Displaying the network Topology

The OpenFlow Topology screen includes the switches and end-nodes in the controller domain.
Figure 27 Topology viewer
The topology legend is show in the top right corner:
Switch — shown in light green
Collapsed Switch — shown in dark green
End Host — shown in orange

Using keyboard shortcuts to change the display

Use the icon to list the keyboard shortcuts you can use to change the display.
To use the keyboard shortcut keys you must first click somewhere in the topology view to bring
it into focus and then you can select a shortcut key. An outline around the topology indicates it
is in focus.
