Yamaha FZ8NA Service Manual page 55

End gap (installed)
Limit
Ring side clearance
Limit
2nd ring
Ring type
Dimensions (B × T)
End gap (installed)
Limit
Ring side clearance
Limit
Oil ring
Dimensions (B × T)
End gap (installed)
Connecting rod
Crankshaft-pin-to-big-end-bearing clearance
Limit
Bearing color code
Crankshaft
Width A
Width B
Runout limit C
Big end side clearance D
Journal oil clearance
Limit
Bearing color code
Clutch
Clutch type
Clutch release method
Clutch cable free play
Friction plate thickness
Wear limit
Plate quantity
Clutch plate thickness
Warpage limit
Plate quantity
ENGINE SPECIFICATIONS
0.25–0.35 mm (0.0098–0.0138 in)
0.60 mm (0.0236 in)
0.030–0.065 mm (0.0012–0.0026 in)
0.115 mm (0.0045 in)
Taper
0.80 × 2.50 mm (0.03 × 0.10 in)
0.35–0.50 mm (0.0138–0.0197 in)
0.85 mm (0.0335 in)
0.020–0.055 mm (0.0008–0.0022 in)
0.115 mm (0.0045 in)
1.50 × 2.00 mm (0.06 × 0.08 in)
0.10–0.35 mm (0.0039–0.0138 in)
0.034–0.058 mm (0.0013–0.0023 in)
0.09 mm (0.0035 in)
1: Blue 2: Black 3: Brown 4: Green
55.20–56.60 mm (2.173–2.228 in)
298.75–300.65 mm (11.76–11.84 in)
0.030 mm (0.0012 in)
0.160–0.262 mm (0.0063–0.0103 in)
0.013–0.037 mm (0.0005–0.0015 in)
0.10 mm (0.0039 in)
0.White 1.Blue 2.Black 3.Brown 4.Green
Wet, multiple-disc
Outer pull, rack and pinion pull
10.0–15.0 mm (0.39–0.59 in)
2.92–3.08 mm (0.115–0.121 in)
2.82 mm (0.1110 in)
8 pcs
1.90–2.10 mm (0.075–0.083 in)
0.10 mm (0.0039 in)
7 pcs
2-6
