Screen component
Export
Time
Event
Data Path ID
Message

Starting, stopping, or clearing OpenFlow trace

Use the buttons above the Time field to control trace operations (see
details" (page

Displaying trace event details

1. Select the event you want to examine.
Figure 36 Selecting an event in the OpenFlow Trace log
2. Click
The Event Detail dialog box is displayed.
Description
Copies the trace log into a CSV (comma-separated values) file. See see
OpenFlow Trace log" (page
The time the message event was generated.
The event type. For example:
CkPt
Indicates a check point in the trace log, such as the starting or stopping of a trace
operation.
Rx
Indicates an OpenFlow message received by the controller (from a datapath).
Tx
Indicates an OpenFlow message sent from the controller (to a datapath).
The Data Path ID of the data path associated with the event.
The trace message.
70)).
. Alternatively, double-click on the event.
72).
"Exporting the
"OpenFlow Trace screen
OpenFlow Trace log 71
