Yamaha FZ8NA Service Manual page 65

Item
Exhaust pipe and muffler bolt
Exhaust pipe and exhaust pipe
bracket bolt
Muffler and muffler bracket bolt
Crankcase stud bolt
Crankcase bolt (main journal)
Crankcase bolt
Crankcase bolt
Crankcase bolt
Generator rotor cover bolt
Generator rotor cover bolt
Drive sprocket cover bolt
Left crankcase cover bolt
Clutch cover bolt
Clutch cover bolt
Pickup rotor cover bolt
Ventilation chamber cover bolt
Oil baffle plate bolt
Plate bolt (drive sprocket cover)
Pickup rotor cover blind bolt
Oil filler cap
Main gallery plug (oil return)
Main gallery plug
Oil return pipe bolt
Oil return plug
Stator coil lead bolt
Stator coil bolt
Generator rotor bearing housing
bolt
Generator rotor cover plug
Thermostat assembly stay bolt
Starter clutch idler gear bolt
Starter motor bolt
Starter motor lead nut
Clutch boss nut
Clutch spring bolt
Drive sprocket nut
Main axle retainer bolt
Shift fork guide bar retainer bolt
Stopper screw
Thread
Q'ty
size
M8 1 20 Nm (2.0 m·kgf, 14 ft·lbf)
M8 1 20 Nm (2.0 m·kgf, 14 ft·lbf)
M10 1 48 Nm (4.8 m·kgf, 35 ft·lbf)
M10 10 8 Nm (0.8 m·kgf, 5.8 ft·lbf)
M9 10
M6 10 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
M8 1 24 Nm (2.4 m·kgf, 17 ft·lbf)
M8 5 24 Nm (2.4 m·kgf, 17 ft·lbf)
M6 4 12 Nm (1.2 m·kgf, 8.7 ft·lbf)
M8 3 24 Nm (2.4 m·kgf, 17 ft·lbf)
M6 3 12 Nm (1.2 m·kgf, 8.7 ft·lbf)
M6 3 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
M6 7 12 Nm (1.2 m·kgf, 8.7 ft·lbf)
M6 1 12 Nm (1.2 m·kgf, 8.7 ft·lbf)
M6 6 12 Nm (1.2 m·kgf, 8.7 ft·lbf)
M6 4 12 Nm (1.2 m·kgf, 8.7 ft·lbf)
M6 3 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
M6 2 12 Nm (1.2 m·kgf, 8.7 ft·lbf)
M8 1 15 Nm (1.5 m·kgf, 11 ft·lbf)
M20 1 1.5 Nm (0.15 m·kgf, 1.1 ft·lbf)
M16 3 8 Nm (0.8 m·kgf, 5.8 ft·lbf)
M20 1 8 Nm (0.8 m·kgf, 5.8 ft·lbf)
M6 2 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
M12 2 32 Nm (3.2 m·kgf, 23 ft·lbf)
M6 1 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
M6 3 14 Nm (1.4 m·kgf, 10 ft·lbf)
M6 3 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
M20 1 8 Nm (0.8 m·kgf, 5.8 ft·lbf)
M6 2 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
M6 1 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
M6 2 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
M6 1 5 Nm (0.5 m·kgf, 3.6 ft·lbf)
M20 1 95 Nm (9.5 m·kgf, 69 ft·lbf)
M6 6 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
M22 1 85 Nm (8.5 m·kgf, 61 ft·lbf)
M6 3 12 Nm (1.2 m·kgf, 8.7 ft·lbf)
M6 2 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
M8 1 22 Nm (2.2 m·kgf, 16 ft·lbf)
2-16
TIGHTENING TORQUES
Tightening torque
See TIP.
Remarks
E
E
E
L = 60
mm (2.36
in)
E
LT
E
LT
LT
LT
LT
LT
LT
LT
LT
LT
Stake
Stake
LT
LT
LT
LT
