Yamaha FZ8NA Service Manual page 56

Clutch spring free length
Limit
Spring quantity
Transmission
Transmission type
Primary reduction system
Primary reduction ratio
Secondary reduction system
Secondary reduction ratio
Operation
Gear ratio
1st
2nd
3rd
4th
5th
6th
Main axle runout limit
Drive axle runout limit
Shifting mechanism
Shift mechanism type
Shift fork guide bar bending limit
Shift fork thickness
Air filter
Air filter element
Fuel pump
Pump type
Maximum consumption amperage
Fuel pressure
Fuel injector
Model/quantity
Throttle position sensor
Resistance
Output voltage (at idle)
Sub-throttle position sensor
Resistance
Output voltage (full close)
Fuel injection sensor
Crankshaft position sensor resistance
Cylinder identification sensor output voltage
(ON)
Cylinder identification sensor output voltage
(OFF)
Atmospheric pressure sensor output voltage
Intake air pressure sensor output voltage
Intake air temperature sensor resistance
ENGINE SPECIFICATIONS
52.50 mm (2.07 in)
49.88 mm (1.96 in)
6 pcs
Constant mesh 6-speed
Spur gear
65/43 (1.512)
Chain drive
46/16 (2.875)
Left foot operation
35/13 (2.692)
33/16 (2.063)
37/21 (1.762)
35/23 (1.522)
27/20 (1.350)
29/24 (1.208)
0.08 mm (0.0032 in)
0.08 mm (0.0032 in)
Shift drum and guide bar
0.050 mm (0.0020 in)
5.76–5.89 mm (0.2268–0.2319 in)
Oil-coated paper element
Electrical
6.0 A
324.0 kPa (3.24 kgf/cm², 47.0 psi)
297500-1720/4
2.64–6.16 kΩ
0.63–0.73 V
3–7 kΩ
0.3–0.4 V
336–504 Ω at 20 °C (68 °F)
More than 4.8 V
Less than 0.8 V
3.594–3.684 V at 101.32 kPa, 25 °C (77 °F)
3.594–3.684 V at 101.32 kPa, 25 °C (77 °F)
5.40–6.60 kΩ at 0 °C (32 °F)
0.29–0.39 kΩ at 80 °C (176 °F)
2-7
