ORDERING REPLACEMENT PARTS

To order replacement parts, contact the ICON Health & Fitness, Ltd. office, or write:

Unit 4

Revie Road Industrial Estate

Revie Road

Beeston

Leeds, LS118JG

Tel:

08457 089 009

Outside the UK: 0 (044) 113 387 7133

Fax: 0 (044) 113 387 7125

Please provide the following information when ordering replacement parts:

• the MODEL NUMBER of the product (WEEVSY59230)

• the NAME of the product (WEIDER

PRO 9350 weight system)

• the SERIAL NUMBER of the product (see the front cover of this manual)

• the KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST and EXPLODED DRAWING in the

centre of this manual)

Part No. 200190 R1203A

Model No.WEEVSY59230

Serial No.

(Write the serial number in the

space above for reference.)

Serial Number Decal (under seat)

QUESTIONS?

As a manufacturer, we are

committed to providing com-

plete customer satisfaction. If

you have questions, or if there

are missing or damaged parts,

please call:

08457 089 009

Or write:

ICON Health & Fitness, Ltd.

Unit 4

Revie Road Industrial Estate

Revie Road

Beeston

Leeds, LS118JG

email: csuk@iconeurope.com

CAUTION

Read all precautions and instruc-

tions in this manual before using

this equipment. Save this manual

for future reference.

USER'S MANUAL

Visit our website at

www.iconeurope.com

Table of Contents

Need help?

Do you have a question about the WEEVSY59230 and is the answer not in the manual?

Questions and answers

Summary of Contents for WeiderPro WEEVSY59230

Page 1: Ordering Replacement Parts
Outside the UK: 0 (044) 113 387 7133 Fax: 0 (044) 113 387 7125 Please provide the following information when ordering replacement parts: • the MODEL NUMBER of the product (WEEVSY59230) Serial Number Decal (under seat) • the NAME of the product (WEIDER ®...
Page 2: Table Of Contents
Rest for a short period of time after each set. The slowly as you stretch and do not bounce. Ease into TABLE OF CONTENTS ideal resting periods are: each stretch gradually and go only as far as you can • Rest for three minutes after each set for a muscle without strain.
Page 3: Important Precautions
EXERCISE GUIDELINES IMPORTANT PRECAUTIONS THE FOUR BASIC TYPES OF WORKOUTS PERSONALIZING YOUR EXERCISE PROGRAM WARNING: To reduce the risk of serious injury, read the following important precautions before using the weight system. MUSCLE BUILDING Determining the exact length of time for each workout, To increase the size and strength of your muscles, as well as the number of repetitions or sets completed, 1.
Page 4: Before You Begin
The numbers show the correct route for each cable. Make sure that the cable traps to tone your body, build dramatic muscle size and WEEVSY59230. The serial number can be found on a do not touch or bind the cables.
Page 5: Assembly
TROUBLESHOOTING AND MAINTENANCE ASSEMBLY Make sure all parts are properly tightened each time the weight system is used. Replace any worn parts immedi- ately. The weight system can be cleaned using a damp cloth and mild non-abrasive detergent. Do not use sol- Make sure you have the following tools: vents.
Page 6: Adjustments
ADJUSTING THE CARRIAGE FRAME ASSEMBLY To adjust the height of the Carriage (89), turn the Carriage Knob (73) counterclockwise until it is loose, Adjustment and pull it out as far as possible. Slide the Carriage Hole Before beginning assembly, make sure you up or down the Carriage Upright (84) to the desired have read and understood the information height.
Page 7 ATTACHING THE SEAT FRAME 3. Attach the Support Upright (88) to the Stabiliser (5) with the indicated two M10 x 55mm Carriage To attach the Seat Frame (36) to the Front Upright Bolts (1) and two M10 Nylon Locknuts (21). Do (42), slide one of the three slots in the bracket on the not tighten the M10 Nylon Locknuts yet.
Page 8 5. Orient the Weight Guides (62) so that the lock ADJUSTMENTS holes (see drawing 6) are closer to the bottom. Insert the two Weight Guides into the indicated holes in the Base (4). This section explains how to adjust the weight system. See the EXERCISE GUIDELINES on page 26 for impor- tant information about how to get the most benefit from your exercise program.
Page 9: Troubleshooting And Maintenance
48. Slide a Pad Tube (28) through the hole in the Leg 7. Press four 40mm x 60mm Inner Caps (27) into Lever (29). Press two 19mm Round Inner Caps the ends of the Top Frame (55). (34) into the ends of the Pad Tube. Slide two Foam Pads (30) onto the Pad Tube.
Page 10 11. Press two 38mm Square Inner Caps (32) into the Seat Assembly end of the Seat Frame (36). Attach the Bumper (87) to the Seat Frame (36) 45. Attach the Shroud (59) to the bracket on the Top with the M5 x 25mm Self-tapping Screw (80). Frame (55) with two M6 Washers (78) and two M6 x 16mm Bolts (18).
Page 11: Cable Diagrams
41. Wrap the Carriage Cable (83) around a 90mm 15. Lubricate the axles on the Top Frame (55) with Pulley (15). Attach the Pulley and a pair of Pulley grease. Orient the Right Butterfly Arm (48) as Covers (40) to the first set of holes from the bot- shown and slide it onto the right axle.
Page 12 18. Wrap the High Cable (11) around a “V”-pulley (6). 37. Attach the Low Cable (69) to the Front Upright Attach the “V”-pulley and a Long Cable Trap (50) (42) with an M8 x 80mm Shoulder Bolt (95), two to the Left Butterfly Arm (47) with an M10 x 60mm M8 Washer (70), and an M8 Nylon Locknut (3).
Page 13 33. Wrap the Low Cable (69) under a 90mm Pulley 22. Locate the Weight Cable (23), which has a bolt (15). Attach the Pulley and a pair of Pulley on each end. Attach the Cable to the Large “U”- Covers (40) to the upper hole in the Front Upright bracket (90) with an M8 Washer (70) and an M8 (42) with an M10 x 115mm Bolt (102), an M10 Nylon Locknut (3).
Page 14 26. Wrap the Weight Cable (23) under a 90mm Pulley 30. Locate the Low Cable (69), which has a ball on (15). Attach the Pulley and a pair of Pulley one end. Rest the Cable in the bracket on the Covers (40) to the second set of holes from the Base (4).
Page 15 This chart is provided to help you identify the small parts used in assembly. The number in parenthesis below each part refers to the key number of the part from the PART LIST in the centre of this manual. Important: Some parts may have been pre-assembled for shipping purposes.
Page 16 PART IDENTIFICATION CHART —Model No. WEEVSY59230 R1203A M10 x 78mm Bolt (76) 17.5mm Spacer (77) M10 x 80mm Bolt (8) M10 x 47mm Bolt (103) M10 x 45mm Bolt (100) M10 Nylon Locknut (21) 15mm Spacer (61) M8 x 45mm Bolt (66)
Page 17 PART LIST—Model No. WEEVSY59230 R1203A REMOVE THIS PART LIST/EXPLODED DRAWING FROM THE MANUAL. Key No. Qty. Description Key No. Qty. Description M10 x 55mm Carriage Bolt Pulley Plate M6 Nylon Locknut Shroud M8 Nylon Locknut M10 x 155mm Bolt Base...
Page 18 EXPLODED DRAWING—Model No. WEEVSY59230 R1203A 21 20 43 78 43 78 21 9 80 21 21 9...
