bag labelled “SEAT Press two 1 1/2”...
- Page 12 18. Wrap the High Cable (58) around a “V”-Pulley (50). 35. Locate the Leg Press Cable (78). Attach the end Attach the “V”-Pulley and a Long Cable Trap (31) to of the Leg Press Cable to the Long “U”-Bracket (57) the indicated bracket on the Front Upright (42) with with a 1/4”...
- Page 13 32. Wrap the Military Press Cable (72) around a 3 1/2” 22. See the inset drawing. Wrap the High Cable (58) Pulley (15). Attach the Pulley and a pair of Pulley around a 3 1/2” Pulley (15). Attach the Pulley and a Covers (77) to the Pivot Arm (80) with the 3/8”...
- Page 14 25. Attach the Pulley and the 5/8” x 9/16” Spacer (7) to 29. Attach the end of the Low Cable (23) to the Long the Press Frame (17) with a 3/8” x 3 3/4” Bolt (88), “U”-Bracket (57) with a 1/4” Nylon Locknut (2) and a 3/8”...
- Page 15 5/8" x 9/16" Spacer (7) 3/4" Round Inner Cap (34) 1" Round Cover Cap (70) This chart is provided to help you identify the small parts used in assembly. The number in parenthesis below each part refers to the key number of the part from the PART LIST in the centre of this manual. Important: Some parts may have been pre-assembled for shipping purposes.
- Page 16 PART IDENTIFICATION CHART—Model No. WEEVSY39120 R0902A 3/8" x 2 1/2" Bolt (86) 5/16" x 2 1/2" Carriage Bolt (1) 1/4" x 2" Machine Screw (81) 3/8" Nylon Lock Nut (21) 3/8" Washer (9) 5/16" x 2 1/2" Bolt (22) 5/16" x 2 3/4" Bolt (11) 3/8"...
- Page 17 PART LIST—Model No. WEEVSY39120 R0902A REMOVE THIS PART LIST/EXPLODED DRAWING FROM THE MANUAL. Key No. Qty. Description Top Frame Leg Press Upright 5/16” x 2 1/2” Carriage Bolt Long “U”-Bracket 1/4” Nylon Locknut High Cable 5/16” Nylon Locknut 3/8” x 8” Bolt SAVE THIS PART LIST/EXPLODED DRAWING FOR FUTURE REFERENCE Base 5/16”...
- Page 18 EXPLODED DRAWING—Model No. WEEVSY39120 R0902A 77 9 11 8...
